		Scientia Silvae Sinicae ›› 2019, Vol. 55 ›› Issue (10): 27-37.doi: 10.11707/j.1001-7488.20191004
Previous Articles Next Articles
Min Zhang1,2,Chunxiang Cao1,*,Wei Chen1
Received:2017-08-18






																	Online:2019-10-25


																	Published:2019-11-26

						Contact:
								Chunxiang Cao
																					Supported by:CLC Number:
Min Zhang,Chunxiang Cao,Wei Chen. Remotely Sensed Diagnosing Temporal and Spatial Variation of Vegetation Coverage in Guangxi Based on MODIS NDVI Data[J]. Scientia Silvae Sinicae, 2019, 55(10): 27-37.


													Table 1
The area of convertible NDVI in different cities"
| 类型Types | 面积Area/km2 | |||
| 改善 Improvement | 基本不变 Almost unchanged | 退化Degradation | 合计Sum | |
| 河池Hechi | 15 156.324 | 15 729.108 | 2 038.450 | 32 923.882 |
| 百色Baise | 13 512.090 | 19 389.686 | 3 443.642 | 36 345.419 |
| 南宁Nanning | 9 807.096 | 7 924.441 | 2 708.768 | 20 440.305 |
| 桂林Guilin | 9 431.816 | 14 191.608 | 3 929.663 | 27 553.086 |
| 柳州Liuzhou | 7 568.101 | 8 816.266 | 2 435.916 | 18 820.282 |
| 来宾Laibin | 6 498.880 | 5 486.777 | 1 417.003 | 13 402.660 |
| 崇左Chongzuo | 6 125.224 | 10 868.511 | 2 825.633 | 19 819.368 |
| 钦州Qinzhou | 5 439.596 | 4 386.685 | 942.294 | 10 768.575 |
| 梧州Wuzhou | 4 549.735 | 6 782.440 | 1 637.422 | 12 969.597 |
| 玉林Yulin | 4 510.050 | 6 361.816 | 1 885.338 | 12 757.204 |
| 贵港Guigang | 4 374.437 | 5 056.227 | 1 499.496 | 10 930.160 |
| 贺州Hezhou | 4 334.503 | 5 736.018 | 1 575.240 | 11 645.761 |
| 防城港Fangchenggang | 1 854.591 | 3 415.044 | 724.563 | 5 994.197 |
| 北海Beihai | 983.791 | 1 354.232 | 949.419 | 3 287.441 |
| 合计Sum | 94 146.230 | 115 498.860 | 28 012.850 | 237 657.939 |


													Table 2
Matrix of area conversion between various land use types in Guangxi during 2006—2013"
| 类型Types | 面积转移Area of conversion/km2 | 合计Sum | |||||
| 林地Forest | 草地 Grassland | 农用地 Agricultural land | 水域 Waters | 城市及建筑用地 Urban construction land | 其他 Others | ||
| 林地Forest | 50 906.250 | 26 987.060 | 17 244.750 | 2 949.000 | 0 | 0 | 98 087.060 |
| 草地Grassland | 5 406.940 | 48 665.750 | 25 804.310 | 769.563 | 0 | 0 | 80 646.560 |
| 农用地Agricultural land | 902.625 | 11 343.560 | 39 941.560 | 168.563 | 0 | 0 | 52 356.310 |
| 水域Waters | 155.313 | 296.813 | 227.625 | 951.188 | 59.450 | 0 | 1 690.387 |
| 城市及建筑用地Urban construction land | 0 | 0 | 0 | 1.625 | 2 555.125 | 0 | 2 556.750 |
| 其他Others | 0 | 0 | 0 | 0 | 0 | 2 321.688 | 2 321.688 |
| 合计Sum | 57 371.125 | 87 293.190 | 83 218.250 | 4 839.938 | 2 614.570 | 2 321.688 | 237 658.800 |


