土壤镉污染状态下不同生物炭添加比例对栓皮栎和白蜡生长生理的影响

doi:10.11707/j.1001-7488.LYKX20250116

摘要/Abstract

摘要：

目的: 通过植物与生物炭联合应用修复土壤镉污染，探究在模拟镉污染土壤中施加不同比例生物炭后北方常见树种栓皮栎和白蜡幼苗的生长生理状况和土壤镉吸附效果差异，为阐明树木对镉污染的响应机制以及提升镉污染治理能力提供参考。方法: 将栓皮栎和白蜡的实生苗在模拟镉污染土壤中进行盆栽试验，向土壤中施加不同比例（0%、2.5%、5%、10%）的生物炭，观察幼树生长、光合及抗氧化生理活性、镉在土壤和苗木中的迁移差异，分析栓皮栎和白蜡的镉吸附效果及生物炭修复作用。结果: 1） 5 mg·L^-1的镉污染导致：栓皮栎、白蜡土壤pH值分别显著降低10.8%和11.7%；栓皮栎苗木的苗高、地径、生物量分别降低18.5%、15.1%及38.9%；白蜡苗木的苗高和生物量分别提高3.9%和12.6%，但地径降低10.1%；2个树种幼苗的叶片净光合速率、蒸腾速率、气孔导度受到抑制；栓皮栎叶片抗氧化酶活性降低，而白蜡叶片抗氧化酶活性有所提高。2）施加生物炭后，土壤酸性得到改善，土壤镉含量显著降低，可缓解苗木胁迫状态，但生物炭施加比例提高至10%时，苗木生长与生理指标下降。3）栓皮栎和白蜡苗木对土壤中镉的吸附表现不同，白蜡有更高的富集系数，而栓皮栎有更高的转运系数。结论: 施加生物炭比例为2.5%时，植物对土壤中镉的吸附效果最好，土壤中镉含量最低；施加生物炭比例为5%时，能有效提高镉污染下的苗木生长状况，保障苗木稳定生长；白蜡的镉耐受性比栓皮栎高，苗木吸附镉的能力也更强。

关键词: 栓皮栎, 白蜡, 镉污染, 生物炭修复

Abstract:

Objective: Through the combined application of plants and biochar to repair soil cadmium pollution, the growth and physiological status of seedlings of two common northern tree species, Quercus variabilis and Fraxinus chinensis, and the differences in soil cadmium adsorption effects were explored after adding different proportions of biochar to simulated cadmium-contaminated soil. Method: A potted experiment was conducted on Q. variabilis and F. chinensis seedlings grown in simulated cadmium-contaminated soil. Different proportions of biochar (0%, 2.5%, 5%, and 10%) were added to the soil. The differences in seedling growth and physiological traits such as photosynthesis and antioxidant activities, as well as cadmium migration in the soil and seedlings were observed. The cadmium adsorption effects of Q. variabilis and F. chinensis and the remediation effects of biochar were analyzed. Result: 1) Cadmium contamination at 5 mg·L^?1 significantly decreased soil pH of Q. variabilis and F. chinensis by 10.8% and 11.7%, respectively. The height, ground diameter, and biomass of Q. variabilis seedlings decreased by 18.5%, 15.1%, and 38.9%, respectively. The height and biomass of F. chinensis seedlings increased by 3.9% and 12.6%, respectively, but the ground diameter decreased by 10.1%. The net photosynthetic rate, transpiration rate, and stomatal conductance of leaves of both tree species were inhibited. Antioxidant enzyme activities in Q. variabilis leaves decreased, while those in F. chinensis increased. 2) Biochar applications increased soil acidity and significantly reduced soil cadmium content, alleviating seedling stress. However, when the biochar application rate was increased to 10%, the growth and physiological indicators of seedlings decreased. 3) Q. variabilis and F. chinensis seedlings exhibited different cadmium adsorption behaviors in soil, with F. chinensis having a higher enrichment coefficient and Q. variabilis having a higher transport coefficient. Conclusion: When the biochar application ratio is 2.5%, the plants have the best adsorption effect on cadmium in the soil and the cadmium content in the soil is the lowest; when the biochar application ratio is 5%, it can effectively improve the growth of seedlings under cadmium pollution and ensure the stable growth of seedlings. The cadmium tolerance of F. chinensis is higher than that of Q. variabilis, and the seedlings have a stronger ability to adsorb cadmium.

