3种丁香属植物花粉特性及繁育系统的比较

doi:10.11707/j.1001-7488.LYKX20230542

Abstract

Abstract:

Objective: The aim of this study is to clarify the pollen morphology and pollen germination methods in vitro of three Syringa species, compare the effects of different storage temperatures on pollen viability, and estimate the pollen/ovule ratio (P/O) and out crossing index (OCI), so as to provide reference for cross breeding of Syringa. Method: S. oblata, S. oblata var. alba and S. × persica were used as experimental materials, and the pollen morphology was observed using scanning electron microscopy. In vitro culture methods were used to study the suitable media for pollen germination, and the effect of different storage temperatures on pollen lifespan was explored. A blood cell counter method was used to calculate the P/O ratio and the out crossing index was estimated through measuring flower traits. Result: All three Syringa species had medium sized pollens, ellipsoidal in shape, with three germination grooves and clear network carvings. The ratio of pollen polar axis length to equatorial axis length (P/E) value ranged from 1.45 to 1.83, and the volume index ranged from 28.24 to 38.82. The contents of sucrose, boric acid, CaCl₂, GA₃, and 6-BA in the culture medium all had effects on pollen germination in vitro. The suitable medium composition for the pollen germination of three Syringa species was as follows: 15 g·L⁻¹ sucrose, 50 mg·L⁻¹ boric acid, 50 mg·L⁻¹ calcium chloride, and 25 mg·L⁻¹ 6-BA for S. oblate, 15 g·L⁻¹ sucrose + 50 mg·L⁻¹ boric acid + 50 mg·L⁻¹ calcium chloride + 50 mg·L⁻¹ GA₃ for S. oblata var. alba and S. × persica. Conclusion: According to the number, position and character (NPC) system of pollen classification, the pollen of all three Syringa species belongs to the N3P4C5-type, which can be identified based on pollen volume, P/E ratio, and extine pattern of pollen. The viability of pollens stored at room temperature can only be maintained for about 14 days. The pollens stored at –80 ℃ maintains high pollen viability, making it the optimal method for preserving pollens. The P/O ratio estimation suggests that the three Syringa species have outcrossing breeding system, whereas the OCI results suggest that the breeding modes of the three Syringa species are partial self-compatible, insect-pollination outcrossing.

Key words: Syringa, pollen morphology, pollen viability, in vitro germination medium, storage temperature, breeding mode

CLC Number:

S718.43

Lie Ma,Ting Zheng,Xiaoyan Ding,Jing Tian,Minghua Yu,Chengzhong Wang. Comparison on Pollen Characteristics and Breeding Systems of Three Syringa Species[J]. Scientia Silvae Sinicae, 2024, 60(11): 190-198.

