基于电子自旋共振和拉曼光谱技术的榛子油氧化特性探析与评价

doi:10.11707/j.1001-7488.20200410

摘要/Abstract

摘要：

目的: 研究榛子油氧化过程中的品质变化规律、自由基产生规律以及油脂内部分子结构的变化，揭示榛子油氧化特性，为榛子油品质检测与货架期预测提供重要的理论依据和技术支持。方法: 以平欧杂种榛主栽品种‘达维’为试验材料，采用60℃烘箱法进行榛子油加速氧化试验，测定榛子油在氧化过程中过氧化值（POV）、p-茴香胺值（AV）、总氧化值（TV）、共轭二烯值、脂肪酸相对含量、总类胡萝卜素含量、自由基相对含量和分子内部结构的变化规律，并对各指标进行相关性分析。结果: 榛子油氧化过程中，POV、AV、TV和共轭二烯值的初始值分别为6.22 meq·kg^-1、0.31、12.75和0.12，加速氧化40天后分别显著增加至370.47 meq·kg^-1、25.91、766.85和3.48，饱和脂肪酸、不饱和脂肪酸相对含量分别从5.96%、93.69%变化至6.35%、93.20%，自由基相对含量从8.41快速增加至28.09；榛子油中总类胡萝卜素氧化30天时含量为0；拉曼光谱中类胡萝素1 158和1 524 cm^-1特征峰强度变化与总类胡萝卜素含量的变化趋势保持一致；拉曼相对强度I_{972 cm^-1}/I_{1 441 cm^-1}、I_{1 268 cm^-1}/I_{1 441 cm^-1}、I_{1 158 cm^-1}/I_{1 441 cm^-1}和I_{1 524 cm^-1}/I_{1 441 cm^-1}均与不饱和度呈正相关。结论: 榛子油氧化大致分为3个阶段，即初始缓慢氧化阶段、中间快速氧化阶段和后期深度氧化阶段，综合4个常规氧化指标（POV、AV、TV和共轭二烯值）可以很好评价榛子油的氧化程度；类胡萝卜素是榛子油色泽的主要贡献因子，与榛子油氧化程度密切相关；自由基相对含量、拉曼光谱特征峰强度和总类胡萝卜素含量指标与常规氧化指标具有极显著相关性，证明电子自旋共振和拉曼光谱技术可用于评价榛子油的氧化程度；电子自旋共振和拉曼光谱技术作为传统油质氧化评价方法的补充或替代具有很大潜力，可为油脂品质快速检测提供新方法。

关键词: 平欧杂种榛, 类胡萝卜素, 电子自旋共振, 拉曼光谱, 氧化特性

Abstract:

Objective: This study investigated the quality change, free radical formation and fatty acid composition of hazelnut oil during oxidation process, and there by revealed the oxidative characteristics which aimed to provide important theoretical basis and technical supports for the quality detection and shelf life prediction for hazelnut oil. Method: A main cultivar of hybrid hazelnut (Corylus heterophylla×C.avellana 'Dawei') was used as the trial material. Hazelnut oil was obtained by the screw pressing method. The accelerated oxidation experiment of hazelnut oil was carried out in an oven at 60℃. The changed regulation of peroxide value (POV), p-anisidine value (AV), total oxidation value (TV), conjugated diene value, relative contents of fatty acids, total carotenoid content, relative content of free radicals and internal structure of the molecules were determined in hazelnut oil during the oxidative period, and the correlations of these indicators were analyzed. Result: During the oxidative process of hazelnut oil, the initial values of POV, AV, TV and conjugated diene were 6.22 meq·kg^-1, 0.31, 12.75 and 0.12, and then the values increased significantly to 370.47 meq·kg^-1, 25.91, 766.85 and 3.48 at the end of the oxidation process for 40 days, respectively. The relative contents of saturated fatty acids and unsaturated fatty acids changed from 5.96% and 93.69% to 6.35% and 93.20%, respectively. The relative content of free radicals increased rapidly from 8.41 to 28.09. Total carotenoid content of hazelnut oil was not detected after 30 days of oxidation. The change of characteristic peak intensity of 1 158 cm^-1 and 1 524 cm^-1 in Raman spectra was consistent with total carotenoid content. Raman relative intensities of I_{972 cm^-1}/I_{1 441 cm^-1}, I_{1 268 cm^-1}/I_{1 441 cm^-1}, I_{1 158 cm^-1}/I_{1 441 cm^-1} and I_{1 524 cm^-1}/I_{1 441 cm^-1} were positively correlated with the unsaturated degree. Conclusion: The oxidation of hazelnut oil is roughly divided into three stages, namely initial slowly oxidative stage, rapidly intermediate oxidative stage and later deeply oxidative stage. The oxidative degree of hazelnut oil can be well evaluated according to comprehensive four oxidation indexes (namely, POV, AV, TV and conjugated diene value). Carotenoids are the main contribution factors to the color of hazelnut oil, and closely related to the oxidative degree of hazelnut oil.The relative content of free radicals, characteristic peak intensity of Raman spectra and total carotenoid content have a significant correlation with conventional oxidation indexes, which proves that electron spin resonance (ESR) and Raman spectroscopy can be used to evaluate the oxidative degree in hazelnut oil. ESR and Raman spectroscopy have great potential as supplement or replacement for evaluation methods of traditional lipid oxidation, providing a new method for rapidly nondestructive test of lipid quality.

