大兴安岭白桦削度方程

doi:10.11707/j.1001-7488.20201109

Abstract

Abstract:

Objective: Stem taper functions are important components in forest management and planning systems. Currently,there is no taper function for Betula platyphylla in northeast China,therefore,it is necessary to develop the taper function for this species. Eight commonly used taper functions in forestry were compared to evaluate which would provide a better prediction for diameter at a specific height and total volume for B. platyphylla in northeast China. Method: The data used in this study were collected from 253 destructively felled sample trees with 3 795 diameter/height measurements in the northwest of the northern slope of Yilehuli Mountains of northeast China. A first-order continuous autoregressive error structure was used to model the error term and account for autocorrelation. Multicollinearity was also evaluated with condition number. Coefficient of determination (R²),mean absolute bias (MAB),root mean square error (RMSE) and mean percentage of bias (MPB) were selected as evaluation criteria of models. Comparison of the taper models was carried out using goodness-of-fit statistics,box plots of diameter and volume residual distributions and validation statistics. Result: 1) In terms of model fitting statistics, the models of Kozak (2004)-2, Fang et al. (2000) and Max et al. (1976) were the top three models. The model of Sharma et al. (2001) showed the poorest performance. 2) Based on the box plots of diameter and volume residuals, the models of Bi (2000), Max et al. (1976), Kozak (2004)-2 and Fang et al. (2000) were more accurate in diameter and volume prediction with smaller errors and almost similar residual diameter and volume distribution. The models of Sharma et al. (2001), Sharma et al. (2004), Sharma et al. (2009) and Kozak (2004)-1 had non homogeneous distribution of the diameter residuals along different sections of the stem. 3) Model validation also confirmed that Max et al. (1976), Kozak (2004)-2 and Fang et al. (2000) showed better performances. In general, the model of Kozak (2004)-2 showed consistent performances and was superior to other taper models in predicting diameter and volume. Conclusion: Based on the evaluation statistics of fitting and validation,graphic analysis and condition number,the model of Kozak (2004)-2 was recommended for estimating diameter at a specific height,total volume and merchantable volume for B. platyphylla in northeast China.

Key words: Betula platyphylla, taper, volume, autocorrelation, multicollinearity

CLC Number:

S757

Muhammad Khurram Shahzad,Amna Hussain,Pei He,Lichun Jiang. Stem Taper Functions for Betula platyphylla in Daxing'anling[J]. Scientia Silvae Sinicae, 2020, 56(11): 87-96.

