Scientia Silvae Sinicae ›› 2020, Vol. 56 ›› Issue (5): 89-96.doi: 10.11707/j.1001-7488.20200510
• Articles • Previous Articles Next Articles
Qianyong Shen,Mengping Tang*
Received:
2018-01-04
Online:
2020-05-25
Published:
2020-06-13
Contact:
Mengping Tang
CLC Number:
Qianyong Shen,Mengping Tang. Stem Volume Models of Phyllostachys edulis in Zhejiang Province[J]. Scientia Silvae Sinicae, 2020, 56(5): 89-96.
Table 1
Statistical summary of modeling data of moso bamboo"
变量 Variables | 平均值 Mean | 最大值 Max. | 最小值 Min. | SD | CV(%) |
胸径DBH(D)/ cm | 9.76 | 15.30 | 4.10 | 2.31 | 23.69 |
竹高Bamboo height(H)/cm | 14.42 | 26.20 | 4.10 | 2.93 | 20.31 |
胸高节长Internode length of bamboo at breast height(L)/ cm | 22.33 | 34.60 | 11.70 | 3.36 | 15.04 |
竹秆材积Stem volume(V)/ dm3 | 22.13 | 63.86 | 2.57 | 11.32 | 51.15 |
Table 2
Statistics of likelihood analysis for the error structure of stem volume models of bamboo in Zhejiang Province"
模型 Models | 方差Variance | AICcnorm | AICcln | ΔAICc | |
σnorm2 | σln2 | ||||
M1 | 9.383 2 | 0.568 3 | 744.996 1 | 690.648 4 | 54.347 7 |
M2 | 9.471 4 | 0.571 2 | 779.289 0 | 695.029 3 | 84.259 7 |
M3 | 9.378 1 | 0.570 3 | 748.152 1 | 692.261 4 | 55.890 7 |
M4 | 9.522 7 | 0.570 2 | 780.135 5 | 692.183 0 | 89.952 4 |
M5 | 9.379 4 | 0.570 4 | 753.491 8 | 692.315 0 | 61.176 8 |
Table 3
Parameter estimates and statistics for log-model fitting of bamboo stem volume models"
模型Models | 参数估计Parameter estimates | 统计指标Statistics | ||||||
a0 | a1 | a2 | Ra2 | SEE | ME | MSE(%) | ||
M1 | -2.150 5(-30.07) | 2.196 0(69.40) | — | 0.958 0 | 0.119 2 | 0.000 0 | 0.566 4 | |
M2 | -2.618 1(-30.50) | 1.883 1(39.21) | 0.442 6(7.98) | 0.967 7 | 0.104 6 | 0.000 0 | 0.422 9 | |
M3 | -2.991 1(-20.26) | 2.119 5(67.44) | 0.327 2(6.36) | 0.964 7 | 0.109 4 | 0.000 0 | 0.448 3 | |
M4 | -1.429 2(-10.65) | 1.988 2(44.62) | -3.481 9(-6.17) | 0.964 3 | 0.109 9 | 0.000 0 | 0.450 0 | |
M5 | -1.654 3(-16.43) | 2.114 9(67.08) | -6.841 1(-6.48) | 0.964 9 | 0.109 0 | 0.000 0 | 0.441 4 |
Table 4
Validation of the correction on anti-log transformation of the log-model"
模型Models | 校正因子CF | ME/dm3 | MSE(%) |
M′1 | CF0 | 0.094 5 | -0.816 8 |
CF1 | -5.153 5 | -29.46 | |
M′2 | CF0 | 0.104 8 | -0.638 2 |
CF2 | -5.167 0 | -29.38 | |
M′3 | CF0 | 0.074 7 | -0.704 4 |
CF3 | -5.197 3 | -29.42 | |
M′4 | CF0 | 0.126 3 | -0.715 7 |
CF4 | -5.130 2 | -29.43 | |
M′5 | CF0 | 0.077 6 | -0.703 7 |
CF5 | -5.194 5 | -29.42 |
陈双林, 吴柏林, 虞敏之, 等. 毛竹材积主要构件因子关系研究及材积表编制. 福建林业科技, 2008. 35 (2): 30- 33.
doi: 10.3969/j.issn.1002-7351.2008.02.007 |
|
Chen S L , Wu B L , Yu M Z , et al. The relationship among main component factors and establishment of timber volume table. Journal of Fujian Forestry Science and Technology, 2008. 35 (2): 30- 33.
doi: 10.3969/j.issn.1002-7351.2008.02.007 |
|
董利虎, 李凤日. 大兴安岭东部天然落叶松林可加性林分生物量估算模型. 林业科学, 2016. 52 (7): 13- 21. | |
Dong L H , Li F R . Additive stand-level biomass models for natural larch forest in the east of Daxing'an Mountains. Scientia Silvae Sinicae, 2016. 52 (7): 13- 21. | |
刘镜婷, 姜立春. 大兴安岭不同区域落叶松相容性材积方程及异方差研究. 林业科学研究, 2016. 29 (3): 317- 323.
