丛枝菌根真菌对低磷胁迫下核桃幼苗根系磷吸收的影响及机制

doi:10.11707/j.1001-7488.LYKX20220253

摘要/Abstract

摘要：

目的: 探索低磷（P）胁迫下丛枝菌根（AM）真菌对核桃幼苗根系P吸收的影响及机制，为核桃幼苗的栽培生产提供参考。方法: 基于前期筛选的1个高效AM真菌菌株——沾屑多孢囊霉，分析适P（100 μmol·L^?1）和低P（1 μmol·L^?1）条件下沾屑多孢囊霉对‘辽河一号’核桃幼苗植株生长、根系构型、根系P含量、根系和土壤磷酸酶活性以及根系酸性磷酸酶分泌基因（JrPAP10和JrPAP12）和磷转运基因（JrPT3;1和JrPT3;2）相对表达量的影响。结果: 沾屑多孢囊霉接种3个月后，核桃幼苗根系侵染率达45.6%~53.2%，且低P处理可提高根系菌根侵染。在低P和适P条件下，接种沾屑多孢囊霉显著提高植物生物量和土壤酸性、中性和碱性磷酸酶活性；低P条件下沾屑多孢囊霉还显著改善植物根系构型，提高根系P含量以及根系酸性磷酸酶活性。根系JrPAP10和JrPT3;1均被沾屑多孢囊霉诱导表达，JrPAP12仅在低P条件时被沾屑多孢囊霉诱导表达，且JrPT3;2的表达量被沾屑多孢囊霉抑制。结论: AM真菌菌株沾屑多孢囊霉诱导低P条件下核桃幼苗JrPAP10、JrPAP12和JrPT3;1基因的表达，可促进土壤和根系磷酸酶活性，改善根系构型，从而提高核桃幼苗P吸收和生物量积累。

关键词: 核桃, 菌根, 磷, 磷酸酶, 磷转运基因

Abstract:

Objective: Walnut is a high-quality economic forest tree. Arbuscular mycorrhizal (AM) fungi can promote plant growth and phosphorus (P) uptake, however, the mechanisms by which AM fungi enhance nutrient utilization and plant growth in walnuts are not clear. This study aims to explore the effect of AM fungi on P uptake of walnuts under low P conditions and the associated mechanisms. Method: In this study, an effective AM fungal strain, Diversispora spurca, screened earlier, was used to inoculate Juglans regia cv. Liaohe 1 seedlings, and the effects of D. spurca on plant growth, root system architecture, root P, root and soil phosphatase activities, and the relative expression of root acid phosphatase secretion genes (JrPAP10 and JrPAP12) and phosphate transporter protein genes (JrPT3;1 and JrPT3;2) of J. regia cv. Liaohe 1 seedlings under appropriate P (100 μmol·L^?1) and low P (1 μmol·L^?1) level conditions were studied. Result: After three months of inoculation with D. spurca, the mycorrhizal colonization of walnut root system reached 45.6%–53.2%, and low P treatment significantly increased root mycorrhizal colonization, compared with appropriate P treatment. Inoculation of D. spurca significantly increased plant biomass and soil acid, neutral, and alkaline phosphatase activities under both low and appropriate P levels conditions. D. spurca also significantly improved root morphology as well as increased root P content and root acid phosphatase activity under low P condition. Root JrPAP10 expression was up-regulated by D. spurca under both low and appropriate P levels conditions, while JrPAP12 expression was induced by D. spurca only under low P level condition. In addition, D. spurca up-regulated the relative expression of JrPT3;1 in roots under both low P and appropriate P level conditions, while the expression of JrPT3;2 was inhibited by D. spurca. Conclusion: The AM fungus, D. spurca, can induce up-regulated expressions of JrPAP10, JrPAP12, and JrPT3;1 in roots of walnut seedlings under low P levels conditions, increase soil phosphatase, root acid phosphatase, and improve root morphology, and thereby enhancing P uptake and biomass accumulation of walnut seedlings.

Key words: walnut, mycorrhiza, phosphorus, phosphatase, phosphate transporter gene

中图分类号:

曹明奡,张菲,黄光明,刘瑞成,刘利平,吴强盛,徐永杰. 丛枝菌根真菌对低磷胁迫下核桃幼苗根系磷吸收的影响及机制[J]. 林业科学, 2023, 59(12): 117-124.

Ming'ao Cao,Fei Zhang,Guangming Huang,Ruicheng Liu,Liping Liu,Qiangsheng Wu,Yongjie Xu. Effects of Arbuscular Mycorrhizal Fungi on Phosphorus Uptake of Walnut Seedling Roots under Low Phosphorus Stress and the Potential Mechanisms[J]. Scientia Silvae Sinicae, 2023, 59(12): 117-124.