Figures/Tables 8

Model	Expression
Bi(2000)	$ d=D\left(\frac{\ln \sin \left(\frac{\pi}{2} q\right)}{\ln \sin \left(\frac{\pi}{2} t\right)}\right)^{b_{0}+b_{1} \sin \left(\frac{\pi}{2} q\right)+b_{2} \cos \left(\frac{3 \pi}{2} q\right)+b_{3} \sin \left(\frac{\pi}{2} q\right) / q+b_{4} D+b_{5} q \sqrt{D}+b_{6} q \sqrt{H}}$
Sharma et al. (2001)	${d = \sqrt {{D^2}{{\left({\frac{h}{{1.3}}} \right)}^{2 - {b_1}}}X} } $
Sharma et al.(2004)	$ {d = D\sqrt {{b_0}{{\left({\frac{h}{{1.3}}} \right)}^{2 - \left({{b_1} + {b_2}z + {b_3}{z^2}} \right)}}\left({\frac{{H - h}}{{H - 1.3}}} \right)} }$
Sharma et al.(2009)	$ {d = D\left[ {{b_0}\left({\frac{{H - h}}{{H - 1.3}}} \right){{\left({\frac{h}{{1.3}}} \right)}^{{b_1} + {b_2}z + {b_3}{z^2}}}} \right]}$
Max et al.(1976)	$d=\sqrt{D^{2}\left[b_{1}(q-1)+b_{2}\left(q^{2}-1\right)+b_{3}\left(a_{1}-q\right)^{2} I_{1}+b_{4}\left(a_{2}-q\right)^{2} I_{2}\right]} $ I₁=1, if q ≤ a₁; 0 otherwiseI₂ =1, if q ≤ a₂; 0 otherwise
Kozak (2004)-1	$d = {b_0}{D^{{b_1}}}{\left[ {\frac{{1 - {q^{1/4}}}}{{1 - {m^{1/4}}}}} \right]^{\left[ {{b_2} + {b_3}\left({1/{{\rm{e}}^{D/H}}} \right) + {b_4}D\left({\frac{{1 - {q^{1/4}}}}{{1 - {m^{1/4}}}}} \right) + {b_5}{{\left({\frac{{1 - {q^{1/4}}}}{{1 - {m^{1/4}}}}} \right)}^{D/H}}} \right]}} $
Kozak (2004)-2	${d = {b_0}{D^b}_1{H^{{b_2}}}{{\left[ {\frac{{1 - {q^{1/3}}}}{{1 - {t^{1/3}}}}} \right]}^{\left[ {{b_3}{q^4} + {b_4}\left({1/{{\rm{e}}^{D/H}}} \right) + {b_5}{{\left({\frac{{1 - {q^{1/3}}}}{{1 - {t^{1/3}}}}} \right)}^{0.1}} + {b_6}(1/D) + {b_7}{H^{1 - {q^{1/3}}}} + {b_8}\left({\frac{{1 - {q^{1/3}}}}{{1 - {t^{1/3}}}}} \right)} \right]}}} $
Fang et al.(2000)	$ \begin{array}{l}\begin{array}{*{20}{l}}{d = {c_1}\sqrt {{H^{\left({k - {b_1}} \right)/{b_1}}}{{(1 - z)}^{(k - b)/b}}q_1^{{I_1} + {I_2}}q_2^{{I_2}}} }\\{{c_1} = \sqrt {{a_0}{D^a}1{H^a}{2^{ - k/b}}1/\left[ {{b_1}\left({{t_0} - {t_1}} \right) + {b_2}\left({{t_1} - {q_1}{t_2}} \right) + {b_3}{q_1}{t_2}} \right]} }\end{array}\\{q_1} = {\left({1 - {p_1}} \right)^{\left({{b_2} - {b_1}} \right)k/{b_1}{b_2}}}\;\;{q_2} = {\left({1 - {p_2}} \right)^{\left({{b_3} - {b_2}} \right)k/{b_2}{b_3}}}\;\;\quad {t_0} = 1\quad {t_1} = {\left({1 - {p_1}} \right)^{k/{b_1}}}\\{t_2} = {\left({1 - {p_2}} \right)^{k/{b_2}}}\quad z = h/H\;\;\quad b = b_1^{1 - \left({{I_1} + {I_2}} \right)}b_2^{{I_1}}{b_3}^{{I_2}}\quad k = 0.000078539\\{\rm{ }}{I_1} = 1, \;{\rm{if }}~~{p_2} \ge z \ge {p_1}, 0{\rm{ }}\;\;{\rm{otherwise }}\;\;\;\;\;\;{I_2} = 1, {\rm{ if }}1 \ge z \ge {p_2}, 0{\rm{ }}\;\;{\rm{otherwise}}\end{array}$