Key words: hybrid hazelnut, carotenoid, electron spin resonance, Raman spectroscopy, oxidative characteristics

中图分类号:

TS225.1

崔娜娜,王贵禧,李如华,马庆华,赵天田,梁丽松. 基于电子自旋共振和拉曼光谱技术的榛子油氧化特性探析与评价[J]. 林业科学, 2020, 56(4): 89-98.

Nana Cui,Guixi Wang,Ruhua Li,Qinghua Ma,Tiantian Zhao,Lisong Liang. Analysis and Evaluation on Oxidation Characteristics of Hazelnut Oil Based on Electron Spin Resonance and Raman Spectroscopy[J]. Scientia Silvae Sinicae, 2020, 56(4): 89-98.

图/表 9

图1

表1

图2

图3

图4

图5

图6

图7

表2

参考文献 0

	李占龙, 周密, 左剑, 等. 红外光谱和拉曼光谱法分析玉米种子的成分. 分析化学, 2007. 35 (11): 1636- 1638. doi: 10.3321/j.issn:0253-3820.2007.11.019
	Li Z L , Zhou M , Zuo J , et al. Infrared and Raman spectral analysis for the corn seed. Chinese Journal of Analytical Chemistry, 2007. 35 (11): 1636- 1638. doi: 10.3321/j.issn:0253-3820.2007.11.019
	林新月, 朱松, 李玥. 拉曼光谱测定食品油脂的氧化. 食品与生物技术学报, 2017. 36 (6): 610- 616. doi: 10.3969/j.issn.1673-1689.2017.06.008
	Lin X Y , Zhu S , Li Y . Evaluation of edible oils oxidation by Raman spectroscopy. Journal of Food Science and Biotechnology, 2017. 36 (6): 610- 616. doi: 10.3969/j.issn.1673-1689.2017.06.008
	刘印志, 胡淑珍, 曾祥菊, 等. 榛子油的研究进展. 中国油脂, 2017. 42 (10): 22- 25. doi: 10.3969/j.issn.1003-7969.2017.10.005
	Liu Y Z , Hu S Z , Zeng X J , et al. Progress in hazelnut oil. China and Fats, 2017. 42 (10): 22- 25. doi: 10.3969/j.issn.1003-7969.2017.10.005
	秦桂珍, 兰士波, 李红艳. 榛子种质资源研究现状及应用策略. 安徽林业科技, 2012. 38 (1): 31- 33.
	Qin G Z , Lan S P , Li H Y . Present research progress and application strategies of germplasm resources of Corylus heterophll. Anhui Forestry Science and Technology, 2012. 38 (1): 31- 33.
	孙月娥, 王卫东. 国内外脂质氧化检测方法研究进展. 中国粮油学报, 2010. 25 (9): 123- 128.
	Sun Y E , Wang W D . Domestic and foreign research progress on analysis methods of lipid oxidation. Journal of the Chinese Cereals and Oils Association, 2010. 25 (9): 123- 128.
	田文瀚. 2012.不同品种榛子营养品质的分析.郑州:河南农业大学硕士学位论文.
	Tian W H. 2012. Nutrition quality analysis of different varieties of hazelnut. Zheng Zhou: MS thesis of Henan Agricultural University.[in Chinese]
	于修烛, 杜双奎, 王青林, 等. 傅里叶红外光谱法油脂定量分析研究进展. 中国粮油学报, 2009. 24 (1): 129- 136.
	Yu X Z , Du S K , Wang Q L , et al. Advance of research on edible oil quantitativeanalysis using FTIR spectroscopy. Journal of the Chinese Cereals and Oils Association, 2009. 24 (1): 129- 136.
	Agregán R , Lorenzo J M , Munekata P E S , et al. Assessment of the antioxidant activity of Bifurcaria bifurcata aqueous extract on canola oil. Effect of extract concentration on the oxidation stability and volatile compound generation during oil storage. Food Research International, 2017. 99 (3): 1095- 1102.
	Alasalvar C , Amaral J S , Shahidi F . Functional lipid characteristics of Turkish Tombul hazelnut (Corylus avellana L.). Journal of Agricultural and Food Chemistry, 2006. 54 (26): 10177- 10183. doi: 10.1021/jf061702w
	Baeten V , Meurens M , Morales M T , et al. Detection of virgin olive oil adulteration by Fourier transform Raman spectroscopy. Journal of Agricultural Food Chemistry, 1996. 44 (8): 2225- 2230. doi: 10.1021/jf9600115
	Berhe D T , Eskildsen C E , Lametsch R , et al. Prediction of total fatty acid parameters and individual fatty acids in pork backfat using Raman spectroscopy and chemometrics:Understanding the cage of covariance between highly correlated fat parameters. Meat Science, 2016. 111, 18- 26. doi: 10.1016/j.meatsci.2015.08.009
	Bonoli-Carbognin M , Cerretani L , Bendini A , et al. Bovine serum albumin produces a synergistic increase in the antioxidant activity of virgin olive oil phenolic compounds in oil-in-water emulsions. Journal of Agricultural and Food Chemistry, 2008. 56 (16): 7076- 7081. doi: 10.1021/jf800743r
	Carmona M Á , Lafont F , Jiménez-Sanchidrián C , et al. Raman spectroscopy study of edible oils and determination of the oxidative stability at frying temperatures. European Journal of Lipid Science and Technology, 2014. 116 (11): 1451- 1456. doi: 10.1002/ejlt.201400127
	Choe E , Min D B . Mechanisms and factors for edible oil oxidation. Comprehensive Reviews in Food Science and Food Safety, 2006. 5 (4): 169- 186. doi: 10.1111/j.1541-4337.2006.00009.x
	Chen Q , Xie Y , Xi J , et al. Characterization of lipid oxidation process of beef during repeated freeze-thaw by electron spin resonance technology and Raman spectroscopy. Food Chemistry, 2018. 243, 58- 64. doi: 10.1016/j.foodchem.2017.09.115
