林业科学 ›› 2021, Vol. 57 ›› Issue (7): 121-130.doi: 10.11707/j.1001-7488.20210713
宁吉彬,耿道通,于宏洲,邸雪颖,杨光*
收稿日期:
2019-11-07
出版日期:
2021-07-25
发布日期:
2021-09-02
通讯作者:
杨光
基金资助:
Jibin Ning,Daotong Geng,Hongzhou Yu,Xueying Di,Guang Yang*
Received:
2019-11-07
Online:
2021-07-25
Published:
2021-09-02
Contact:
Guang Yang
摘要:
目的: 基于室内模拟的飞火引燃试验数据,使用Logistic模型对影响飞火引燃的因子进行建模,探究该模型在预测飞火引燃中的适用性,为林火行为研究提供依据和参考。方法: 选取黑龙江大兴安岭兴安落叶松纯林为对象,以球果、1 h时滞、10 h时滞小枝为火源,构造不同风速、可燃物含水率和压缩比的可燃物床层,进行引燃试验,建立以Logistic模型为基础的3种火源的引燃概率模型。结果: 3种类型火源分别进行了1 800次点烧试验,球果、1 h时滞和10 h时滞小枝引燃次数分别为414、161和337次;本研究梯度范围内,火源引燃概率随着风速增加而显著增加;可燃物含水率与引燃概率负相关,但受火源的干质量影响较大,在可燃物含水率为40%时,较大的3种火源干质量造成了引燃率升高;床层压缩比对火源引燃概率并没有表现出明显的正或负相关性;构建的球果模型预测引燃准确率为87.2%,总预测准确率为71.1%;1 h时滞小枝模型预测引燃准确率为79.6%,总预测准确率为78.6%;10 h时滞小枝模型预测引燃准确率为81.5%,总预测准确率为79.5%。结论: 3种火源引燃能力为球果>10 h时滞小枝>1 h时滞小枝,风速、可燃物含水率和火源干质量对引燃有较大作用,建立的3种Logistic引燃概率模型有较高准确率,可供飞火引燃预测时参考,以提高森林火灾扑救效率和减少扑救伤亡。
中图分类号:
宁吉彬,耿道通,于宏洲,邸雪颖,杨光. 基于Logistic回归的兴安落叶松林飞火引燃试验[J]. 林业科学, 2021, 57(7): 121-130.
Jibin Ning,Daotong Geng,Hongzhou Yu,Xueying Di,Guang Yang. Experiment on Spotting Ignition of Larix gmelinii Forest Based on Logistic Regression[J]. Scientia Silvae Sinicae, 2021, 57(7): 121-130.
表1
试验材料基本特征及燃烧特性"
试验材料 Experimental materials | 长度 Length (cm·ind-1) | 直径 Diameter (cm·ind-1) | 干质量 Dry mass (g· ind-1) | 含水率 Moisture content(%) | 灰分 Ash(%) | 抽提物 Extract(%) |
球果Cone | 1.955 | 2.052 | 0.566 | 7.254 | 0.025 | 0.083 |
1 h时滞小枝1 h time-lag twig | 5 | 0.428 | 0.436 | 5.649 | 0.100 | 3.667 |
10 h时滞小枝10 h time-lag twig | 5 | 0.956 | 0.342 | 2.654 | 0.130 | 2.500 |
可燃物床层Fuel bed | — | — | 42.4 | 29.591 | 0.031 | 3.000 |
表2
3种火源模型多重共线性诊断(VIF值)"
变量 Variables | 球果模型 Cone model | 1 h时滞小枝模型 1 h time-lag twig model | 10 h时滞小枝模型 10 h time-lag twig model |
温度Temperature | 1.256 | 1.153 | 1.848 |
相对湿度 Relative humidity | 1.265 | 2.518 | 2.167 |
风速Wind speed | 1.141 | 1.046 | 1.035 |
火源干质量 Firebrand ovendry mass | 3.571 | 3.986 | 5.495 |
火源含水率 Firebrand moisture content | 1.145 | 1.192 | 1.159 |
火源直径 Firebrand diameter | 1.572 | 3.818 | 5.285 |
火源长度 Firebrand length | 2.960 | — | — |
可燃物含水率 Fuel moisture content | 1.109 | 1.096 | 1.114 |
压缩比Packing ratio | 1.103 | 2.508 | 1.327 |
表3
Logistic模型变量在中间样本中的显著性次数"
变量 Variables | 球果模型 Cone model | 1 h时滞小枝模型 1 h time-lag twig model | 10 h时滞小枝模型 10 h time-lag twig model |
温度Temperature | 2 | 2 | 0 |
