宁夏枸杞果实性状和预处理对果实制干的影响

doi:10.11707/j.1001-7488.LYKX20230184

摘要/Abstract

摘要：

目的: 探究不同品种（系）宁夏枸杞果实性状和预处理对果实制干的影响，为枸杞制干工艺提供有价值的理论依据。方法: 以制干差异较大的不同品种（系）宁夏枸杞为试验材料，采用称重法、石蜡切片和扫描电镜等方法，对果实加工性状、果皮及角质层结构、果皮蜡质微形态和不同预处理枸杞果实制干时间进行探究，明确不同品种（系）宁夏枸杞果实性状和预处理对果实制干的影响。结果: 1）不同品种（系）枸杞果实纵径、百粒质量、单果体积存在显著差异，‘16-23-7-8’横径、纵径、百粒质量、单果体积均最高，‘宁杞1号’最低。2）随着果实发育，果皮和角质层厚度逐渐增加且存在显著差异。‘宁杞5号’果皮厚度最大，达768.273 μm；‘宁杞1号’果皮厚度最小，为445.100 μm。‘14-402’角质层最厚，达9.420 μm；‘16-23-7-8’最低，为7.528 μm。3）成熟期枸杞果实表皮被束状蜡质层覆盖，蜡质晶体呈无规则片状，片状蜡质层较厚，排列较紧密。4）不同品种（系）枸杞果实制干时间存在显著差异，由易到难依次为‘宁杞1号’、 ‘Z44’、‘16-23-7-8’、‘14-402’、‘宁杞5号’。与对照相比，碱处理后，平均制干时间缩短4.10 h；氯仿处理后，平均制干时间缩短16.94 h。结论: 枸杞果皮结构通过影响水分运输进而影响枸杞果实制干过程；预处理可破坏枸杞表皮蜡质层缩短制干时间。本研究5个枸杞品种（系）中，‘宁杞5号’不易制干，‘宁杞1号’最易制干，在枸杞制干时，应用的预处理方式必须考虑品种间存在的组织和形态解剖学特征的差异。

关键词: 宁夏枸杞, 果实性状, 果皮结构, 角质层, 表皮蜡质, 预处理, 制干时间

Abstract:

Objective: Drying is an important step of the processing of Chinese medicine wolfberry. The effects of different varieties (lines) of Lycium barbarum fruit traits and pretreatment on drying were studied to provide a valuable theoretical basis for the drying process of L. barbarum. Method: In this study, different varieties (lines) of L. barbarum with obvious differences in dryness were used as experimental materials. The paraffin sectioning and scanning electron microscopy techniques were used to investigate the fruit processing characteristics, peel and cuticle structure, and peel waxy micromorphology, as well as effects of different pretreatment times on the drying of L. barbarum fruits, by which the influence of the L. barbarum fruit traits on the drying of the fruits was clarified. Result: 1) There were significant differences in the longitudinal diameter, fresh weight of 100 grains, and single fruit volume among different varieties (lines). L. barbarum ‘16-23-7-8’ had the largest transverse diameter, longitudinal diameter, fresh weight of 100 grains, and single fruit volume, while those parameters of L. barbarum ‘Ningqi No.1’ were the lowest. 2) With the development of the fruit, the thickness of the pericarp and cuticle increased gradually and there were significant differences in those traits among different varieties (lines). The pericarp thickness of L. barbarum ‘Ningqi No.5’ was the largest with 768.273 μm, and that of L. barbarum ‘Ningqi No.1’ was the lowest with 445.100 μm. L. barbarum ‘14-402’ had the thickest cuticle with 9.420 μm, and the L. barbarum ‘16-23-7-8’ cuticle was the lowest, being 7.528 μm. 3) The epidermis of L. barbarum fruit at mature stage was covered by fascicular waxy layer, and the waxy crystals were irregular flakes, and the flake waxy layer was thicker and arranged closely. 4) There were differences in the drying time of different varieties (lines) of L. barbarum fruits, and the order from easy to difficult was ‘Ningqi No.1’, ‘Z44’, ‘16-23-7-8’, ‘14-402’, and ‘Ningqi No 5’. Compared with the control, the average drying time was shortened by 4.10 h after alkali treatment, and the average drying time was shortened by 16.94 h after chloroform treatment. Conclusion: The structure of L. barbarum peel affects the drying process of the wolfberry fruits by affecting the water transport pathway. Pretreatment can destroy the waxy layer of wolfberry epidermis and shorten the drying time. In this study, ‘Ningqi No.5’ is hard to dry, while ‘Ningqi No.1’ is the easiest to dry. Therefore, when drying wolfberry, the pretreatment method applied must take into account the differences in tissue and morphological anatomical characteristics among varieties.