	Durmaz G , Gökmen V . Effect of refining on bioactive composition and oxidative stability of hazelnut oil. Food Research International, 2019. 116, 586- 591. doi: 10.1016/j.foodres.2018.08.077
	Halliwell B , Chirico S . Lipid peroxidation:its mechanism, measurement, and significance. American Journal of Clinical Nutrition, 1993. 57 (5): 715- 725. doi: 10.1093/ajcn/57.5.715S
	Jerzykiewicz M , D'wieląg-Piasecka I , Witwicki M , et al. α-Tocopherol impact on oxy-radical induced free radical decomposition of DMSO:spintrapping EPR and theoretical studies. Chemical Physics, 2011. 383 (1/3): 27- 34.
	Li-Chan E . Developments in the detection of adulteration of olive oil. Trends in Food Science and Technology, 1994. 5 (1): 3- 11. doi: 10.1016/0924-2244(94)90042-6
	Lyndgaard L B , Sorensen K M , Berg F , et al. Depth profiling of porcine adipose tissue by Raman spectroscopy. Journal of Raman Spectroscopy, 2012. 43 (4): 482- 489. doi: 10.1002/jrs.3067
	Muik B , Lendl B , Molina-Díaz A , et al. Direct monitoring of lipid oxidation in edible oils by Fourier transform Raman spectroscopy. Chemistry and Physics of Lipids, 2005. 134 (2): 173- 182. doi: 10.1016/j.chemphyslip.2005.01.003
	Oliveira I , Sousa A , Morais J S , et al. Chemical composition, and antioxidant and antimicrobial activities of three hazelnut (Corylus avellana L.) cultivars. Food Chemical Toxicology, 2008. 46 (5): 1801- 1807. doi: 10.1016/j.fct.2008.01.026
	Poiana M A . Enhancing oxidative stability of sunflower oil during convective and microwave heating using grape seed extract. International Journal of Molecular science, 2012. 13 (7): 9240- 9259. doi: 10.3390/ijms13079240
	Pratt D A , Mills J H , Porter N A . Theoretical calculations of carbon-oxygen bond dissociation enthalpies of peroxyl radicals formed in the autoxidation of lipids. Journal of American Chemical Society, 2003. 125 (19): 5801- 5810. doi: 10.1021/ja034182j
	Sullivan J C , Budge S M , St-Onge M . Modeling the primary oxidation in commercial fish oil preparations. Lipids, 2011. 46 (1): 78- 93.
	Sánchez-Alonso I , Carmona P , Careche M . Vibrational spectroscopic analysis of hake (Merluccius merluccius L.) lipids during frozen storage. Food Chemistry, 2012. 132 (1): 160- 167. doi: 10.1016/j.foodchem.2011.10.047
	Shahidi F, Wanasundara U N. 2002. Method for measuring oxidative rancidity in fats and oils//Food lipids, New York: Marcel Dekker, 465.
	Siew W L, Tang T S, Tan Y A. 1995. Methods of test for palm oil and palm oil products//PORIM test methods. Palm Oil Research Institute of Malaysia, 43-44.
	Weber J , Bochi V C , Ribeiro C P , et al. Effect of different cooking methods on the oxidation, proximate and fatty acid composition of silver catfish(Rhamdia quelen)fillets. Food Chemistry, 2008. 106 (1): 140- 146. doi: 10.1016/j.foodchem.2007.05.052
	Westermann S , Brüggemann D A , Karsten O , et al. Light-induced formation of free radicals in cream cheese. Food Chemistry, 2009. 116 (4): 974- 981. doi: 10.1016/j.foodchem.2009.03.059
	Yang Z , Zhao T T , Ma Q H , et al. Resolving the speciation patterns and evolutionary history of the intercontinental disjunct genus Corylus(Betulaceae) using Genome-wide SNPs. Frontiers in Plant Science, 2018. 9, 1386. doi: 10.3389/fpls.2018.01386
	Yettella R R , Castrodale C , Proctor A . Oxidative stability of conjugated linoleic acid rich soy oil. Journal of America Oil Chemists' Society, 2012. 89 (4): 685- 693. doi: 10.1007/s11746-011-1962-1
	Yi J , Andersen M L , Skibsted L H . Interactions between tocopherols, tocotrienols and carotenoids during autoxidation of mixed palm olein and fish oil. Food Chemistry, 2011. 127 (4): 1792- 1797. doi: 10.1016/j.foodchem.2011.02.061
	Zhang X F , Zou M Q , Qi X H , et al. Quantitative detection of adulterated olive oil by Raman spectroscopy and chemometrics. Journal of Raman Spectroscopy, 2011. 42 (9): 1784- 1788. doi: 10.1002/jrs.2933
	Zhang Y , Yang L , Zu Y , et al. Oxidative stability of sunflower oil supplemented with carnosic acid compared with synthetic antioxidants during accelerated storage. Food Chemistry, 2010. 118 (3): 656- 662. doi: 10.1016/j.foodchem.2009.05.038

