基于元胞自动机模型的松材线虫病小班尺度预测

doi:10.11707/j.1001-7488.LYKX20240521

摘要/Abstract

摘要：

目的: 为探究影响松材线虫病传播扩散的主要影响因素，结合自然气候、人类活动以及地理空间特征多源数据，围绕松材线虫病“传入-定殖-扩散”的生态入侵过程，构建适用于更小空间尺度数据的传播预测模型，实现对松材线虫病高风险发生地区的精准预测和早期预警。方法: 基于国家林业和草原局公布的江苏省松材线虫病小班本底发生数据，结合松材线虫病的生态特性和地理空间分布规律，选取包含自然气候、人类活动因素以及空间特征等25项影响因子数据，采用主成分分析方法进行数据预处理，通过Spearman相关性分析方法和Apriori数据挖掘算法，探究各影响因子与松材线虫病发生之间的相互作用关系。结合贝叶斯估计方法对影响因子数据进行特征增强，建立灰狼优化算法-元胞自动机模型模拟松材线虫病的传播扩散过程，同时与其他5种主流机器学习模型预测结果进行横向对比验证，通过计算其精确率、召回率和AUC等评价指标对模型性能进行验证。结果: 构建的灰狼优化算法-元胞自动机模型在松材线虫病新发小班预测中表现出优异的性能，模型召回率达到78.5%，显著优于其他5种主流机器学习模型；同时，其AUC值达到89.0%，表明模型在识别新发疫情点位的同时，兼顾较高的整体预测准确性与判别能力。本研究进一步证实地理空间特征在松材线虫病传播预测中的重要性，并验证元胞自动机模型在处理复杂时空数据和更精细尺度空间数据预测方面的高度适用性。结论: 木材运输是驱动松材线虫病传播扩散的关键因素，而温度与降水的差异也在显著程度上影响其发生风险。作为一种融合空间异质性与时间动态特征的建模方法，元胞自动机模型在处理复杂生态数据与入侵物种风险评估方面展现出较高的适用性与灵活性，可为松材线虫病的精准防控与高效管理提供有力的技术支撑。

关键词: 松材线虫病, 传播预测模型, 大数据, 数据挖掘, 元胞自动机

Abstract:

Objective: In this study, multi-source data comprising natural climate variables, anthropogenic activity indicators, and geospatial features is used to analyze the key factors influencing the spread and expansion of pine wilt disease (PWD). Focusing on the ecological invasion process of PWD of ‘introduction-colonization-expansion’, a predictive model applicable at a fine spatial scale is constructed, aiming to achieve precise identification and early warning of high-risk outbreak areas of pine wilt disease. Method: This study utilized subcompartment-level outbreak records of PWD in Jiangsu Province published by the National Forestry and Grassland Administration of China. Based on the ecological characteristics and spatial distribution patterns of PWD, a total of 25 influencing variables were selected, covering natural climate conditions, human activity, and spatial features. Principal Component Analysis (PCA) was used for dimensionality reduction, and Spearman correlation analysis and the Apriori data mining algorithm were applied to examine the interactions between each influencing factor and the occurrence of PWD. Bayesian estimation was employed to enhance the feature of the variables. A Grey Wolf Optimizer-Cellular Automata (GWO-CA) model was constructed to simulate the spatiotemporal spread of PWD. The model’s predictive performance was further evaluated through horizontal comparison with five mainstream machine learning models, with precision, recall, and AUC as evaluation metrics. Result: The Grey Wolf Optimizer-Cellular Automata model developed in this study exhibited excellent performance in predicting the new occurrence of pine wilt disease in subcompartment. The model achieved a recall rate of 78.5%, and significantly outperformed the other five mainstream machine learning models. Additionally, the model yielded an AUC value of 89.0%, indicating a high level of predictive accuracy and discriminative ability in identifying new outbreak locations. This study also underscored the critical role of geospatial features in forecasting the spread of pine wilt disease, and confirmed the strong suitability of cellular automata for modeling complex spatiotemporal data, especially at fine spatial scales. Conclusion: This study has identified timber transportation as a key driver of the spread of pine wood nematode, and temperature and precipitation differences also exert significant influence on outbreak risk. As a modeling approach that integrates spatial heterogeneity and temporal dynamics, the Cellular Automata model has proven to be highly adaptable and effective for complex ecological data analysis and invasive species risk assessment. It offers robust technical support for the precise prevention and efficient management of pine wilt disease.