Key words: Lycium barbarum, fruit traits, peel structure, cuticle, epicuticular waxes, pretreatment, drying time

中图分类号:

赵娟红,米娟娟,李治刚,包晗,黄婷,秦垦,杨涓,郑国琦. 宁夏枸杞果实性状和预处理对果实制干的影响[J]. 林业科学, 2024, 60(3): 35-44.

Juanhong Zhao,Juanjuan Mi,Zhigang Li,Han Bao,Ting Huang,Ken Qin,Juan Yang,Guoqi Zheng. Effects of Lycium barbarum Fruit Characteristics and Pretreatment on the Fruit Drying[J]. Scientia Silvae Sinicae, 2024, 60(3): 35-44.

图/表 8

表1

图1

图2

图3

图4

图5

图6

表2

参考文献 0

	曹　兵, 宋培建, 康建宏, 等. 大气CO₂浓度倍增对宁夏枸杞生长的影响. 林业科学, 2011, 47 (7): 193- 198.
	Cao B, Sun P J, Kang J H, et al. Effect of elevated CO₂ concentration on growth in Lycium barbarum. Scientia Silvae Sinicae, 2011, 47 (7): 193- 198.
	蒋　兰, 杨　毅. 超声对枸杞表皮蜡质的影响. 食品工业, 2018, 39 (12): 201- 203.
	Jiang L, Yang Y. The effect of ultrasound on the wax of the epidermis of wolfberry. The Food Industry, 2018, 39 (12): 201- 203.
	李文丽. 2016. 枸杞脱蜡剂及促干机理研究. 天津: 天津科技大学.
	Li W L. 2016. Experimental study on the dewaxing agent and its drying improvement mechanism of Lycium barbarum. Tianjin: Tianjin University of Science and Technology. ［in Chinese］
	李正理. 植物显微制片技术的发展(下). 植物杂志, 1990, (3): 40- 41.
	Li Z L. Development of plant microfilming techniques (below). Plant Journal, 1990, (3): 40- 41.
	刘玲霞, 刘相东, 常　剑. 等. 果蔬干燥过程的水分跨膜传输模型构建. 农业工程学报, 2012, 28 (20): 256- 264.
	Liu L X, Liu X D, Chang J, et al. Transmission model of moisture transmembrane during fruit and vegetable drying process. Journal of Agricultural Engineering, 2012, 28 (20): 256- 264.
	刘　瑜, 姚思远, 冉国伟, 等. 脱蜡工艺对枸杞热风干燥时间的影响. 食品工业科技, 2015, 36 (24): 211- 215.
	Liu Y, Yao S Y, Ran G W, et al. Influence of dewaxing process on hot air drying effcience of wolfberry. Science and Technology of Food Industry, 2015, 36 (24): 211- 215.
	冉国伟, 张慧媛, 刘　瑜, 等. 智能多段式变温变湿太阳能枸杞烘干设备的设计与试验. 包装与食品机械, 2015, 33 (6): 34- 38. doi: 10.3969/j.issn.1005-1295.2015.06.008
	Ran G W, Zhang H Y, Liu Y, et al. Design and testing of solar dryer for chinese wolfberry using temperature and humidity by stages changed hot-air drying method. Packaging and Food Machinery, 2015, 33 (6): 34- 38. doi: 10.3969/j.issn.1005-1295.2015.06.008
	宋慧慧, 陈芹芹, 毕金峰, 等. 干燥方式及碱液处理对鲜枸杞干燥特性和品质的影响. 食品科学, 2018, 39 (15): 197- 206. doi: 10.7506/spkx1002-6630-201815029
	Song H H, Chen Q Q, Bi J F, et al. Effects of different drying methods and alkali pretreatment on drying characteristics and quality of fresh goji berries (Lycium barbarum). Food Science, 2018, 39 (15): 197- 206. doi: 10.7506/spkx1002-6630-201815029
	王晓雨, 利　通, 常晨光, 等. 2022. 促干护色剂在枸杞干制过程中促干护色机理的研究. 食品与发酵工业, 49(14): 41-49.
	Wang X Y, Li T, Chang C G, et al. 2023. Study on the mechanism of drying promoting and color-protecting agent during the drying process of Lycium barbarum. Food and Fermentation Industry, 49(14): 41- 49. ［in Chinese］
	谢兆森, 杜鸿儒, 项殿芳, 等. 蓝莓果实不同发育期维管束解剖结构与水分运输变化. 植物生理学报, 2018, 54 (1): 45- 53.
	Xie Z S, Du H R, Xiang D F, et al. The changes of anatomical structure of vascular bundles and water transport in blueberry fruit during different growth and development stages. Plant Physiology Communications, 2018, 54 (1): 45- 53.
	徐秀苹, 谷　丹, 冯　旻. 适用于扫描电镜的拟南芥蜡质样品制备方法. 电子显微学报, 2015, 34 (1): 82- 84.
	Xu X P, Gu D, Feng M. Comparison of sample preparation methods for scanning electron microscopy (SEM) of leaf epicuticular waxes in arabidopsis. Journal of Chinese Electron Microscopy Society, 2015, 34 (1): 82- 84.
	姚娜娜, 车凤斌, 张　婷, 等. 不同预处理对提高大果沙棘热风干燥效果的对比分析. 现代食品科技, 2020, 36 (8): 211- 219,22.
	Yao N N, Che F B, Zhang T, et al. Comparative analysis of different pretreatment on improving hot air drying effect of seabuckthorn (Hippophae rhamnoides L.). Modern Food Science & Technology, 2020, 36 (8): 211- 219,22.
	张　静, 丁胜华, 谢秋涛, 等. 温州蜜柑和冰糖橙果实表面角质层组分及微观结构差异分析. 食品科学, 2018, 39 (7): 131- 138.
	Zhang J, Ding S H, Xie Q T, et al. Analysis of cuticle components and microstructure of satsuma mandarin(Citrus unshiu Marc.) and bingtang sweet orange(Citrus sinensis Osbeck). Food Science, 2018, 39 (7): 131- 138.
	赵建华, 述小英, 李浩霞, 等. 不同果色枸杞鲜果品质性状分析及综合评价. 中国农业科学, 2017, 50 (12): 2338- 2348.