图/表 9

表1

图1

表2

表3

图2

表4

图3

图4

表5

参考文献 0

	黄京华, 骆世明, 曾任森, 等. 磷胁迫下AMF对玉米生长的影响. 广西农业生物科学, 2006, 25 (4): 321- 324.
	Huang J H, Luo S M, Zeng R S, et al. Effects of AMF on maize plant growth under phosphorus stress. Journal of Guangxi Agriculture and Biological Science, 2006, 25 (4): 321- 324.
	李永夫, 金松恒, 叶正钱, 等. 低磷胁迫对山核桃幼苗根系形态和生理特征的影响. 浙江林学院学报, 2010, 27 (2): 239- 245.
	Li Y F, Jin S H, Ye Z Q, et al. Root morphology and physiological characteristics in Carya cathayensis seedlings with low phosphorus stress. Journal of Zhejiang Forestry College, 2010, 27 (2): 239- 245.
	刘春艳, 吴强盛, 邹英宁. 2017. AM真菌对枳吸收磷和分泌磷酸酶的影响. 菌物学报, 36(7): 942− 949.
	Liu C Y, Wu Q S, Zou Y N. Effects of arbuscular mycorrhizal fungi on phosphorous uptake and phosphatase release in trifoliate orange seedlings. Mycosystema, 36(7): 942 − 949. ［in Chinese］
	舒　波. 2013. 丛枝菌根真菌促进枳(Poncirus trifoliata L. Raf)磷吸收效应及其机理研究. 武汉: 华中农业大学.
	Shu B. 2013. Effects and mechanism of aebuscular mycorrhizal fungi on phosphrous uptake in trifoliate orange. Wuhan: Huazhong Agricultural University. ［in Chinese］
	薛英龙, 李春越, 王苁蓉, 等. 丛枝菌根真菌促进植物摄取土壤磷的作用机制. 水土保持学报, 2019, 33 (6): 12- 22.
	Xue Y L, Li C Y, Wang C R, et al. Mechanisms of phosphorus uptake from soils by arbuscular mycorrhizal fungi. Journal of Soil and Water Conservation, 2019, 33 (6): 12- 22.
	张翠萍. 2014. 氮、磷对核桃苗木水分代谢的影响. 北京: 中国林业科学研究院.
	Zhang C P. 2014. Influence of nitrogen or phosphorous on water metabolism of Juglans regia seedlings. Beijing: Chinese Academy of Forestry. [ in Chinese ]
	赵兰坡, 姜　岩. 土壤磷酸酶活性测定方法的探讨. 土壤通报, 1986, (3): 138- 141. doi: 10.19336/j.cnki.trtb.1986.03.013
	Zhao L P, Jiang Y. Methods of soil phosphatase activity. Chinese Journal of Soil Science, 1986, (3): 138- 141. doi: 10.19336/j.cnki.trtb.1986.03.013
	Aarle I, Cavagnaro T R, Smith S E, et al. Metabolic activity of Glomus intraradices in Arum- and Paris-type arbuscular mycorrhizal colonization. New Phytologist, 2010, 166 (2): 611- 618.
	Behrooz A, Vahdati K, Rejali F, et al. Arbuscular mycorrhiza and plant growth-promoting bacteria alleviate drought stress in walnut. HortScience, 2019, 54 (6): 1087- 1092. doi: 10.21273/HORTSCI13961-19
	Cheng W J, Xu Y J, Huang G M, et al. Effects of five mycorrhizal fungi on biomass and leaf physiological activities of walnut. Notulae Botanicae Horti Agrobotanici Cluj-Napoca, 2020, 48, 2021- 2031. doi: 10.15835/nbha48412144
	Dolcet-Sanjuan R, Claveria E, Camprubi A, et al. Micropropagation of walnut trees (Juglans regia L. ) and response to arbuscular mycorrhizal inoculation. Agronomie, 1996, 16 (10): 639- 645. doi: 10.1051/agro:19961008
	Huang G M, Zou Y N, Wu Q S, et al. 2020. Mycorrhizal roles in plant growth, gas exchange, root morphology, and nutrient uptake of walnuts. Plant, Soil and Environment, 66: 295 − 302.
	Izabela F, Gerlach N, Almario J, et al. Plant-mediated effects of soil phosphorus on the root-associated fungal microbiota in Arabidopsis thaliana. New Phytologist, 2019, 221, 2123- 2137. doi: 10.1111/nph.15538
	Jiang F, Zhang L, Zhou J, et al. Arbuscular mycorrhizal fungi enhance mineralisation of orgaic phosphorus by carrying bacterial along their extraradical hyphae. New Phytologist, 2021, 2021,230, 304- 315.
	Li R B, Jing Y B, Mou J H, et al. Correlation between arbuscular mycorrhizal in walnut orchards under different intercropping with soil factors. Journal of West China Forestry Science, 2021, 50, 71- 78,84.
	Liu R C, Gao W Q, Srivastava A K, et al. Differential effects of exogenous glomalin-related soil proteins on plant growth of trifoliate orange through regulating auxin changes. Frontiers in Plant Science, 2021, 12, 745402. doi: 10.3389/fpls.2021.745402