Key words: pine wilt disease, spread prediction model, big data, cellular automata, data mining

中图分类号:

S763.18

周宏威,李永正,郭文辉,陈怡帆,胡浩昌,张思岩,崔迪,陈雨茉. 基于元胞自动机模型的松材线虫病小班尺度预测[J]. 林业科学, 2026, 62(1): 133-143.

Hongwei Zhou,Yongzheng Li,Wenhui Guo,Yifan Chen,Haochang Hu,Siyan Zhang,Di Cui,Yumo Chen. Prediction of Subcompartment-Scale Spread of Pine Wilt Disease Based on Cellular Automata Model[J]. Scientia Silvae Sinicae, 2026, 62(1): 133-143.

图/表 8

表1

图1

图2

表2

表3

图3

图4

表4

参考文献 0

	陈崇成, 李建微, 唐丽玉, 等. 林火蔓延的计算机模拟与可视化研究进展. 林业科学, 2005, 41 (5): 155- 162.
	Chen C C, Li J W, Tang L Y, et al. Research advance in simulation and visualization of forest fire spreading via computer. Scientia Silvae Sinicae, 2005, 41 (5): 155- 162.
	程　功, 吕　全, 冯益明, 等. 气候变化背景下松材线虫在中国分布的时空变化预测. 林业科学, 2015, 51 (6): 119- 126.
	Cheng G, Lv Q, Feng Y M, et al. Temporal and spatial dynamic pattern of pine wilt disease distribution in China predicted under climate change scenario. Scientia Silvae Sinicae, 2015, 51 (6): 119- 126.
	丁晓磊, 汪青桐, 林司曦, 等. 广东省与江苏省松材线虫种群遗传结构差异分析. 林业科学, 2022, 58 (8): 1- 9.
	Ding Y L, Wang Q T, Lin S X, et al. Analysis of genetic variations of Bursaphelenchus xylophilus populations between Guangdong and Jiangsu provinces with SNP marker. Scientia Silvae Sinicae, 2022, 58 (8): 1- 9.
	郭彦龙, 赵泽芳, 乔慧捷, 等. 物种分布模型面临的挑战与发展趋势. 地球科学进展, 2020, 35 (12): 1292- 1305.
	Guo Y L, Zhao Z F, Qiao H J, et al. Challenges and development trend of species distribution model. Advances in Earth Science, 2020, 35 (12): 1292- 1305.
	韩阳阳, 王　焱, 项　杨, 等. 基于Maxent生态位模型的松材线虫在中国的适生区预测分析. 南京林业大学学报(自然科学版), 2015, 39 (01): 6- 10.
	Han Y Y, Wang Y, Xiang Y, et al. Prediction of potential distribution of Bursaphelenchus xylophilus in China based on Maxent ecological niche model. Journal of Nanjing Forestry University (Natural Science Edition), 2015, 39 (01): 6- 10.
	洪承昊, 陈京元, 赵　勇, 等. 三峡库区松材线虫病扩张速度对人为活动的响应. 生态学报, 2017, 37 (20): 6800- 6808.
	Hong C H, Chen J Y, Zhao Y, et al. A correlation of pine wood nematode dispersal rate with human activities-a case study in the Three Gorges Reservoir Area. Acta Ecologica Sinica, 2017, 37 (20): 6800- 6808.
	巨云为, 李明阳, 吴文浩. 江苏省松材线虫发生的预测方法. 林业科学, 2010, 46 (12): 91- 96.
	Ju Y W, Li M Y, Wu W H. Predictive methods of pine wilt disease in Jiangsu Province. Scientia Silvae Sinicae, 2010, 46 (12): 91- 96.
	焦强英, 韩宗甫, 王炜烨, 等. 基于多源数据和机器学习方法的大兴安岭地区雷击火驱动因子及火险预测模型. 林业科学, 2023, 59 (6): 74- 87.
	Jiao Q Y, Han Z P, Wang W Y, et al. Driving factors and forecasting model of lightning-caused forest fires in daxing’ anling mountains based on multi-sources data and machine learning method. Scientia Silvae Sinicae, 2023, 59 (6): 74- 87.
	刘婷婷, 杨晋帆, 周汝良, 等. 基于地理栅格变量与机器学习的松材线虫病扩散风险分析. 浙江农林大学学报, 2023, 40 (3): 617- 626.
	Liu T T, Yang J F, Zhou R L, et al. Prediction of spread risk of pine wilt disease based on geographic raster variables and machine learning models. Journal of Zhejiang A& F University, 2023, 40 (3): 617- 626.