	Zhao J H, Shu X Y, Li H X, et al. Analysis and comprehensive evaluation of the quality of wolfberry (Lycium L.) fresh fruits with different fruit colors. Scientia Agricultura Sinica, 2017, 50 (12): 2338- 2348.
	袁惠君, 贾鸿震, 李虎军, 等. 不同品种宁夏枸杞鲜果干制特征分析及评价. 食品与发酵工业, 2018, 44 (6): 200- 204.
	Yuan H J, Jia H Z, Li H J, et al. Comparative analysis of drying process characters of wolfberry (Lycium barbarum L.) fresh fruit in different cultivars. Food and Fermentation Industries, 2018, 44 (6): 200- 204.
	Atkinson R G, Sutherland P W, Johnston S L, et al. Down-regulation of POLYGALACTURONASE1 alters firmness, tensile strength and water loss in apple (Malus × domestica) fruit. BMC Plant Biology, 2012, 12, 1- 13. doi: 10.1186/1471-2229-12-129
	Baomeng Z, Xuesen W, Guodong W. Effect of pre-treatments on drying characteristics of chinese jujube (Zizyphus jujuba Miller). International Journal of Agricultural and Biological Engineering, 2014, 7 (1): 94- 102.
	Barthlott W, Neinhuis C, Cutler D, et al. Classification and terminology of plant epicuticular waxes. Botanical Journal of the Linnean Society, 1998, 126 (3): 237- 260. doi: 10.1111/j.1095-8339.1998.tb02529.x
	Brizzolara S, Minnocci A, Yembaturova E, et al. Ultrastructural analysis of berry skin from four grapes varieties at harvest and in relation to postharvest dehydration. Oeno One, 2020, 54 (4): 1121- 1131.
	Carvajal F, Castro-Cegrí A, Jiménez-Muñoz R, et al. 2021. Changes in morphology, metabolism and composition of cuticular wax in zucchini fruit during postharvest cold storage. Frontiers in Plant Science, 12.778745.
	Chai Y, Li A, Chit Wai S, et al. cuticular wax composition changes of 10 apple cultivars during postharvest storage. Food Chemistry, 2020, 324, 126903. doi: 10.1016/j.foodchem.2020.126903
	Chu W, Gao H, Cao S, et al. Composition and morphology of cuticular wax in blueberry (Vaccinium spp.) fruits. Food Chemistry, 2017, 219, 436- 442. doi: 10.1016/j.foodchem.2016.09.186
	Chu W, Gao H, Chen H, et al. Effects of cuticular wax on the postharvest quality of blueberry fruit. Food Chemistry, 2018, 239, 68- 74. doi: 10.1016/j.foodchem.2017.06.024
	Defraeye T. Impact of size and shape of fresh-cut fruit on the drying time and fruit quality. Journal of Food Engineering, 2017, 210, 35- 41. doi: 10.1016/j.jfoodeng.2017.04.004
	Diarte C, Lai P, Huang H, et al. 2019. Insights into olive fruit surface functions: a comparison of cuticular composition, water permeability, and surface topography in nine cultivars during maturation. Frontiers in Plant Science, 10.478529
	Dı́az-pérez J C. Transpiration rates in eggplant fruit as affected by fruit and calyx size. Postharvest Biology and Technology, 1998, 13 (1): 45- 49. doi: 10.1016/S0925-5214(97)00078-1
	Doymaz İ. Effect of pre-treatments using potassium metabisulphide and alkaline ethyl oleate on the drying kinetics of apricots. Biosystems Engineering, 2004, 89 (3): 281- 287. doi: 10.1016/j.biosystemseng.2004.07.009
	Gorb E V, Kozeretska I A, Gorb S N. Hierachical epicuticular wax coverage on leaves of Deschampsia antarctica as a possible adaptation to severe environmental conditions. Beilstein Journal of Nanotechnology, 2022, 13 (1): 807- 816. doi: 10.3762/bjnano.13.71
	Hansmann C F, Joubert E, Britz T J. 1998. Dehydration of Peaches without Sulphur Dioxide. Drying Technology, 16(1-2), 101−121.
	Isaacson T, Kosma D K, Matas A J, et al. Cutin deficiency in the tomato fruit cuticle consistently affects resistance to microbial infection and biomechanical properties, but not transpirational water loss. The Plant Journal, 2009, 60 (2): 363- 377. doi: 10.1111/j.1365-313X.2009.03969.x
	Jatoi M A, Fruk M, Buhin J, et al. 2018. Effect of different storage temperatures on storage life, physico-chemical and sensory attributes of goji berry (Lycium barbarum L.) fruits. Erwerbs-Obstbau, 60(2): 119-126.
	Kim H, Choi D, Suh M C. Cuticle ultrastructure, cuticular lipid composition, and gene expression in hypoxia-stressed arabidopsis stems and leaves. Plant Cell Reports, 2017, 36 (6): 815- 827. doi: 10.1007/s00299-017-2112-5