Key words: Quercus variabilis, Fraxinus chinensis, cadmium contamination, biochar remediation

中图分类号:

S718.43

郑志伟,马铭,刘勇,王佳茜,朱雨帆,李国雷. 土壤镉污染状态下不同生物炭添加比例对栓皮栎和白蜡生长生理的影响[J]. 林业科学, 2025, 61(11): 14-23.

Zhiwei Zheng,Ming Ma,Yong Liu,Jiaxi Wang,Yufan Zhu,Guolei Li. Effects of Different Biochar Addition Ratios on the Growth and Physiology of Quercus variabilis and Fraxinus chinensis in Cadmium-Contaminated Soil[J]. Scientia Silvae Sinicae, 2025, 61(11): 14-23.

图/表 11

表1

图1

表2

图2

图3

表3

图4

表4

图5

表5

图6

参考文献 0

	卜晓莉, 薛建辉. 生物炭对土壤生境及植物生长影响的研究进展. 生态环境学报, 2014, 23 (3): 535- 540.
	Bu X L, Xue J H. Biochar effects on soil habitat and plant growth: a review. Ecology and Environmental Sciences, 2014, 23 (3): 535- 540.
	曹艳晓, 陈　诺, 徐鑫宇, 等. 生物炭修复塑料-镉复合污染土壤潜力与机制研究. 中国环境科学, 2025, 45 (3): 1395- 1409.
	Cao Y X, Chen N, Xu X Y, et al. Exploring the potential of biochar for the remediation of soils co-contaminated with plastics and cadmium. China Environmental Science, 2025, 45 (3): 1395- 1409.
	陈　宏, 徐秋曼, 王　葳, 等. 2000. 镉对小麦幼苗脂质过氧化和保护酶活性的影响. 西北植物学报, 20 (3): 399−403.
	Chen H, Xu Q M, Wang W, et al. 2000. The effect of Cd²⁺ on the activity of protectiase and cell membrance lipid peroxidation change of wheat seedlings. Acta Botanica Boreali-Occidentalia Sinica, 20(3): 399−403. ［in Chinese］
	高梦雨. 2020. 长期施用生物炭和炭基肥对土壤有机碳及团聚体微生物特性的影响. 沈阳: 沈阳农业大学.
	Gao M Y. 2020. Effects of long-term application of biochar and biochar-based fertilizer on soil organic carbon and aggregate microbial characteristics. Shenyang: Shenyang Agricultural University. ［in Chinse］
	国家林业局. 2001. 生态公益林建设技术规程(GB/T 18337.3—2001). 北京: 中国标准出版社.
	State Forestry Administration. 2001. Non-commercial forest construction-technical regulation(GB/T 18337.3—2001). Beijing: Standards Press of China. ［in Chinese］
	贾中民, 王　力, 魏　虹, 等. 垂柳和旱柳对镉的积累及生长光合响应比较分析. 林业科学, 2013, 49 (11): 51- 59.
	Jia Z M, Wang L, Wei H, et al. Comparative analysis of Salix babylonica and Salix matsudana for their cadmium accumulation, growth and photosynthesis in response to cadmium contamination. Scientia Silvae Sinicae, 2013, 49 (11): 51- 59.
	简敏菲, 何旭芬, 彭雨露, 等. 生物炭对镉污染土壤中紫花地丁的生长及生理生态的影响. 江西师范大学学报(自然科学版), 2022, 46 (1): 99- 106.
	Jian M F, He X F, Peng Y L, et al. The effects of biochar on the growth and physiological ecology of Viola philippica in cadmium-contaminated soil. Journal of Jiangxi Normal University (Natural Science Edition), 2022, 46 (1): 99- 106.
	蒋欣梅, 薛冬冬, 于锡宏, 等. 玉米秸秆生物炭对镉污染土壤中小白菜生长的影响. 江苏农业学报, 2020, 36 (4): 1000- 1006.
	Jiang X M, Xue D D, Yu X H, et al. Effects of corn-stalk biochar on the growth of Chinese cabbage in cadmium contaminated soil. Jiangsu Journal of Agricultural Sciences, 2020, 36 (4): 1000- 1006.
	雷星宇, 胡　瑶, 邓钢桥, 等. 钝化剂对卷丹百合镉含量及生理特性的影响. 中国农学通报, 2022, 38 (19): 66- 72.
	Lei X Y, Hu Y, Deng G Q, et al. Effects of passivator on cadmium content and physiological characteristics of Lilium lancifolium. Chinese Agricultural Science Bulletin, 2022, 38 (19): 66- 72.
	李　彪, 李　丹. 微波消解ICP-MS法测定植物样品中的镉. 现代科学仪器, 2011, 28 (1): 112- 113.
	Li B, Li D. Determination of trace amounts of cadmium in a plant samples by ICP-MS. Modern Scientific Instruments, 2011, 28 (1): 112- 113.
	李合生. 2000. 植物生理生化试验原理和技术. 北京: 高等教育出版社.