Figures/Tables 11

Table 1

Table 2

Fig.1

Table 3

Fig.2

Fig.3

Table 4

Table 5

Fig.4

Table 6

Table 7

References 0

	埃尔特曼. 1978. 中国科学院植物研究所古植物研究室孢粉组译. 孢粉学手册. 北京: 科学出版社.
	Erdtman G. 1978. Handbook of palynology. Translated by Palynology Department, Institute of Botany, Chinese Academy of Sciences. Beijing: Science Press. ［in Chinese］
	何芮庆, 杨云尧, 胡增辉, 等. 紫丁香195个实生单株花表型性状变异分析. 植物研究, 2021, 41 (2): 213- 220. doi: 10.7525/j.issn.1673-5102.2021.02.009
	He R Q, Yang Y Y, Hu Z H, et al. Variation of flower phenotypic traits on 195 Syringa oblata seed seedings single trees. Bulletin of Botanical Research, 2021, 41 (2): 213- 220. doi: 10.7525/j.issn.1673-5102.2021.02.009
	黄东晨, 任晓亮, 马小民, 等. 榧树的花粉活力检测及短期贮藏条件. 中南林业科技大学学报, 2023, 43 (5): 58- 65, 129.
	Huang D C, Ren X L, Ma X M, et al. Studies on pollen vitality detection and short-term storage conditions of Torreya grandis. Journal of Central South University of Forestry & Technology, 2023, 43 (5): 58- 65, 129.
	纪文跃, 何　淼, 尉文婕, 等. 4种丁香的开花特性与繁育系统. 东北林业大学学报, 2020, 48 (12): 23- 26. doi: 10.3969/j.issn.1000-5382.2020.12.005
	Ji W Y, He M, Wei W J, et al. Preliminary study on the biological characteristics and breeding system of four species of Syringa. Journal of Northeast Forestry University, 2020, 48 (12): 23- 26. doi: 10.3969/j.issn.1000-5382.2020.12.005
	贾文庆, 王艳丽, 郭英姿, 等. 大花黄牡丹花粉萌发及贮存特性. 林业科学, 2021, 57 (2): 82- 92. doi: 10.11707/j.1001-7488.20210209
	Jia W Q, Wang Y L, Guo Y Z, et al. Characterization of pollen germination and storage of Paeonia ludlowii. Scientia Silvae Sinicae, 2021, 57 (2): 82- 92. doi: 10.11707/j.1001-7488.20210209
	黎怀成, 徐　波, 高信芬. 国产山蚂蝗属植物花粉形态及其分类意义. 应用与环境生物学报, 2018, 24 (6): 1330- 1337.
	Li H C, Xu B, Gao X F. Pollen morphology and its taxonomic significance for Desmodium Desv. in China. Chinese Journal of Applied and Environmental Biology, 2018, 24 (6): 1330- 1337.
	李玉萍, 罗凤霞, 王春彦, 等. 风信子花粉萌发及贮藏性研究. 西北植物学报, 2010, 30 (12): 2484- 2489.
	Li Y P, Luo F X, Wang C Y, et al. Characteristics of pollen germination and storage in Hyacinthus orientalis. Acta Botanica Boreali-Occidentalia Sinica, 2010, 30 (12): 2484- 2489.
	刘　芊, 徐　瑾, 石　印, 等. 丁香属12种植物花粉保存方法研究. 浙江农业学报, 2014, 26 (3): 615- 620. doi: 10.3969/j.issn.1004-1524.2014.03.14
	Liu Q, Xu J, Shi Y, et al. Storage methods of 12 species of lilac (Syringa L.) pollen. Acta Agriculturae Zhejiangensis, 2014, 26 (3): 615- 620. doi: 10.3969/j.issn.1004-1524.2014.03.14
	刘雪莲, 杨晴晴, 秦佳梅, 等. 植物生长调节剂对紫丁香花粉离体萌发的影响. 东北林业大学学报, 2011, 39 (10): 54- 55. doi: 10.3969/j.issn.1000-5382.2011.10.015
	Liu X L, Yang Q Q, Qin J M, et al. Effects of plant growth regulators on in vitro pollen germination of Syringa oblata. Journal of Northeast Forestry University, 2011, 39 (10): 54- 55. doi: 10.3969/j.issn.1000-5382.2011.10.015
	刘壮壮, 曹　凡, 张　瑞, 等. 5个薄壳山核桃品种花粉形态电镜扫描观察. 经济林研究, 2016, 34 (2): 137- 142.
	Liu Z Z, Cao F, Zhang R, et al. Observation of pollen morphologies in five cultivars of Carya illinoensis by SEM. Nonwood Forest Research, 2016, 34 (2): 137- 142.
	马玉花, 王小东, 徐　恒, 等. 丁香属10种植物的同工酶谱分析研究. 甘肃农业大学学报, 2012, 47 (4): 151- 154. doi: 10.3969/j.issn.1003-4315.2012.04.030
	Ma Y H, Wang X D, Xu H, et al. Analysis on isozyme pattern of 10 Syringa species. Journal of Gansu Agricultural University, 2012, 47 (4): 151- 154. doi: 10.3969/j.issn.1003-4315.2012.04.030
	乔占国, 汪　芳, 吴娇娇, 等. 榆林沙区黑沙蒿花粉二型性特征观察. 西北林学院学报, 2022, 37 (6): 107- 112. doi: 10.3969/j.issn.1001-7461.2022.06.15
	Qiao Z G, Wang F, Wu J J, et al. Observation on the characteristics of pollen dimorphism of Artemisia ordosica in Yulin sandy area. Journal of Northwest Forestry University, 2022, 37 (6): 107- 112. doi: 10.3969/j.issn.1001-7461.2022.06.15