	Konishi A, Terabayashi S, Itai A. Relationship of cuticle development with water loss and texture of pepper fruit. Canadian Journal of Plant Science, 2021, 102 (1): 103- 111.
	Liu D, Zeng Q, Ji Q, et al. A comparison of the ultrastructure and composition of fruits cuticular wax from the wild-type ‘Newhall’ Navel Orange (Citrus sinensis [L. ] Osbeck cv. Newhall) and its glossy mutant. Plant Cell Reports, 2012, 31, 2239- 2246. doi: 10.1007/s00299-012-1333-x
	Lufu R, Ambaw A, Opara U L. Water loss of fresh fruit: influencing pre-harvest, harvest and postharvest factors. Scientia Horticulturae, 2020, 272, 109519. doi: 10.1016/j.scienta.2020.109519
	Mothibe K J, Zhang M, Nsor-Atindana J, et al. Use of ultrasound pretreatment in drying of fruits: drying rates, quality attributes, and shelf life extension. Drying Technology, 2011, 29 (14): 1611- 1621. doi: 10.1080/07373937.2011.602576
	Ni J, Ding C, Zhang Y, et al. Impact of different pretreatment methods on drying characteristics and microstructure of goji berry under electrohydrodynamic (EHD) drying process. Innovative Food Science & Emerging Technologies, 2020, 61, 102318.
	Riederer M, Arand K, Burghardt M, et al. Water loss from litchi (Litchi chinensis) and longan (Dimocarpus longan) fruits is biphasic and controlled by a complex pericarpal transpiration barrier. Planta, 2015, 242 (5): 1207- 1219. doi: 10.1007/s00425-015-2360-y
	Ristic Z, Jenks M A. Leaf cuticle and water loss in maize lines differing in dehydration avoidance. Journal of Plant Physiology, 2002, 159 (6): 645- 651. doi: 10.1078/0176-1617-0743
	Rosati A, Zipanćič M, Caporali S, et al. Fruit weight is related to ovary weight in olive (Olea europaea). Scientia Horticulturae, 2009, 122 (3): 399- 403. doi: 10.1016/j.scienta.2009.05.034
	Tan S, Xu Y, Zhu L, et al. Hot air drying of Seabuckthorn (Hippophae rhamnoides ) berries: effects of different pretreatment methods on drying characteristics and quality attributes. Foods, 2022, 11 (22): 3675. doi: 10.3390/foods11223675
	Theron J A. 2015. Moisture loss studies in Japanese plums (Prunus salicina Lindl. ). Stellenbosch: Stellenbosch University.
	Wang J, Cui Q, Li H, et al. Mechanical properties and microstructure of apple peels during storage. International Journal of Food Properties, 2017, 20 (5): 1159- 1173. doi: 10.1080/10942912.2016.1203934
	Wang J, Haohao H, Runsheng L, et al. Comparative analysis of surface wax in mature fruits between satsuma mandarin (Citrus unshiu) and ‘newhall’ navel orange (Citrus sinensis) from the perspective of crystal morphology, Chemical Composition and Key Gene Expression. Food Chemistry, 2014, 153, 177- 185. doi: 10.1016/j.foodchem.2013.12.021
	Wang P, Wang J, Zhang H, et al. Chemical composition, crystal morphology, and key gene expression of the cuticular waxes of Goji (Lycium barbarum L.) berries. Journal of Agricultural and Food Chemistry, 2021a, 69 (28): 7874- 7883. doi: 10.1021/acs.jafc.1c02009
	Wang Y, Mao H, Lv Y, et al. Comparative analysis of total wax content, chemical composition and crystal morphology of cuticular wax in korla pear under different relative humidity of storage. Food Chemistry, 2021b, 339, 128097. doi: 10.1016/j.foodchem.2020.128097
	Wu X, Yin H, Shi Z, et al. 2018. Chemical composition and crystal morphology of epicuticular wax in mature fruits of 35 pear (Pyrus spp.) cultivars. Frontiers in Plant Science, 9, 347625.
	Yan Y, Castellarin S D. Blueberry water loss is related to both cuticular wax composition and stem scar size. Postharvest Biology and Technology, 2022, 188, 111907. doi: 10.1016/j.postharvbio.2022.111907
	Yang M, Ding C. 2016. Electrohydrodynamic (EHD) drying of the Chinese wolfberry fruits. SpringerPlus, 5, 1−20.
	Yilbas B S, Hussain M, Dincer I. Heat and moisture diffusion in slab products to convective boundary condition. Heat and Mass Rransfer, 2003, 39 (5): 471- 476. doi: 10.1007/s00231-002-0323-x
	Zhao D, Wei J, Hao J, et al. Effect of sodium carbonate solution pretreatment on drying kinetics, antioxidant capacity changes, and final quality of wolfberry (Lycium barbarum) during drying. Lwt, 2019, 99, 254- 261. doi: 10.1016/j.lwt.2018.09.066