References 0

	姜立春, 马英莉, 李耀翔. 大兴安岭不同区域兴安落叶松可变指数削度方程. 林业科学, 2016, 52 (2): 17- 25.
	Jiang L C , Ma Y L , Li Y X . Variable-exponent taper models for dahurian larch in different regions of Daxing'anling. Scientia Silvae Sinicae, 2016, 52 (2): 17- 25.
	Anta M B , Diéguez-Aranda U , Castedo-Dorado F , et al. Merchantable volume system for pedunculate oak in northwestern Spain. Annals of Forest Science, 2007, 64, 511- 520. doi: 10.1051/forest:2007028
	Belsley D A. 1991. Conditioning diagnostics: collinearity and weak data in regression. John Wiley & Sons, Inc., New York, 396.
	Bi H . Trigonometric variable-form taper equations for Australian eucalypts. Forest Science, 2000, 46, 397- 409.
	Biging G S . Taper equations for second-growth mixed conifers of Northern California. Forest Science, 1984, 30, 1103- 1117.
	Corral-Rivas J J , Diéguez-Aranda U , Rivas S C , et al. A merchantable volume system for major pine species in El Salto, Durango (Mexico). Forest Ecology and Management, 2007, 238, 118- 129. doi: 10.1016/j.foreco.2006.09.074
	Crecente-Campo F , Alboreca A R , Diéguez-Aranda U . A merchantable volume system for Pinus sylvestris L. in the major mountain ranges of Spain. Annals of Forest Science, 2009, 66, 1- 12.
	de-Miguel S , Meht talo L , Shater Z , et al. Evaluating marginal and conditional predictions of taper models in the absence of calibration data. Canadian Journal of Forest Research, 2012, 42, 1383- 1394. doi: 10.1139/x2012-090
	Demaerschalk J . Converting volume equations to compatible taper equations. Forest Science, 1972, 18, 241- 245. doi: 10.1093/forestscience/18.3.241
	Diéguez-Aranda U , Castedo-Dorado F , lvarez-González J G , et al. Compatible taper function for Scots pine plantations in northwestern Spain. Canadian Journal of Forest Research, 2006, 36, 1190- 1205. doi: 10.1139/x06-008
	Fang Z , Bailey R L . Compatible volume and taper models with coefficients for tropical species on Hainan Island in Southern China. Forest Science, 1999, 45, 85- 100.
	Fang Z , Borders E , Bailey L . Compatible volume-taper models for loblolly and slash pine based on a system with segmented-stem form factors. Forest Science, 2000, 46, 1- 12.
	Gómez-García E , Crecente-Campo F , Diéguez-Aranda U . Selection of mixed-effects parameters in a variable-exponent taper equation for birch trees in northwestern Spain. Annals of Forest Science, 2013, 70, 707- 715. doi: 10.1007/s13595-013-0313-9
	Heidarsson L , Pukkala T . Taper functions for lodgepole pine (Pinus contorta) and Siberian larch (Larix sibirica) in Iceland. Icelandic Agricultural Sciences, 2011, 24, 3- 11.
	Jiang L , Brooks J R , Wang J . Compatible taper and volume equations for yellow-poplar in West Virginia. Forest Ecology and Management, 2005, 213, 399- 409. doi: 10.1016/j.foreco.2005.04.006
	Kozak A . A variable-exponent taper equation. Canadian Journal of Forest Research, 1988, 18, 1363- 1368. doi: 10.1139/x88-213
	Kozak A . My last words on taper equations. The Forestry Chronicle, 2004, 80, 507- 515. doi: 10.5558/tfc80507-4
	Lee W K , Seo J H , Son Y M , et al. Modeling stem profiles for Pinus densiflora in Korea. Forest Ecology and Management, 2003, 172, 69- 77. doi: 10.1016/S0378-1127(02)00139-1
	Li R , Weiskittel A , Dick A R , et al. Regional stem taper equations for eleven conifer species in the Acadian region of North America: development and assessment. Northern Journal of Applied Forestry, 2012, 29, 5- 14. doi: 10.5849/njaf.10-037
	Li R , Weiskittel A R . Comparison of model forms for estimating stem taper and volume in the primary conifer species of the North American Acadian Region. Annals of Forest Science, 2010, 67, 302- 317. doi: 10.1051/forest/2009109
	Lumbres C , Abino A C , Pampolina N M , et al. Comparison of stem taper models for the four tropical tree species in Mount Makiling, Philippines. Journal of Mountain Science, 2016, 13 (3): 536- 545. doi: 10.1007/s11629-015-3546-2
	Max T A , Burkhart H E . Segmented polynomial regression applied to taper equations. Forest Science, 1976, 22, 283- 289.
	Muhairwe C K . Taper equations for Eucalyptus pilularis and Eucalyptus grandis for the north coast in New South Wales, Australia. Forest Ecology and Management, 1999, 113, 251- 269. doi: 10.1016/S0378-1127(98)00431-9
	Muhairwe C K , LeMay V M , Kozak A . Effects of adding tree, stand, and site variables to Kozak's variable-exponent taper equation. Canadian Journal of Forest Research, 1994, 24, 252- 259. doi: 10.1139/x94-037
	Newton P F , Sharma M . Evaluation of sampling design on taper equation performance in plantation-grown Pinus banksiana. Scandinavian journal of forest research, 2008, 23, 358- 370. doi: 10.1080/02827580801995349
	Poudel K P , Cao Q V . Evaluation of methods to predict Weibull parameters for characterizing diameter distributions. Forest Science, 2013, 59, 243- 252. doi: 10.5849/forsci.12-001
	Reed D D , Green E J . Compatible stem taper and volume ratio equations. Forest Science, 1984, 30, 977- 990.
	Rojo A , Perales X , Sánchez-Rodríguez F , et al. Stem taper functions for maritime pine (Pinus pinaster Ait.) in Galicia (Northwestern Spain). European Journal of Forest Research, 2005, 124, 177- 186. doi: 10.1007/s10342-005-0066-6
	Sharma M , Oderwald R G . Dimensionally compatible volume and taper equations. Canadian Journal of Forest Research, 2001, 31, 797- 803. doi: 10.1139/x01-005
	Sharma M , Parton J . Modeling stand density effects on taper for jack pine and black spruce plantations using dimensional analysis. Forest Science, 2009, 55, 268- 282.
	Sharma M , Zhang S . Variable-exponent taper equations for jack pine, black spruce, and balsam fir in eastern Canada. Forest Ecology and Management, 2004, 198, 39- 53. doi: 10.1016/j.foreco.2004.03.035
	Thomas C E , Parresol B R . Simple, flexible, trigonometric taper equations. Canadian Journal of Forest Research, 1991, 21, 1132- 1137. doi: 10.1139/x91-157
	Wilhelmsson L . Two models for predicting the number of annual rings in cross-sections of tree stems. Scandinavian Journal of Forest Research, 2006, 21, 37- 47. doi: 10.1080/14004080500486799
	Zhang S , Liu C . Predicting the lumber volume recovery of Picea mariana using parametric and non-parametric regression methods. Scandinavian Journal of Forest Research, 2006, 21, 158- 166. doi: 10.1080/02827580500531791