	任洪岩, 吾买尔夏提·塔汉, 周桂玲. 12种十字花科植物花粉形态研究. 西北植物学报, 2011, 31 (1): 72- 78.
	Ren H Y, Wumaierxiati T H, Zhou G L. Pollen morphology of twelve species in Brassicaceae. Acta Botanica Boreali-Occidentalia Sinica, 2011, 31 (1): 72- 78.
	王楚彪, 李敖彬, 潘松海, 等. 7种桉树花粉微观形态及其亲缘关系分析. 热带亚热带植物学报, 2021, 29 (2): 180- 186. doi: 10.11926/jtsb.4258
	Wang C B, Li A B, Pan S H, et al. Analysis of pollen micro-morphology and phylogenetic relationship among seven species of Eucalyptus. Journal of Tropical and Subtropical Botany, 2021, 29 (2): 180- 186. doi: 10.11926/jtsb.4258
	许　昕, 刘佳奇, 王宇含, 等. 小叶丁香花芽分化进程及内源激素的变化. 生态学杂志, 2024, 43 (1): 146- 152.
	Xu X, Liu J Q, Wang Y H, et al. The process of flower bud differentiation and changes of endogenous hormones in Syringa microphylla. Chinese Journal of Ecology, 2024, 43 (1): 146- 152.
	杨延红, 宋桂全, 董　慧, 等. 连翘花粉离体萌发及活力测定. 北方园艺, 2021, (10): 112- 117.
	Yang Y H, Song G Q, Dong H, et al. , Determination of pollen vitality and in vitro germination of pollen in Forsythia suspensa. Northern Horticulture, 2021, (10): 112- 117.
	姚瑞红, 魏　杰, 孟　昕, 等. 基于ISSR标记的丁香属植物亲缘关系分析. 河北农业大学学报, 2021, 44 (5): 48- 56.
	Yao R H, Wei J, Meng X, et al. Genetic relationship analysis of Syringa materials based on ISSR marker. Journal of Hebei Agricultural University, 2021, 44 (5): 48- 56.
	曾思源. 2023. 中国女贞亚族的分类研究. 重庆: 西南大学.
	Zeng S Y. 2023. A taxonomic study of China-distribution subtribe Ligustrinae (Oleaceae). Chongqing: Southwest University. ［in Chinese］
	张小平, 王　琼. 菊科花粉形态与系统分类的研究现状与发展趋势. 安徽师范大学学报(自然科学版), 2007, 30 (3): 326- 330.
	Zhang X P, Wang Q. Recent advance in study of pollen morphology and systematics of the family Asteraceae. Journal of Anhui Normal University (Natural Science), 2007, 30 (3): 326- 330.
	赵艺璇, 冯　琪, 田　琳, 等. 22个木槿品种花粉形态与分类研究. 广西植物, 2021, 41 (1): 103- 113. doi: 10.11931/guihaia.gxzw201911037
	Zhao Y X, Feng Q, Tian L, et al. Pollen morphology and numerical taxonomy of 22 Hibiscus syriacus. Guihaia, 2021, 41 (1): 103- 113. doi: 10.11931/guihaia.gxzw201911037
	郑　林, 陈　红, 张　雷, 等. 木瓜属植物的花粉形态及品种分类. 林业科学, 2008, 44 (5): 53- 59. doi: 10.3321/j.issn:1001-7488.2008.05.011
	Zheng L, Chen H, Zhang L, et al. Pollen morphology and cultivar classification of the genus Chaenomeles. Scientia Silvae Sinicae, 2008, 44 (5): 53- 59. doi: 10.3321/j.issn:1001-7488.2008.05.011
	中国科学院中国植物志编辑委员会. 2004. 中国植物志. 北京: 科学出版社.
	Flora of China Editorial Board, Chinese Academy of Sciences. 2004. Flora of China. Beijing: Science Press. ［in Chinese］
	Cruden R W. Pollen-ovuleratios: a conservative indicator of breeding systems in flowering plants. Evolution, 1977, 31 (1): 32- 46. doi: 10.2307/2407542
	Dafni A. 1992. Pollination ecology:a practical approach. Oxford: Oxford University Press.
	Li J H, Alexander J H, Zhang D L. Paraphyletic Syringa (Oleaceae): evidence from sequence of nuclear ribosomal DNA ITS and ETS regions. Systematic Botany, 2002, 27 (3): 592- 597.
	Karim K, Awad M A, Manar A, et al. Effect of flowering stage and storage conditions on pollen quality of six male date palm genotypes. Saudi Journal of Biological Sciences, 2022, 29 (4): 2564- 2572. doi: 10.1016/j.sjbs.2021.12.038
	Sorkheh K, Azimkhani R, Mehri N, et al. Interactive effects of temperature and genotype on almond (Prunus dulcis L.) pollen germination and tube length. Scientia Horticulturae, 2018, 227, 162- 168. doi: 10.1016/j.scienta.2017.09.037
	Xu B, Gao X F, Wu N, et al. Pollen diversity and its systematic implications in Lespedeza (Fabaceae). Systematic Botany, 2011, 36 (2): 352- 361. doi: 10.1600/036364411X569534