	刘晓梅, 蒲永兰, 李宏群, 等. 基于MaxEnt模型的重庆松材线虫病潜在生境分析. 三峡生态环境监测, 2017, 2 (3): 75- 80.
	Liu X M, Pu Y L, Li H Q, et al. Potential habitat analysis of pine wilt disease in Chongqing based on the MaxEnt model. Ecology and Environmental Monitoring of Three Gorges, 2017, 2 (3): 75- 80.
	田　静, 邢艳秋, 姚松涛, 等. 基于元胞自动机和BP神经网络算法的Landsat-TM遥感影像森林类型分类比较. 林业科学, 2017, 53 (2): 26- 34.
	Tian J, Xing Y Q, Yao S T, et al. Comparison of Landsat-TM image forest type classification based on cellular automata and BP neural network algorithm. Scientia Silvae Sinicae, 2017, 53 (2): 26- 34.
	田相林, 廖梓延, 孙帅超, 等. 多源数据对林分动态预测的影响及不确定性分析. 林业科学, 2021, 57 (3): 51- 66.
	Tian X L, Liao Z Y, Sun S C, et al. Impacts of multiple source data on forest forecasting and uncertainty propagatio. Scientia Silvae Sinicae, 2021, 57 (3): 51- 66.
	王冬至, 张冬燕, 李永宁, 等. 基于贝叶斯法的针阔混交林树高与胸径混合效应模型. 林业科学, 2019, 55 (11): 85- 94.
	Wang D Z, Zhang D Y, Li Y N, et al. Height-diameter relationship for conifer mixed forest based on bayesian nonlinear mixed-effects model. Scientia Silvae Sinicae, 2019, 55 (11): 85- 94.
	王曦茁, 曹业凡, 汪来发, 等. 松材线虫病发生及防控现状. 环境昆虫学报, 2018, 40 (2): 256- 267.
	Wang Z X, Cao Y F, Wang L F, et al. Current status of pine wilt disease and its control status. Journal of Environmental Entomology, 2018, 40 (2): 256- 267.
	项移娟, 管剑锋, 李　健, 等. 浙江省松材线虫病发生程度预测预报模型. 浙江农林大学学报, 2011, 28 (5): 775- 778.
	Xiang Y J, Guan J F, Li J, et al. A pine wilt disease forecasting model for Zhejiang Province. Journal of Zhejiang A & F University, 2011, 28 (5): 775- 778.
	许格希, 余荣兵, 杨昌旭, 等. 基于GIS空间技术和MaxEnt模型预测川西松材线虫病入侵风险. 北京林业大学学报, 2023, 45 (09): 104- 115.
	Xu G X, Yu R B, Yang C X, et al. Prediction of invasion risk of pine wilt disease based on GIS spatial technology and MaxEnt model in western Sichuan province of southwestern China. Journal of Beijing Forestry University, 2023, 45 (09): 104- 115.
	应晨希, 吴小芹, 温彤玥, 等. 不同致病力松材线虫和拟松材线虫种群繁殖对温度的响应. 环境昆虫学报, 2023, 45 (2): 433- 441.
	Ying C X, Wu X Q, Wen T Y, et al. Population reproduction of Bursaphelenchus xylophilus and Bursaphelenchus mucronatus with different virulence response to temperature. Journal of Environmental Entomology, 2023, 45 (2): 433- 441.
	叶建仁. 松材线虫病在中国的流行现状、防治技术与对策分析. 林业科学, 2019, 55 (9): 1- 10.
	Ye J R. The current situation, control techniques, and countermeasures of pine wilt disease in China. Scientia Silvae Sinicae, 2019, 55 (9): 1- 10.
	张晓芳, 郭旭展, 洪　亮, 等. 冬奥核心区华北落叶松和白桦单木冠幅预测模型——组级贝叶斯模型、加性模型和混合效应模型比较. 林业科学, 2022, 58 (10): 89- 100.
	Zhang X F, Guo X Z, Hong L, et al. Comparison of single tree crown prediction models of Larix principis-rupprechtii and Betula platyphylla in the core area of the Winter Olympics in China. Scientia Silvae Sinicae, 2022, 58 (10): 89- 100.
	张志诚, 刘　鹏, 孙江华, 等. 松树萎蔫病在安徽的侵染及其发生的气候分布研究. 宁夏大学学报(自然科学版), 2006, 27 (1): 89- 92.