Data	Variable	Number of trees	Mean	Min.	Max.	SD
Fitting	D	191	18.18	5.0	43.8	8.26
Fitting	H	191	17.25	7.9	24.1	3.92
Validation	D	62	16.84	5.2	36.3	8.00
Validation	H	62	15.77	8.5	22.1	3.09

Models	b₀	b₁	b₂	b₃	b₄	b₅	b₆	b₇	b₈	a₀	a₁	a₂	p₁	p₂
Bi (2000)	0.339 4 (0.061 0)	0.339 4 (0.030 1)	0.339 4 (0.009 7)	0.339 4 (0.033 8)	0.339 4 (0.000 2)	—	—
Sharma et al. (2001)		2.037 6 (0.000 7)
Sharma et al. (2004)	1.011 2 (0.004 1)	2.033 4 (0.000 7)	—	0.363 7 (0.012 3)
Sharma et al. (2009)	1.010 8 (0.002 3)	-0.013 8 (0.000 3)	0.201 6 (0.014 7)	0.046 1 (0.021 4)
Max et al. (1976)		-3.919 8 (0.361 9)	1.878 8 (0.198 5)	-1.775 3 (0.176 7)	156.608 3 (12.162 7)						0.747 3 (0.027 6)	0.064 4 (0.002 4)
Kozak (2004)-1	1.353 7 (0.027 5)	0.945 8 (0.006 7)	0.346 9 (0.012 2)	0.357 4 (0.040 5)	0.008 3 (0.000 8)	-0.697 2 (0.062 3)
Kozak (2004)-2	0.892 2 (0.034 6)	0.967 2 (0.007 7)	0.076 6 (0.017 9)	0.432 4 (0.021 6)	0.154 0 (0.035 0)	0.365 9 (0.014 6)	—	0.011 8 (0.001 9)	-0.086 3 (0.025 3)
Fang et al. (2000)		6.62E-06 (1.8E-7)	0.000 035 (2.7E-7)	0.000 030 (6.0E-7)						0.000 048 (3.4E-6)	1.950 1 (0.015 1)	0.970 3 (0.034 4)	0.047 6 (0.001 3)	0.613 2 (0.034 1)

Models	RMSE	R²	Rank	CN
Bi (2000)	1.528 7	0.971 1	1.667	113.4 5
Sharma et al. (2001)	1.885 1	0.955 9	8.000	1.000 0
Sharma et al. (2004)	1.578 6	0.969 1	2.527	1.800 0
Sharma et al. (2009)	1.528 2	0.971 1	1.662	8.904 8
Max et al. (1976)	1.495 6	0.972 3	1.123	274.69
Kozak (2004)-1	1.630 6	0.967 1	2.905	30.220
Kozak (2004)-2	1.488 7	0.972 6	1.000	77.830
Fang et al. (2000)	1.492 4	0.972 4	1.074	83.083

Models	Diameter				Volume
Models	MPB	MAB	RMSE	Rank	MPB	MAB	RMSE	Rank
Bi (2000)	7.428 3	0.982 2	1.696 9	1.613	10.102 4	0.022 0	0.046 8	2.081
Sharma et al. (2001)	10.713 1	1.416 5	2.338 3	8.000	17.913 1	0.039 1	0.070 7	8.000
Sharma et al. (2004)	7.814 3	1.033 1	1.714 9	2.180	10.621 4	0.023 1	0.048 1	2.445
Sharma et al. (2009)	7.331 8	0.969 4	1.656 9	1.358	16.236 0	0.035 4	0.066 7	6.817
Max et al. (1976)	7.294 0	0.964 4	1.605 2	1.143	9.980 1	0.021 7	0.047 1	2.039
Kozak (2004)-1	8.463 2	1.119 0	1.811 4	3.342	8.771 7	0.019 1	0.041 8	1.000
Kozak (2004)-2	7.185 3	0.950 0	1.651 9	1.148	9.653 0	0.021 0	0.045 5	1.745
Fang et al. (2000)	7.249 5	0.958 5	1.634 9	1.179	10.078 3	0.022 0	0.046 4	2.043