处理组 Treatments	赤霉素 GA₃/(mg·L^?1)	6-苄氨基嘌呤 6-BA/(mg·L^?1)
A2	25	0
B2	50	0
C2	100	0
D2	0	10
E2	0	25
F2	0	50

形态 Morphology	紫丁香 S. oblata	白丁香 S. oblata var. alba	花叶丁香 S. × persica
外部形状 External shape	长球形 Ellipsoidal	长球形 Ellipsoidal	长球形 Ellipsoidal
极轴长 Polar axis length/μm	38.82±3.34a	32.65±3.54a	27.24±3.03b
赤道轴长 Equatorial axis length/μm	21.17±2.18a	19.94±3.06b	18.82±1.55b
极赤比 Polar/equatorial ratio（P/E）	1.83a	1.64b	1.45c
萌发沟数量 Germinal furrow number	3	3	3
萌发沟宽 Germinal furrow width/μm	4.24±0.50	4.93±0.74	4.01±0.62
体积大小指数 Volume size index	38.82a	32.65b	28.24c
外壁纹饰类别 Decorative pattern	网状雕纹 Mesh carving pattern	网状雕纹 Mesh carving pattern	网状雕纹 Mesh carving pattern
网孔特点 Mesh characteristics	网脊较厚，网孔较圆钝，呈不规则状 Mesh ridge thick, mesh hole round, blunt, and irregular in shape	网脊较薄，网孔较圆钝，呈不规则状 Mesh ridges thin, mesh hole round, blunt, and irregular in shape	网脊较厚，网孔较大且锐利，不规则多角形 Mesh ridge thick, mesh hole large, sharp, irregular polygonal shape

花粉活力 Pollen viability	紫丁香 S. oblata	白丁香 S. oblata var. alba	花叶丁香 S. × persica
强活力花粉占比 The proportion of strong pollen viability	5.67±0.72	1.67±0.33	2.33±0.40
弱活力花粉占比 The proportion of weak pollen viability	12.33±1.32	4.67±0.64	7.33±0.93
总花粉活力 Total pollen viability	18.00±1.31	6.34±0.83	9.66±1.05

花粉处理 Treatment	紫丁香 S. oblata	白丁香 S. oblata var. alba	花叶丁香 S. × persica
新鲜花粉 Fresh pollen	30.17±4.15	27.60±3.20	32.73±5.44
自然阴干24 h Natural shade drying for 24 h	25.83±2.10	23.05±2.46	27.32±2.84
35 ℃培养箱1 h Incubator at 35 ℃ for 1 h	19.26±1.38	15.84±1.77	17.25±1.29
35 ℃培养箱3 h Incubator at 35 ℃ for 3 h	14.26±1.93	11.71±1.08	12.48±1.00

	紫丁香 S. oblata	白丁香 S. oblata var. alba	花叶丁香 S. × persica
单花花粉数量 Number of pollens	12 240±2 480	10 470±2 040	15 580±1 510
单花胚珠数量 Number of ovules	4±0	4±0	4±0
花粉/胚珠比 Pollen/ovule ratio	3 060	2 617.5	3 895