	Li H S. 2000. Principles and techniques of plant physiology and biochemistry experiments. Beijing: Higher Education Press. ［in Chinese］
	李鸿博, 钟　怡, 张昊楠, 等. 生物炭修复重金属污染农田土壤的机制及应用研究进展. 农业工程学报, 2020, 36 (13): 173- 185.
	Li H B, Zhong Y, Zhang H N, et al. Mechanism for the application of biochar in remediation of heavy metal contaminated farmland and its research advances. Transactions of the Chinese Society of Agricultural Engineering, 2020, 36 (13): 173- 185.
	李江月, 陈　良, 赵志宏, 等. 提质培优技术对秦岭南坡栓皮栎林结构和健康的影响. 绿色科技, 2024, 26 (11): 76- 81.
	Li J Y, Chen L, Zhao Z H, et al. Effects of quality improvement, training and tending on the structures and health of Quercus variabilis Bl. on the southern slope of the Qinling Mountains. Journal of Green Science and Technology, 2024, 26 (11): 76- 81.
	李京威, 党晶晶, 关卫省. 2023. 重金属污染土壤修复方法研究进展. 南昌: 中国环境科学学会2023年科学技术年会论文集(二), 732−736.
	Li J W, Dang J J, Guan W S. 2023. Research progress on remediation methods for heavy metal contaminated soil. Nanchang: Proceedings of the 2023 annual conference of science and technology of the Chinese Society for Environmental Sciences (II), 732−736. ［in Chinese］
	李　康. 2019. 生物炭对龙葵生长和富集Cd能力的影响研究. 济南: 济南大学.
	Li K. 2019. Study on the effects of biochar on growth and cadmium accumulation of Solanum nigrum L. Jinan: University of Jinan. ［in Chinese］
	刘阿梅. 2014. 生物炭对植物生长发育及镉吸收的影响. 湘潭: 湖南科技大学.
	Liu A M. 2014. Effects of biochar on plant growth and uptake of heavy metal cadmium. Xiangtan: Hunan University of Science and Technology. ［in Chinese］
	刘　克, 和文祥, 张　红, 等. 镉在小麦各部位的富集和转运及籽粒镉含量的预测模型. 农业环境科学学报, 2015, 34 (8): 1441- 1448.
	Liu K, He W X, Zhang H, et al. Cadmium accumulation and translocation in wheat and grain Cd prediction. Journal of Agro-Environment Science, 2015, 34 (8): 1441- 1448.
	卢德亮, 乔　璐, 陈立新, 等. 哈尔滨市区绿地土壤重金属污染特征及植物富集. 林业科学, 2012, 48 (8): 16- 24.
	Lu D L, Qiao L, Chen L X, et al. Soil pollution characteristics by heavy metals and the plant enrichment in green space of urban areas of Harbin. Scientia Silvae Sinicae, 2012, 48 (8): 16- 24.
	马阳阳, 廉梅花, 王　鹏. 超富集植物修复土壤重金属污染及强化措施研究进展. 环境保护与循环经济, 2024, 44 (1): 25- 32.
	Ma Y Y, Lian M H, Wang P. Research progress on the remediation of heavy metal pollution in soil by hyperenrichment plants and enhancement measures. Environmental Protection and Circular Economy, 2024, 44 (1): 25- 32.
	宋　洋, 李晓娜, 蒋　新. 2019. 生物炭和根系分泌物对土壤中多环芳烃消减与微生物群落结构的影响. 重庆: 2019年中国土壤学会土壤环境专业委员会、土壤化学专业委员会联合学术研讨会.
	Song Y, Li X N, Jiang X. 2019. The effects of biochar and root secretions on the reduction of polycyclic aromatic hydrocarbons in soil and the structure of microbial communities. Chongqing: The 2019 joint academic symposium of the Soil Environment Professional Committee and Soil Chemistry Professional Committee of the Chinese Society of Soil Science. ［in Chinese］
	檀建新, 尹　君, 王文忠, 等. 镉对小麦、玉米幼苗生长和生理生化反应的影响. 河北农业大学学报, 1994, 17 (S1): 83- 87.
	Tan J X, Yin J, Wang W Z, et al. Effects of cadmium on the growth and physiologicol and biochemical reaction of wheat seedlings. Journal of Hebei Agricultural University, 1994, 17 (S1): 83- 87.
	王晓娟, 王文斌, 杨　龙, 等. 重金属镉(Cd)在植物体内的转运途径及其调控机制. 生态学报, 2015, 35 (23): 7921- 7929.
	Wang X J, Wang W B, Yang L, et al. Transport pathways of cadmium (Cd) and its regulatory mechanisms in plant. Acta Ecologica Sinica, 2015, 35 (23): 7921- 7929.