	Livak K J, Schmittgen T D. Analysis of relative gene expression data using real-time quantitative PCR and the 2^−ΔΔCt method. Methods, 2001, 25 (4): 402- 408. doi: 10.1006/meth.2001.1262
	Mclachlan K D, Elliot D E, Marco D, et al. Leaf acid phosphatase isozymes in the diagnosis of phosphorus status in field-grown wheat. Crop & Pasture Science, 1987, 38 (1): 1- 13.
	Philips J M, Hayman D S. Improved procedures for clearing roots and staining parasitic and vesicular-arbuscular mycorrhizal fungi for rapid assessment of infection. Transactions of the British Mycological Society, 1970, 55 (1): 158- 161. doi: 10.1016/S0007-1536(70)80110-3
	Rausch C, Daram P, Brunner S, et al. A phosphate transporter expressed in arbuscule-containing cells in potato. Nature, 2001, 414, 462- 470. doi: 10.1038/35106601
	Shao Y D, Hu X C, Wu Q S, et al. Mycorrhizas promote P acquisition of tea plants through changes in root morphology and P transporter gene expression. South African Journal of Botany, 2021, 137, 455- 462. doi: 10.1016/j.sajb.2020.11.028
	Smith S E, Smith F A, Jakobsen I. Mycorrhizal fungi can dominate phosphate supply to plants irrespective of growth responses. Plant Physiology, 2003, 133, 16- 20. doi: 10.1104/pp.103.024380
	Tatsuhiro E, Smith S E, Andrew S F. Differentiation of polyphosphate metabolism between the extra- and intraradical hyphae of arbuscular mycorrhizal fungi. New Phytologist, 2010, 149 (3): 555- 563.
	Wu Q S, Li Y, Zou Y N, et al. Arbuscular mycorrhiza mediates glomalin-related soil protein production and soil enzyme activities in the rhizosphere of trifoliate orange grown under different P levels. Mycorrhiza, 2015, 25, 121- 130. doi: 10.1007/s00572-014-0594-3
	Xie X, Lai W, Che X, et al. A SPX domain-containing phosphate transporter from Rhizophagus irregularis handles phosphate homeostasis at symbiotic interface of arbuscular mycorrhizas. New Phytologist, 2022, 234 (2): 650- 671. doi: 10.1111/nph.17973
	Xu Y J, Liu F, Li X Y, et al. The mycorrhiza-induced maize ZmPt9 gene affects root development and phosphate availability in nonmycorrhizal plant. Plant Signaling and Behavior, 2018, 13, e1542240. doi: 10.1080/15592324.2018.1542240
	Yang L, Zou Y N, Tian Z H, et al. Effects of beneficial endophytic fungal inoculants on plant growth and nutrient absorption of trifoliate orange seedlings. Scientia Horticulturae, 2021, 277, 109815. doi: 10.1016/j.scienta.2020.109815
	Yu X, Liu X, Zhu T H, et al. Isolation and characterization of phosphate-solubilizing bacteria from walnut and their effect on growth and phosphorus mobilization. Biology and Fertility of Soils, 2011, 47 (4): 437- 446. doi: 10.1007/s00374-011-0548-2
	Zhang C, Simpson, R J, Kim, C M, et al. Do longer root hairs improve phosphorus uptake? Testing the hypothesis with transgenic Brachypodium distachyon lines overexpressing endogenous RSL genes. New Phytologist, 2018a, 217, 1654- 1666. doi: 10.1111/nph.14980
	Zhang L, Feng G, Declerck S. Signal beyond nutrient, fructose, exuded by an arbuscular mycorrhizal fungus triggers phytate mineralization by a phosphate solubilizing bacterium. ISME Journal, 2018b, 12, 2339- 2351. doi: 10.1038/s41396-018-0171-4
	Zhang L, Shi N, Fan J, et al. Arbuscular mycorrhizal fungi stimulate organic phosphate mobilization associated with changing bacterial community structure under field conditions. Environmental Microbiology, 2018c, 20, 2639- 2651. doi: 10.1111/1462-2920.14289
	Zuccaro A. Plant phosphate status drives host microbial preferences: a trade-off between fungi and bacteria. EMBO Journal, 2019, 39, e104144.