	Zhang Z C, Liu P, Shun J H, et al. GIS method on the spatial-climate distributed characteristic of pine wilt disease in Anhui Province. Journal of Ningxia University(Natural Science Edition), 2006, 27 (1): 89- 92.
	郑雅楠, 刘佩旋, 时　勇, 等. 辽宁松材线虫病与中国其他疫区的差异性分析. 北京林业大学学报, 2021, 43 (5): 155- 160.
	Zheng Y N, Liu P X, Shi Y, et al. Difference analysis on pine wilt disease between Liaoning province of northeastern China and other epidemic areas in China. Journal of Beijing Forestry University, 2021, 43 (5): 155- 160.
	赵　理. 2024. 从典型案件谈松材线虫病疫木管理. 中国森林病虫, 43(3):42−45.
	Zhao L. 2024. Discussing the management of pine wood nematode-infected wood through typical case studies. Forest Pest and Disease, 43(3):42−45.［in Chinese］
	Aburas M M, Ho Y M, Ramli M F, et al. The simulation and prediction of spatio-temporal urban growth trends using cellular automata models: A review. International Journal of Applied Earth Observation and Geoinformation, 2016, 52, 380- 389. doi: 10.1016/j.jag.2016.07.007
	Barik M, Hafidi I, Rochd Y. 2023. Review of heuristic algorithms for frequent itemsets mining problem. Computing and Informatics, 42(6): 1360–1377-1360–1377.
	Choi W I, Song H J, Kim D S, et al. 2017. Dispersal patterns of pine wilt disease in the early stage of its invasion in South Korea. Forests, 8(11): 411.
	Gan W, Lin J C W, Fournier-Viger P, et al. A survey of utility-oriented pattern mining. IEEE Transactions on Knowledge and Data Engineering, 2019, 33 (4): 1306- 1327.
	Hirata A, Nakamura K, Nakao K, et al. Potential distribution of pine wilt disease under future climate change scenarios. PLoS One, 2017, 12 (8): e0182837. doi: 10.1371/journal.pone.0182837
	Huang J, Zhao X, Mo X, et al. 2024. Host vegetation connectivity is decisive for the natural spread of pine wilt disease. Pest Management Science, 80(10):5141-5156
	Jin Z, He D, Wei Z. Intelligent fault diagnosis of train axle box bearing based on parameter optimization VMD and improved DBN. Engineering Applications of Artificial Intelligence, 2022, 110, 104713. doi: 10.1016/j.engappai.2022.104713
	Jolliffe I T, Cadima J. 2016. Principal component analysis: a review and recent developments. Philosophical Transactions of the Royal Society A: Mathematical, Physical and Engineering Sciences, 374(2065): 20150202.
	Lee D S, Choi W I, Nam Y, et al. Predicting potential occurrence of pine wilt disease based on environmental factors in South Korea using machine learning algorithms. Ecological informatics, 2021, 64, 101378. doi: 10.1016/j.ecoinf.2021.101378
	Lin J, Li X, Wen Y, et al. Modeling urban land-use changes using a landscape-driven patch-based cellular automaton (LP-CA). Cities, 2023, 132, 103906. doi: 10.1016/j.cities.2022.103906
	Liu C, Newell G, White M. On the selection of thresholds for predicting species occurrence with presence‐only data. Ecology and evolution, 2016, 6 (1): 337- 348. doi: 10.1002/ece3.1878