	吴立文, 李国雷, 杨钦淞, 等. 栎树研究进展与展望. 林业科学, 2025, 61 (10): 1- 14.
	Wu L W, Li G L, Yang Q S, et al. Research progress and prospect on oak trees. Scientia Silvae Sinicae, 2025, 61 (10): 1- 14.
	赵牧秋, 金凡莉, 孙照炜, 等. 制炭条件对生物炭碱性基团含量及酸性土壤改良效果的影响. 水土保持学报, 2014, 28 (4): 299- 303, 309.
	Zhao M Q, Jin F L, Sun Z W, et al. Effects of pyrolysis condition on basic group of biochar and amelioration of acid soil. Journal of Soil and Water Conservation, 2014, 28 (4): 299- 303, 309.
	赵蕊蕊, 刘　勇, 王　凯. 生物炭和有机肥对毛白杨人工林地木质分解及土壤养分循环相关酶活性的影响. 林业科学, 2023, 59 (11): 1- 11.
	Zhao R R, Liu Y, Wang K. Effects of biochar and manure on wood decomposition and soil enzyme activities related soil nutrient cycling in a triploid Populus tomentosa plantation. Scientia Silvae Sinicae, 2023, 59 (11): 1- 11.
	中华人民共和国生态环境部. 2016. 土壤和沉积物 12种金属元素的测定王水提取-电感耦合等离子体质谱法(HJ 803—2016). 北京: 中国环境科学出版社.
	Ministry of Ecology and Environment of the People’s Republic of China. 2016. Soil and sediment-determination of aqua regia extracts of 12 metal elements-inductively coupled plasma mass spectrometry(HJ 803—2016). Beijing: China Environmental Press. ［in Chinese］
	中华人民共和国生态环境部. 2018. 土壤环境质量农用地土壤污染风险管控标准(试行)(GB 15618—2018). 北京: 中国环境科学出版社.
	Ministry of Ecology and Environment of the People’s Republic of China. 2018. Soil environmental quality risk control standard for soil contamination of agricultural land(GB 15618—2018). Beijing: China Environmental Press. ［in Chinese］
	中华人民共和国生态环境部. 2019. 土壤pH值的测定电位法(HJ 962—2018). 北京: 中国环境科学出版社.
	Ministry of Ecology and Environment of the People’s Republic of China. 2019. Soil-determination of pH-potentiometry(HJ 962—2018). Beijing: China Environmental Press. ［in Chinese］
	周际海, 程　坤, 郜茹茹, 等. 土壤镉污染对香樟幼苗光合和生理特性的影响. 林业科学, 2020, 56 (6): 193- 201.
	Zhou J H, Cheng K, Gao R R, et al. Photosynthesis and other physiological characteristics of Cinnamomum camphora seedlings under cadmium stress. Scientia Silvae Sinicae, 2020, 56 (6): 193- 201.
	朱秀红, 张梦霄, 崔明康, 等. 不同生物炭种类和用量对镉胁迫下小麦幼苗光合特性和镉积累的影响. 河南农业大学学报, 2023, 57 (3): 404- 412.
	Zhu X H, Zhang M X, Cui M K, et al. Effects of different biochar types and dosages on photosynthetic characteristics and cadmium accumulation in wheat under cadmium stress. Journal of Henan Agricultural University, 2023, 57 (3): 404- 412.
	Gill S S, Hasanuzzaman M, Nahar K, et al. Importance of nitric oxide in cadmium stress tolerance in crop plants. Plant Physiology and Biochemistry, 2013, 63, 254- 261. doi: 10.1016/j.plaphy.2012.12.001
	He L Z, Fan S L, Müller K, et al. Comparative analysis biochar and compost-induced degradation of di-(2-ethylhexyl) phthalate in soils. Science of The Total Environment, 2018, 625 (1): 987- 993.
	Hasan S A, Fariduddin Q, Ali B, et al. Cadmium: toxicity and tolerance in plants. Journal of Environmental Biology, 2009, 30 (2): 165- 174.
	Wang L, Chen H R, Wu J Z, et al. Effects of magnetic biochar-microbe composite on Cd remediation and microbial responses in paddy soil. Journal of Hazardous Materials, 2021, 414 (15): 125494.
	Zhu Q H, Huang D Y, Liu S L, et al. 2013. Accumulation and subcellular distribution of cadmium in ramie (Boehmeria nivea L. Gaud. ) planted on elevated soil cadmium contents. Plant, Soil and Environment, 59(2): 57–61.