相对湿度 Relative humidity | 2 | 1 | 0 |
风速Wind speed | 5 | 5 | 5 |
火源干质量 Firebrand ovendry mass | 3 | 5 | 0 |
火源含水率 Firebrand moisture content | 0 | 1 | 5 |
火源直径 Firebrand diameter | 2 | 1 | 1 |
火源长度 Firebrand length | 2 | — | — |
压缩比 Packing ratio | 1 | 3 | 0 |
可燃物含水率 Fuel moisture content | 5 | 5 | 5 |
表4
基于建模样本的Logistic模型参数拟合"
火源类型Firebrand type | 变量Variables | 系数Coefficient | 标准误SE | 显著性Sig |
球果模型 Cone model | 风速Wind speed | 1.078 | 0.083 | 0.000 |
火源干质量Firebrand ovendry weight | 2.377 | 0.397 | 0.000 | |
可燃物含水率Fuel moisture content | -3.778 | 0.579 | 0.000 | |
常量Constant | -4.552 | 0.410 | 0.000 | |
1 h时滞小枝模型 1 h time-lag twig model | 风速Wind speed | 1.240 | 0.135 | 0.000 |
火源干质量Firebrand ovendry weight | 3.396 | 0.560 | 0.000 | |
可燃物含水率Fuel moisture content | -2.850 | 0.849 | 0.001 | |
压缩比Packing ratio | -28.679 | 9.912 | 0.004 | |
常量Constant | -4.684 | 0.887 | 0.000 | |
10 h时滞小枝模型 10 h time-lag twig model | 风速Wind speed | 1.575 | 0.119 | 0.000 |
可燃物含水率Fuel moisture content | -2.427 | 0.645 | 0.000 | |
火源含水率Firebrand moisture content | 11.495 | 4.164 | 0.006 | |
常量Constant | -5.919 | 0.466 | 0.000 |
表5
Logistic模型预测准确率"
火源类型 Firebrand type | 样本类型 Sample type | 预测引燃准确率 Prediction accuracy of ignition | 预测未燃准确率 Prediction accuracy of unignited | 总预测准确率 Total prediction accuracy |
球果模型 Cone model | 建模样本Modeling sample | 87.2 | 65.9 | 71.1 |
验证样本Validating sample | 81.8 | 65.3 | 69.3 | |
1 h时滞小枝模型 1 h time-lag twig mode | 建模样本Modeling sample | 79.6 | 78.5 | 78.6 |
验证样本Validating sample | 75.5 | 81.7 | 81.2 | |
10 h时滞小枝模型 10 h time-lag twig mode | 建模样本Modeling sample | 81.5 | 79.0 | 79.5 |
验证样本Validating sample | 82.1 | 77.6 | 78.7 |
金森, 张运林, 朱凯月, 等. 烟头点燃蒙古栎落叶床层的概率. 东北林业大学学报, 2014, 42 (8): 75- 78.
doi: 10.3969/j.issn.1000-5382.2014.08.016 |
|
Jin S , Zhang Y L , Zhu K Y , et al. Burning probability of fuelbed composed of Mongolian Oak leaf ignited by cigarette ends. Journal of Northeast Forestry University, 2014, 42 (8): 75- 78.
doi: 10.3969/j.issn.1000-5382.2014.08.016 |
|
梁慧玲, 林玉蕊, 杨光, 等. 基于气象因子的随机森林算法在塔河地区林火预测中的应用. 林业科学, 2016, 52 (1): 89- 98.
doi: 10.3969/j.issn.1006-1126.2016.01.017 |
|
Liang H L , Lin Y R , Yang G , et al. Application of random forest algorithm on the forest fire prediction in Tahe area based on meteorolo gical factors. Scientia Silvae Sinicae, 2016, 52 (1): 89- 98.