	Liu D, Zhang X. Occurrence prediction of pine wilt disease based on CA-Markov model. Forests, 2022, 13 (10): 1736. doi: 10.3390/f13101736
	Liu Y, Huang J, Yang T. Natural factors play a dominant role in the short-distance transmission of pine wilt disease. Forests, 2023, 14 (5): 1059. doi: 10.3390/f14051059
	Lu X, Huang J, Li X, et al. The interaction of environmental factors increases the risk of spatiotemporal transmission of pine wilt disease. Ecological Indicators, 2021, 133, 108394. doi: 10.1016/j.ecolind.2021.108394
	Lundberg S, Lee S I. 2017. A unified approach to interpreting model predictions. Advances in neural information processing systems, 30.
	Medrek M, Pastuszak Z. Numerical simulation of the novel coronavirus spreading. Expert Systems with applications, 2021, 166, 114109. doi: 10.1016/j.eswa.2020.114109
	Mirjalili S, Mirjalili S M, Lewis A. Grey wolf optimizer. Advances in Engineering Software, 2014, 69, 46- 61. doi: 10.1016/j.advengsoft.2013.12.007
	Mohd Pozi M S, Sulaiman M N, Mustapha N, et al. A new classification model for a class imbalanced data set using genetic programming and support vector machines: case study for wilt disease classification. Remote Sensing Letters, 2015, 6 (7): 568- 577. doi: 10.1080/2150704X.2015.1062159
	Tang X, Yuan Y, Li X, et al. Maximum entropy modeling to predict the impact of climate change on pine wilt disease in China. Frontiers in plant science, 2021, 12, 652500. doi: 10.3389/fpls.2021.652500
	Wang W, Zhu Q, He G, et al. Impacts of climate change on pine wilt disease outbreaks and associated carbon stock losses. Agricultural and Forest Meteorology, 2023, 334, 109426. doi: 10.1016/j.agrformet.2023.109426
	Xiao Y, Guo Q, Xie N, et al. Predicting the global potential distribution of Bursaphelenchus xylophilus using an ecological niche model: expansion trend and the main driving factors. BMC Ecology and Evolution, 2024, 24 (1): 48. doi: 10.1186/s12862-024-02234-1
	Yu B, Yin H, Zhu Z. 2017. Spatio-temporal graph convolutional networks: A deep learning framework for traffic forecasting. arXiv preprint arXiv: 1709.04875.
	Zhou H, Zhang S, Chen Y, et al. Research on pine wilt disease spread prediction based on an improved LGBM model. Phytopathology®, 2025, 115 (4): 410- 421.
	Zhou H W, Xie M, Koski T M, et al. Epidemiological model including spatial connection features improves prediction of the spread of pine wilt disease. Ecological Indicators, 2024, 63, 112103.
	Zhou J, Qiu Y, Zhu S, et al. Optimization of support vector machine through the use of metaheuristic algorithms in forecasting TBM advance rate. Engineering Applications of Artificial Intelligence, 2021, 97, 104015. doi: 10.1016/j.engappai.2020.104015
	Zhang Y, Dian Y, Zhou J, et al. Characterizing spatial patterns of pine wood nematode outbreaks in subtropical zone in China. Remote Sensing, 2021, 13 (22): 4682. doi: 10.3390/rs13224682