变异来源 Source of variation	土壤镉含量 Soil Cd content	土壤pH值 Soil pH value
处理 Treatment	41.5^**	9.6^**
树种 Species	4.5^*	1.2
处理×树种 Treatment×species	0.4	0.2

变异来源 Source of variation	苗高 Seedling height	地径 Ground diameter	地上部分生物量 Aboveground biomass	地下部分生物量 Underground biomass	总生物量Total biomass
处理 Treatment	15.5^**	11.8^**	7.6^**	7.7^**	7.3^**
树种 Species	3.3	124.4^**	0.1	5.4^*	0.2
处理×树种 Treatment× species	1.4	0.4	2.5	3.4^*	2.7^*

变异来源 Source of variation	地上部分镉含量 Cd content in aboveground	地下部镉含量 Cd content in underground	总镉含量 Total Cd content	富集系数 Bioconcen tration factor	转运系数 Transfer factor
处理 Treatment	14.2^**	51.1^**	52.8^**	8.8^**	17.8^**
树种 Species	11.2^**	186.8^**	107.9^**	44.3^**	106.6^**
处理×树种 Treatment× species	8.2^**	15.4^**	7.3^**	1.4	25.3^**

变异来源 Source of variation	最大光化学量子产量Fv/Fm Maximal quantum yield of PSⅡ	叶片净光合速率 Net photosynthetic rate of leaves	胞间CO₂浓度 Intercellular CO₂ concentration	蒸腾速率 Transpiration rate	气孔导度 Stomatal conductance	叶片水分利用效率 Water use efficiency of leaf
处理 Treatment	1.8	2.2	2.2	3.0^*	3.3^*	1.4
树种 Species	30.0^**	22.5^**	5.8^*	0.03	6.9^**	1.7
处理×树种 Treatment×species	1.9	0.1	4.1^**	1.9	1.6	3.7^**

变异来源 Source of variation	超氧化物歧化酶（SOD酶）活性 Superoxide dismutase enzyme activity	过氧化物酶（POD酶）活性 Peroxidase enzyme activity	过氧化氢酶（CAT酶）活性 Catalase enzyme activity
处理 Treatment	1.2	0.8	1.2
树种 Species	71.5^**	65.3^**	31.6^**
处理×树种 Treatment × species	0.9	0.8	0.8