品种 Varieties	横径 Transverse diameter/cm	纵径 Longitudinal diameter/cm	百粒质量 Hundred-grain weight/g	体积 Volume/cm³
‘Ningqi No. 1’	0.741±0.004a	1.469±0.013c	52.176±1.109d	0.229±0.024b
‘Ningqi No. 5’	0.806±0.031a	1.641±0.039bc	75.382±0.885c	0.246±0.007b
‘Z44’	0.836±0.028a	1.893±0.119ab	91.757±1.111b	0.298±0.014b
‘16-23-7-8’	0.841±0.033a	2.100±0.023a	99.161±2.160a	0.383±0.023a
‘14-402’	0.784±0.028a	1.961±0.165ab	74.305±3.311c	0.306±0.036ab

	制干时间 Drying time	横径 Transverse diameter	纵径 Longitudinal diameter	百粒质量 Hundred-grain weight	体积 Volume	角质层厚度 Cuticle thivkness	果皮厚度 Pericarp thicknesss
制干时间 Drying time	1
横径 Transverse diameter	?0.021	1
纵径 Longitudinal diameter	?0.302	0.724^**	1
百粒质量 Hundred-grain weight	?0.054	0.629^*	0.704^**	1
体积 Volume	?0.206	0.250	0.528^*	0.754^**	1
角质层厚度 Cuticle thivkness	0.358	?0.339	?0.400	?0.577^*	?0.604^*	1
果皮厚度 Pericarp thicknesss	0.674^**	0.309	?0.025	0.276	?0.174	0.285	1