影响因子类型 Environmental factor type	影响因子 Environmental factor	缩写 Abbreviation	数据来源 Data source
生物气候因子 Bioclimatic factor	19项生物气候因子 19 Bioclimatic factors	Bio1-Bio19	https://data.cma.cn/
地理环境因子 Geography factor	海拔 Elevation	Ele	https://data.cma.cn/
人为影响因子 Human influence	人口 Population	Pop	https://www.resdc.cn/
	地区生产总值 Gross domestic product	GDP	https://www.resdc.cn/
	道路密度 Road density	R.dens	http://geodata.pku.edu.cn
	木材运输量 Pine wood transportation	PWT	国家林业和草原局生物灾害防控中心 Center for Biological Disaster Prevention and Control, National Forestry and Grassland Administration
	疫区木材运输量 Infected pine wood transportation	IPWT

项集长度 Length	频繁项集 Frequent items	支持度 Support	频率 Occurrences
1	疫区木材运输量 Infected pine wood transportation: 中 Middle（3.11~8.52）	0.546	1 601
1	木材运输量 Pine wood transportation: 较高 Relatively high（349.15~2 951.08）	0.454	1 329
1	木材运输量 Pine wood transportation: 中 Middle（200.00~349.15）	0.423	1 238
1	疫区木材运输量 Infected pine wood transportation: 较高 Relatively high（8.52~167.83）	0.311	913
1	木材运输量 Pine wood transportation: 高 High（6 386.88 ~ 8 478.69）	0.208	610
2	降水类影响因子 Synthetic precipitation class: 低 Low（?1.94~?1.62），疫区木材运输量 Infected pine wood transportation: 中 Middle（3.11~8.52）	0.394	1 155
2	疫区木材运输量 Infected pine wood transportation: 较高 Relatively high（8.52~167.83），木材运输量 Pine wood transportation: 高 High（6 386.88~8 478.69）	0.312	913
2	降水类影响因子 Synthetic precipitation class: 低 Low（?1.94~?1.62），木材运输量 Pine wood transportation: 中 Middle（200.00~349.15）	0.188	551
2	温度类影响因子 Synthetic temperature class: 较低 Relatively low（?1.75~?1.43），疫区木材运输量Infected pine wood transportation: 中 Middle（3.11~8.52）	0.168	492
2	木材运输量 Pine wood transportation: 中 Middle（200.00~349.15），温度类影响因子 Synthetic temperature class: 较低 Relatively low（?1.75~?1.43）	0.156	455

项集长度 Length	频繁项集 Frequent items	支持度 Support	频率 Frequency
1	Bio5: 较高Relatively high（54.32~54.42）	0.337	423
1	Bio6: 高High（0.20~1.02）	0.327	410
1	Bio11: 中Middle（14.65~14.82）	0.316	396
1	Bio11: 较高Relatively high（14.99~20.75）	0.274	343
1	Bio6: 中（0.16~0.20）	0.271	340
2	Bio16: 较高Relatively high（809.40~834.40）， Bio18: 较高Relatively high（809.40~834.40）	0.229	287
2	Bio16: 高High（801.20~809.40），Bio18: 高High（801.20~809.40）	0.226	283
2	Bio1: 较高Relatively high（26.39~49.54）， Bio10: 较高Relatively high（37.53~119.48）	0.226	283
2	Bio1: 较高Relatively high（26.39~49.54），Bio11: 较高Relatively high（14.99~20.75）	0.217	272
2	Bio5: 较高Relatively high（54.32~54.42），Bio8: 较高Relatively high（37.84~38.24）	0.213	267

预测模型 Predict model	准确率 Accuracy	召回率 Recall	精确率 Precision	F1分数 F1 score	曲线下面积 AUC
CA	0.979	0.785	0.382	0.491	0.890
SVM	0.967	0.147	0.062	0.088	0.781
RF	0.989	0.270	0.517	0.355	0.699
CART	0.987	0.298	0.360	0.326	0.988
GLM	0.991	0.273	0.736	0.398	0.986
ANN	0.991	0.288	0.701	0.408	0.988