doi: 10.3969/j.issn.1006-1126.2016.01.017 |
|
林其钊, 朱霁平, 张慧波. 森林大火中飞火行为的研究. 自然灾害学报, 1998, 7 (3): 33- 39. | |
Lin Q Z , Zhu J P , Zhang H B . Investigation on the spotting fire during a large forest fire. Journal of Natural Disasters, 1998, 7 (3): 33- 39. | |
刘欣. 2017. 肝胆手术手术部位感染风险预测模型的构建. 石河子: 石河子大学硕士学位论文. | |
Liu X. 2017. Construction of risk prediction model of surgical site infection after liver and gallbladder surgery. Shihezi: MS thesis of Shihezi University. [in Chinese] | |
楼玉海, 焦擎芳. 1990. 五·六特大森林火灾的调查与分析. 哈尔滨: 黑龙江科学技术出版社. | |
Lou Y H, Jiao Q F. 1990. Investigation and analysis of "5·6" particularly serious forest fires. Harbin: Heilongjiang Science & Technology Press. [in Chinese] | |
宁吉彬, 瓮岳太, 邸雪颖, 等. 大兴安岭沟塘草甸地表可燃物载量快速测定方法. 东北林业大学学报, 2018, 46 (5): 44- 48. | |
Ning J B , Weng Y T , Di X Y , et al. Rapid determination method for swamp meadow surface fuel loads of Daxing'an mountains. Journal of Northeast Forestry University, 2018, 42 (8): 75- 78. | |
牛树奎. 2012. 北京山区主要森林类型火行为与可燃物空间连续性研究. 北京: 北京林业大学博士学位论文. | |
Niu S K. 2012. Fire behavior and fuel spatial continuity of major forest types in the mountainous area, Beijing. Beijing: PhD thesis of Beijing Forestry University. [in Chinese] | |
彭志红. 2019. 飞火和热辐射点燃松针的实验及数值模拟研究. 合肥: 中国科学技术大学硕士学位论文. | |
Peng Z H. 2019. Experimental and numerical study on the ignition of pine needles by firebrands and thermal radiation. Hefei: MS thesis of University of Science and Technology of China. [in Chinese] | |
王苏盼. 2016. 飞火颗粒点燃的实验及机理研究. 合肥: 中国科学技术大学博士学位论文. | |
Wang S P. 2016. Experimental and theoretical study on spotting ignition. Hefei: PhD thesis of University of Science and Technology of China. [in Chinese] | |
王新, 陈海翔, 刘乃安, 等. 火旋风环境中飞火颗粒的上升行为研究. 安全与环境学报, 2011, 11 (6): 177- 180.
doi: 10.3969/j.issn.1009-6094.2011.06.041 |
|
Wang X , Chen H X , Liu N A , et al. Study on rising behavior of firebrand in fire whirlwind. Journal of Safety and Environment, 2011, 11 (6): 177- 180.
doi: 10.3969/j.issn.1009-6094.2011.06.041 |
|
杨光, 袁思博, 舒立福, 等. 森林火灾中高能量火——飞火研究进展. 世界林业研究, 2020, 33 (1): 20- 25. | |
Yang G , Yuan S B , Shu L F , et al. High-energy fire of foest fire-research progress of spotting fire. World Forestry Research, 2020, 33 (1): 20- 25. | |
张运林, 宋红, 胡海清. 无风条件下蒙古栎-红松混交林下地表可燃物3种火源点燃的能力分析. 中南林业科技大学学报, 2018, 38 (12): 96- 102, 114. | |
Zhang Y L , Song H , Hu H Q . Analysis of the ignition ability of three kinds of fire sources under the condition of the mixed forests of Quercus mongolica and Pinus koraiensis under no-wind conditions. Journal of Central South University of Forestry and Technology, 2018, 38 (12): 96- 102, 114. | |
张运林, 张恒, 金森. 基于Logistic回归的烟头点燃红松松针概率研究. 中南林业科技大学学报, 2015, 35 (9): 45- 51. | |
Zhang Y L , Zhang H , Jin S . Study on probability of Pinus koraiensis needles fire lighted by burning cigarette end based on Logistic regression. Journal of Central South University of Forestry and Technology, 2015, 35 (9): 45- 51. | |
中国森林草原防火网. 内蒙古大兴安岭毕拉河发生森林火灾: 国务院赴火场工作组指导扑救, 国家森林防火指挥部紧急调拨扑火物资和力量. (2017-05-03). [2019-09-25]. http://slcyfh.mem.gov.cn/Item/24453.aspx. | |
Forest Grassland Fire Prevention of China. Forest fire in Bila River, Daxinganling, Inner Mongolia: Working group of the State Council arrive fire site to guide fire fighting, National Forest Fire Prevention Headquarters allocate supplies and firefighters of suppression. (2017-05-03). [2019-09-25]. http://slcyfh.mem.gov.cn/Item/24453.aspx. [in Chinese] | |
中国新闻网. 山西沁源火场突发飞火: 火焰高达60余米形成新火线. (2019-03-31)a. [2019-09-25]. http://www.chinanews.com/shipin/cns-d/2019/03-31/news809844.shtml. | |
Chinanews. Spotting fire occured in Qinyuan, Shanxi: Flame height was up to 60 m and created new burning lines. (2019-03-31). [2019-09-25]. http://www.chinanews.com/shipin/cns-d/2019/03-31/news809844.shtml. [in Chinese]). | |
中国新闻网. 四川凉山木里火场出现复燃. (2019-04-07)b. [2019-09-25]. http://www.chinanews.com/sh/2019/04-07/8802269.shtml | |
Chinanews. Reburning occured in Muli, Sichuan. (2019-04-07). [2019-09-25]. http://www.chinanews.com/sh/2019/04-07/8802269.shtml. [in Chinese]). | |
Chuvieco E , González I , Verdú F , et al. Prediction of fire occurrence from live fuel moisture content measurements in a Mediterranean ecosystem. International Journal of Wildland Fire, 2009, 18 (4): 430- 441.