doi: 10.3969/j.issn.1001-1498.2016.03.002 |
|
Liu J T , Jiang L C . Compatible tree volume equations and heteroscedasticity for Dahurian Larch in different region of Daxing'anling. Forest Research, 2016. 29 (3): 317- 323.
doi: 10.3969/j.issn.1001-1498.2016.03.002 |
|
孟宪宇. 测树学. 北京: 中国林业出版社. 2006. | |
Meng X Y . Forest measuration. Beijing: China Forestry Publishing House. 2006. | |
唐守正, 张会儒, 胥辉. 相容性生物量模型的建立及其估计方法研究. 林业科学, 2000. 36 (zk): 19- 27.
doi: 10.11707/j.1001-7488.2000S103 |
|
Tang S Z , Zhang H R , Xu H . Study on establish and estimate method of compatible biomass model. Scientia Silvae Sinicae, 2000. 36 (zk): 19- 27.
doi: 10.11707/j.1001-7488.2000S103 |
|
唐思嘉. 2017.毛竹林立地分类与立地质量评价研究.杭州:浙江农林大学硕士学位论文. | |
Tang S J. 2017. Study on site classification and site quality evaluation of Phyllostachys pubescens forest. Hangzhou: MS thesis of Zhejiang Agriculture and Forestry University.[in Chinese] | |
吴丁. 毛竹计量分析——材积生长模型之探讨. 福建林业科技, 1987. 14 (1): 49- 55. | |
Wu D . Quantitative analysis of Phyllostachys pubescens-a study on volume growth model. Journal of Fujian Forestry Science and Technology, 1987. 14 (1): 49- 55. | |
胥辉. 一种与材积相容的生物量模型. 北京林业大学学报, 1999. 21 (5): 32- 36.
doi: 10.3321/j.issn:1000-1522.1999.05.007 |
|
Xu H . A biomass model compatible with volume. Journal of Beijing Forestry University, 1999. 21 (5): 32- 36.
doi: 10.3321/j.issn:1000-1522.1999.05.007 |
|
杨麒麟, 李柏. 滑坡区毛竹根系生长分布及其护坡效果研究. 长江科学院院报, 2017. (10): 45- 49.
doi: 10.11988/ckyyb.20170091 |
|
Yang Q L , Li B . Growth distribution of bamboo root system in landslide area and its slope protection effect. Journal of Yangtze River Scientific Research Institute, 2017. (10): 45- 49.
doi: 10.11988/ckyyb.20170091 |
|
虞岳世, 黄清民. 毛竹干形和材积计算方法的初步研究. 林业科学, 1958. 4 (4): 451- 476. | |
Yu Y S , Huang Q M . A preliminary study on the stem form of bamboo(Phyllostachys pubescens)and the method of calculating its volume. Scientia Silvae Sinicae, 1958. 4 (4): 451- 476. | |
曾鸣, 聂祥永, 曾伟生. 中国杉木相容性立木材积和地上生物量方程. 林业科学, 2013. 49 (10): 74- 79. | |
Zeng M , Nie X Y , Zeng W S . Compatible tree volume and aboveground biomass equations of Chinese fir in China. Scientia Silvae Sinicae, 2013. 49 (10): 74- 79. | |
曾伟生,张会儒,唐守正. 2011a.立木生物量建模方法.北京:中国林业出版社. | |
Zeng W S, Zhang H R, Tang S Z. 2011a. The modeling method of tree biomass. Beijing: China Forestry Publishing House.[in Chinese] | |
曾伟生, 唐守正. 非线性模型对数回归的偏差校正及与加权回归的对比分析. 林业科学研究, 2011b. 24 (2): 137- 143. | |
Zeng W S , Tang S Z . Bias correction in logarithmic regression and comparison with weighted regression for non-linear models. Forest Research, 2011b. 24 (2): 137- 143. | |
曾伟生, 唐守正. 立木生物量方程的优度评价和精度分析. 林业科学, 2011c. 47 (11): 106- 113. | |
Zeng W S , Tang S Z . Goodness evaluation and precision analysis of tree biomass equations. Scientia Silvae Sinicae, 2011c. 47 (11): 106- 113. | |
张刚华, 萧江华, 郭子武. 毛竹竹秆直径与材积的垂直格局. 南京林业大学学报:自然科学版, 2007. 31 (2): 51- 54. | |
Zhang G H , Xiao J H , Guo Z W . Vertical patterns of diameter and volume of moso bamboo stem. Journal of Nanjing Forestry University:Natural Sciences Edition, 2007. 31 (2): 51- 54. | |
张振瀛, 廖为明. 毛竹干形结构及毛竹计量数表的研究. 江西农业大学学报, 1990. 12 (1): 18- 28. | |
Zhang Z Y , Liao W M . Studies on the structure of culm form and measuring tables of Phyllostachys pubescens. Acta Agriculture University Jiangxiensis, 1990. 12 (1): 18- 28. | |
周国模, 姜培坤. 毛竹林的碳密度和碳储量及其空间分布. 林业科学, 2004. 40 (6): 5- 11. | |
Zhou G M , Jiang P K . Density, storage and spatial distribution of carbon in Phyllostachy pubescens forest. Scientia Silvae Sinicae, 2004. 40 (6): 5- 11. | |
Ballantyne F . Evaluating model fit to determine if logarithmic transformations are necessary in allometry:a comment on the exchange between Packard(2009)and Kerkhoff and Enquist(2009). Journal of Theoretical Biology, 2013. 317, 418- 421.