基因 Genes	登记号 Accessions	引物序列 Primer sequence（5’→3’）
JrPAP10	Jm3DG00060700	F: ACACCCCTCAATACCAATGGC
		R: ACTCTCATGGTTTCCCCCTCC
JrPAP12	Jm4DG00150700	F: ACACTCCACAATACAAATGGC
		R: TGGGCAATGCATAAAAACGAT
JrPHT3;1	Jm2DG00002500	F: ATCTCATCTGGGTTTGGAGTG
		R: CTGAGCACTGTAGCCAAGCAA
JrPHT3;2	Jm6DG00001600	F: TGCCCACTTTTCTAGGTTACA
		R: AGGTTTTGTACTTGGTTGCAT
18S rRNA	LOC109010173	F: GGTCAATCTTCTCGTTCCCTT
		R: TCGCATTTCGCTACGTTCTT

AM真菌接种 AM fungal inoculation	P处理 P treatment	地上部生物量 Shoot biomass/（g·plant^?1）	地下部生物量 Root biomass/（g·plant^?1）	总生物量 Total biomass/（g·plant^?1）
?A	?P	7.74±0.47d	9.05±0.69d	18.11±1.39d
?A	+P	9.86±0.52c	12.03±1.25c	24.07±2.51c
+A	?P	12.11±1.08b	13.72±0.42b	27.43±0.84b
+A	+P	15.43±1.02a	15.32±1.13a	30.63±2.27a
显著性 Significance
A		0.0001	<0.0001	<0.0001
P		0.0001	0.0004	0.0005
A×P		0.1688	0.1665	0.1455

AM真菌接种 AM fungal inoculation	P处理 P treatment	总长 Total length/cm	投影面积 Projected area/cm²	表面积 Surface area/cm²	平均直径 Average diameter/mm	体积 Volume/cm³
?A	?P	600±65b	47.6±4.3b	149±16b	0.73±0.04c	3.05±0.16b
	+P	609±70b	58.2±6.7a	167±15ab	0.97±0.06a	3.09±0.25b
+A	?P	728±65a	60.3±4.0a	190±13a	0.94±0.09ab	4.42±0.25a
	+P	645±38ab	53.1±7.3ab	183±21a	0.85±0.09b	4.57±0.39a
显著性 Significance
A		0.0199	0.2068	0.0047	0.2377	<0.0001
P		0.2489	0.5673	0.5240	0.0775	0.4998
A×P		0.1560	0.0091	0.1622	0.0007	0.7064

变量 Variables	A	P	A×P	变量 Variables	A	P	A×P
土壤酸性磷酸酶Soil acid phosphatase	<0.0001	0.7781	0.0061	JrPT3;1	<0.0001	0.0002	0.0002
土壤中性磷酸酶Soil acid phosphatase	<0.0001	<0.0001	<0.0001	JrPT3;2	0.0002	<0.0001	0.0062
土壤碱性磷酸酶Soil alkaline phosphatase	<0.0001	<0.0001	<0.0001	JrPAP10	<0.0001	<0.0001	<0.0001
根系酸性磷酸酶Root acid phosphatase	0.0189	0.0350	0.2499	JrPAP12	0.7294	0.0256	0.0095
根系P Root P	<0.0001	<0.0001	<0.0001

项目	土壤磷酸酶 Soil acid phosphatase			根系酸性磷酸酶 Root acid phosphatase	根系P Root P	JrPT3;1	JrPT3;2	JrPAP10	JrPAP12	根系性状 Root character
项目	酸性 Acid	中性 Neutral	碱性 Alkaline	根系酸性磷酸酶 Root acid phosphatase	根系P Root P	JrPT3;1	JrPT3;2	JrPAP10	JrPAP12	根长 Root length	投影面积 Projected area	表面积 Surface area	平均直径 Diameter	体积 Volume
根系P Root P	0.57	0.40	0.67*	0.11	1.00	0.27	?0.93**	0.13	0.66*	0.22	0.58*	0.59*	0.61*	0.49
菌根侵染率 Mycorrhizal colonization	0.84**	0.90**	0.77**	0.51	0.45	0.85**	?0.48	0.71**	0.10	0.60*	0.33	0.67**	0.23	0.91**