时间 Time/d	脂肪酸相对含量Fatty acid relative content(%)
时间 Time/d	C16:0	C16:1	C18:0	C18:1	C18:2	C18:3	C20:0
0	4.40±0.012a	0.22±0.000a	1.35±0.100b	83.41±0.029a	9.97±0.023f	0.10±0.006cd	0.21±0.000abc
5	4.40±0.017a	0.22±0.006b	1.43±0.100b	83.36±0.081ab	9.87±0.021f	0.10±0.006d	0.21±0.006ab
10	4.41±0.006a	0.23±0.000b	1.42±0.117b	83.47±0.093ab	9.80±0.030ef	0.10±0.010cd	0.20±0.012ab
15	4.41±0.020a	0.22±0.006a	1.37±0.137b	83.68±0.080b	9.67±0.030e	0.09±0.000c	0.20±0.015a
20	4.42±0.015a	0.22±0.006ab	1.46±0.023b	83.70±0.045b	9.47±0.021d	0.10±0.012cd	0.21±0.006bc
25	4.43±0.006a	0.22±0.000a	1.08±0.021a	84.14±0.010c	9.42±0.006d	0.09±0.000cd	0.23±0.000de
30	4.48±0.017b	0.22±0.006ab	1.33±0.249b	84.46±0.229d	8.71±0.065c	0.07±0.006b	0.22±0.006cd
35	4.51±0.025b	0.22±0.000a	1.39±0.231b	84.86±0.221e	8.15±0.289b	0.06±0.006a	0.22±0.006cd
40	4.64±0.065c	0.23±0.010b	1.47±0.110b	85.76±0.326f	7.15±0.101a	0.05±0.006a	0.24±0.000e