doi: 10.1071/WF08020 |
|
Ganteaume A , Lampinmaillet C , Guijarro M , et al. Spotting fires: fuel bed flammability and capability of firebrands to ignite fuel beds. International Journal of Wildland Fire, 2009, 18 (8): 951- 969.
doi: 10.1071/WF07111 |
|
Guo F T , Zhang L J , Jin S , et al. Modeling anthropogenic fire occurrence in the boreal forest of China using logistic regression and random forests. Forests, 2016, 7 (12): 250.
doi: 10.3390/f7110250 |
|
Manzello S L , Cleary T G , Shields J R , et al. Ignition of mulch and grasses by firebrands in wildland-urban interface fires. International Journal of Wildland Fire, 2006, 15 (3): 427- 431.
doi: 10.1071/WF06031 |
|
Manzello S L , Cleary T G , Shields J R , et al. Experimental investigation of firebrands: Generation and ignition of fuel beds. Fire Safety Journal, 2008, 43 (3): 226- 233.
doi: 10.1016/j.firesaf.2006.06.010 |
|
Manzello S L , Maranghidesa A , Mella W E . Firebrand generation from burning vegetation. International Journal of Wildland Fire, 2007, 16 (4): 458- 462.
doi: 10.1071/WF06079 |
|
Manzello S L , Maranghides A , Shields J R , et al. Mass and size distribution of firebrands generated from burning Korean pine(Pinus koraiensis) trees. Fire & Materials, 2010, 33 (1): 21- 31. | |
Manzello S L , Park S H , Cleary T G . Investigation on the ability of glowing firebrands deposited within crevices to ignite common building materials. Fire Safety Journal, 2009, 44 (6): 894- 900. | |
Manzello S L , Suzuki S , Gollner M J , et al. Role of firebrand combustion in large outdoor fire spread. Progress in Energy and Combustion Science, 2020, 76, 100801. | |
Matvienko O V , Kasymov D P , Filkov A I , et al. Simulation of fuel bed ignition by wildland firebrands. International Journal of Wildland Fire, 2018, 27 (8): 550- 561. | |
Oliveira S , Oehler F , San-Miguel-Ayanz J , et al. Modeling spatial patterns of fire occurrence in Mediterranean Europe using Multiple Regression and Random Forest. Forest Ecology & Management, 2012, 275 (4): 117- 129. | |
Sun P , Zhang Y , Sun L , et al. Influence of fuel moisture content, packing ratio and wind velocity on the ignition probability of fuel beds composed of Mongolian Oak leaves via cigarette butts. Forests, 2018, 9 (9): 507. | |
Suzuki S , Manzello S L , Kagiya K , et al. Ignition of mulch beds exposed to continuous wind-driven firebrand showers. Fire Technology, 2015, 51 (4): 905- 922.
doi: 10.1007/s10694-014-0425-2 |
|
Urban J L , Zak C D , Song J , et al. Smoldering spotting ignition of natural fuels by a hot metal particle. Proceedings of the Combustion Institute, 2017, 36 (2): 3211- 3218. | |
Urban J L , Zak C D , Fernandez-Pello C . Spot fire ignition of natural fuels by hot aluminum particles. Fire Technology, 2018, 54 (3): 797- 808. | |
Viegas D X , Almeida M , Raposo J , et al. Ignition of Mediterranean fuel beds by several types of firebrands. Fire Technology, 2012, 50 (1): 61- 77.
doi: 10.1007/s10694-012-0267-8 |
|
Yin P , Liu N , Chen H , et al. New correlation between ignition time and moisture content for pine needles attacked by firebrands. Fire Technology, 2012, 50 (1): 79- 91.
doi: 10.1007/s10694-012-0272-y |