doi: 10.1016/j.jtbi.2012.09.035 |
|
Baskerville G L . Use of logarithmic regression in the estimation of plant biomass. Canadian Journal of Forest Research, 1974. 2 (1): 49- 53. | |
Case B S C S , Hall R J H J . Erratum:assessing prediction errors of generalized tree biomass and volume equations for the boreal forest region of west-central Canada. Canadian Journal of Forest Research, 2008. 38, 878- 889.
doi: 10.1139/x07-212 |
|
Clifford D , Cressie N , England J R , et al. Correction factors for unbiased, efficient estimation and prediction of biomass from log-log allometric models. Forest Ecology and Management, 2013. 310, 375- 381.
doi: 10.1016/j.foreco.2013.08.041 |
|
Dong L H , Zhang L J , Li F R . A compatible system of biomass equations for three conifer species in northeast China. Forest Ecology and Management, 2014. 329, 306- 317.
doi: 10.1016/j.foreco.2014.05.050 |
|
Finney D J . On the distribution of a variate whose logarithm is normally distributed. Supplement to the Journal of the Royal Statistical Society, 1941. 7 (2): 155- 161.
doi: 10.2307/2983663 |
|
Kozak A , Kozak R . Does cross validation provide additional information in the evaluation of regression models?. Canadian Journal of Forest Research, 2003. 33 (6): 1499- 1499. | |
Lai J , Yang B , Lin D , et al. The allometry of coarse root biomass:log-transformed linear regression or nonlinear regression?. Plos One, 2013. 8 (10): e77007.
doi: 10.1371/journal.pone.0077007 |
|
Madgwick H A I , Satoo T . On estimating the aboveground weights of tree stands. Ecology, 1975. 56 (6): 1446- 1450.
doi: 10.2307/1934713 |
|
Myers B. 1986. Classical and modern regression with applications. Boston: Duxbury Press. | |
Packard G C , Birchard G F . Traditional allometric analysis fails to provide a valid predictive model for mammalian metabolic rates. Journal of Experimental Biology, 2008. 211 (22): 3581- 3587.
doi: 10.1242/jeb.023317 |
|
Parresol B R . Additivity of nonlinear biomass equations. Canadian Journal of Forest Research, 2001. 31 (5): 965- 878. | |
Snorrason A , Stefán A , Einarsson F . Single-tree biomass and stem volume functions for eleven tree species used in Icelandic forestry. Icelandic Agricultural Sciences, 2006. 19 (19): 15- 24. | |
Snowdon P . A ratio estimator for bias correction in logarithmic regressions. Revue Canadienne De Recherche Forestière, 1991. 21 (5): 720- 724.
doi: 10.1139/x91-101 |
|
Tang S , Li Y , Wang Y . Simultaneous equations, error-in-variable models, and model integration in systems ecology. Ecological Modelling, 2001. 142 (3): 285- 294.
doi: 10.1016/S0304-3800(01)00326-X |
|
Tang S , Wang Y . A parameter estimation program for the error-in-variable model. Ecological Modelling, 2002. 156 (2): 225- 236. | |
Xiao X , White E P , Hooten M B , et al. On the use of log-transformation vs.nonlinear regression for analyzing biological power laws. Ecology, 2011. 92 (10): 1887- 1894. | |
Zeng W S . Using nonlinear mixed model and dummy variable model approaches to develop origin-based individual tree biomass equations. Trees, 2015. 29 (1): 275- 283.
doi: 10.1007/s00468-014-1112-0 |
|
Zianis D , Xanthopoulos G , Kalabokidis K , et al. Allometric equations for aboveground biomass estimation by size class for Pinus brutia Ten. trees growing in north and south Aegean Islands, Greece. European Journal of Forest Research, 2011. 130 (2): 145- 160.
doi: 10.1007/s10342-010-0417-9 |