	过氧化值 POV	p-茴香胺值 AV	总氧化值 Total oxidation value	共轭二烯值 Conjugated dienes value	不饱和脂肪酸相对含量 UFA relative content	饱和脂肪酸相对含量 SFA relative content	总类胡萝卜素含量 Total carotenoid content	自由基相对含量 Free radical relative content	拉曼相对强度 Raman relative intensity
	过氧化值 POV	p-茴香胺值 AV	总氧化值 Total oxidation value	共轭二烯值 Conjugated dienes value	不饱和脂肪酸相对含量 UFA relative content	饱和脂肪酸相对含量 SFA relative content	总类胡萝卜素含量 Total carotenoid content	自由基相对含量 Free radical relative content	I_{972 cm^-1}/I_{1 441 cm^-1}	I_{1 268 cm^-1}/I_{1 441 cm^-1}	I_{1 158 cm^-1}/I_{1 441 cm^-1}	I_{1 524 cm^-1}/I_{1 441 cm^-1}
过氧化值 POV	1	0.976^**	1.000^**	0.926^**	-0.572^**	0.563^**	-0.831^**	0.980^**	-0.822^**	-0.886^**	-0.903^**	-0.913^**
p-茴香胺值 AV		1	0.977^**	0.895^**	-0.618^**	0.653^**	-0.765^**	0.952^**	-0.894^**	-0.931^**	-0.826^**	-0.840^**
总氧化值 Total oxidation value			1	0.926^**	-0.574^**	0.567^**	-0.830^**	0.980^**	-0.825^**	-0.889^**	-0.901^**	-0.911^**
共轭二烯值 Conjugated dienes				1	-0.583^**	0.510^**	-0.865^**	0.930^**	-0.693^**	-0.761^**	-0.893^**	-0.901^**
不饱和脂肪酸相对含量 UFA relative content					1	-0.797^**	0.526^**	-0.602^**	0.538^**	0.643^**	0.528^**	0.540^**
饱和脂肪酸相对含量 SFA relative content						1	-0.394^*	0.564^**	-0.634^**	-0.722^**	-0.418^*	-0.435^*
总类胡萝卜素含量 Total carotenoid content							1	-0.913^**	0.575^**	0.676^**	0.966^**	0.966^**
自由基相对含量 Free radical relative content								1	-0.776^**	-0.857^**	-0.948^**	-0.957^**
I_{972 cm^-1}/I_{1 441 cm^-1}									1	0.944^**	0.653^**	0.662^**
I_{1 268 cm^-1}/I_{1 441 cm^-1}										1	0.745^**	0.759^**
I_{1 158 cm^-1}/I_{1 441 cm^-1}											1	0.998^**
I_{1 524 cm^-1}/I_{1 441 cm^-1}												1