													Table 3
Matrix of area convertible rate between main land use types in Guangxi during 2006—2013"
| 类型Types | 面积转移率Convertible rate of area(%) | ||||
| 林地Forest | 草地Grassland | 农用地Agricultural land | 水域Waters | ||
| 林地Forest | — | 11.356 | 7.256 | 1.241 | |
| 草地Grassland | 2.275 | — | 10.858 | 0.324 | |
| 农用地Agricultural land | 0.380 | 4.773 | — | 0.071 | |
| 水域Waters | 0.065 | 0.125 | 0.096 | — | |
| 白淑英, 王莉, 史建桥, 等.  长江流域NDVI对气候变化响应的时滞效应. 中国农业气象, 2012. 33 (4): 579- 586. doi: 10.3969/j.issn.1000-6362.2012.04.016 | |
| Bai S Y ,  Wang L ,  Shi J Q , et al.  Time lag effect of NDVI response to climatic change in Yangtze River basin. Chinese Journal of Agrometeorology, 2012. 33 (4): 579- 586. doi: 10.3969/j.issn.1000-6362.2012.04.016 | |
| 陈燕丽, 黄敏堂, 莫伟华, 等. 基于MODIS NDVI的广西西南典型生态区植被变化对比监测. 气象科学, 2015. 35 (1): 93- 99. | |
| Chen Y L , Huang M T , Mo W H , et al. Vegetation variation in typical ecological sections of southwest Guangxi based on MODIS NDVI data. Journal of the Meteorological Sciences, 2015. 35 (1): 93- 99. | |
| 丁明军, 张镱锂, 刘林山, 等.  1982-2009年青藏高原草地覆盖度时空变化特征. 自然资源学报, 2010. 25 (12): 2114- 2122. doi: 10.11849/zrzyxb.2010.12.012 | |
| Ding M J ,  Zhang Y L ,  Liu L S , et al.  Temporal and spatial distribution of grassland coverage change in Tibetan Plateau since 1982 to 2010. Journal of Natural Resources, 2010. 25 (12): 2114- 2122. doi: 10.11849/zrzyxb.2010.12.012 | |
| 刘世梁, 董玉红, 安南南, 等. 基于增强型植被指数序列和景观格局分析的松嫩平原盐碱地动态——以大安市为例. 应用生态学报, 2014. 25 (11): 3263- 3269. | |
| Liu S L , Dong Y H , An N N , et al. Dynamics of salinization land based on EVI series data and landscape pattern analysis in Songnen Plain:a case study in Da'an City. Chinese Journal of Applied Ecology, 2014. 25 (11): 3263- 3269. | |
| 马明国, 王建, 王雪梅. 基于遥感的植被年际变化及其与气候关系研究进展. 遥感学报, 2006. 10 (3): 421- 431. | |
| Ma G M , Wang J , Wang X M . Advance in the inter-annual variability of vegetation and its relation to climate based on remote sensing. Journal of Remote Sensing, 2006. 10 (3): 421- 431. | |
| 潘蔷, 范文义, 于海群, 等. 北京市植被指数变化与影响因素分析. 北京林业大学学报, 2012. 34 (2): 26- 33. | |
| Pan Q , Fan W Y , Yu H Q , et al. Temporal and spatial variation of normalized difference vegetation index and its influencing factors in Beijing. Journal of Beijing Forestry University, 2012. 34 (2): 26- 33. | |
| 沈斌, 房世波, 余卫国. NDVI与气候因子关系在不同时间尺度上的结果差异. 遥感学报, 2016. 20 (3): 481- 490. | |
| Shen B , Fang S B , Yu W G . Different correlations between NDVI and meteorological factors at temporal-time scales. Journal of Remote Sensing, 2016. 20 (3): 481- 490. | |
| 宋富强, 邢开雄, 刘阳, 等. 基于MODIS/NDVI的陕北地区植被动态监测与评价. 生态学报, 2011. 31 (2): 354- 363. | |
| Song F Q , Xing K X , Liu Y , et al. Monitoring and assessment of vegetation variation in Northern Shaanxi based on MODIS/NDVI. Acta Ecologica Sinica, 2011. 31 (2): 354- 363. | |
| 田海静, 曹春香, 戴晟懋, 等. 准格尔旗植被覆盖度变化的时间序列遥感监测. 地球信息科学学报, 2014. 16 (1): 126- 133. | |
| Tian H J , Cao C X , Dai S M , et al. Analysis of vegetation fractional cover in Jungar Banner based on time-series remote sensing data. Journal of Geo-Information Science, 2014. 16 (1): 126- 133. | |
| 温远光, 李治基, 李信贤, 等.  广西植被类型及其分类系统. 广西科学, 2014. (5): 484- 513. doi: 10.3969/j.issn.1005-9164.2014.05.008 | |
| Wen Y G ,  Li Z J ,  Li X X , et al.  Types of vegetation and its classified system in Guangxi. Guangxi Sciences, 2014. (5): 484- 513. doi: 10.3969/j.issn.1005-9164.2014.05.008 | |
| 叶铎, 吴溪玭, 罗应华, 等.  广西植被资源保护现状与策略. 广西科学, 2014. (5): 514- 524. doi: 10.3969/j.issn.1005-9164.2014.05.009 | |
| Ye D ,  Wu X P ,  Luo Y H , et al.  The current status and protection way of Guangxi Vegetation resource, south China. Guangxi Sciences, 2014. (5): 514- 524. doi: 10.3969/j.issn.1005-9164.2014.05.009 | |
| 杨小兰, 曾春阳, 文娟, 等. 基于9号超强台风"威马逊"灾害谈广西沿海防护林建设. 防护林科技, 2015. (7): 65- 67. | |
| Yang X L , Zeng C Y , Wen J , et al. Discussion on the construction of coastal protective forests in Guangxi based on the No.9 super typhoon "Weimason" disaster. Protection Forest Science and Technology, 2015. (7): 65- 67. | |
| 喻素芳, 佘光辉, 罗叶红, 等. 基于MODIS NDVI数据广西植被覆盖变化特征分析. 湖北农业科学, 2015. 54 (2): 321- 325. | |
| Yu S F , She G H , Luo Y H , et al. Analysis of characteristics of vegetation cover change in Guangxi Province based on MODIS NDVI. Hubei Agricultural Sciences, 2015. 54 (2): 321- 325. | |
| 周定文, 范广洲, 华维, 等.  我国春季降水与青藏高原东南部冬季归一化植被指数变化的关系. 大气科学, 2009. 33 (3): 649- 656. doi: 10.3878/j.issn.1006-9895.2009.03.20 | |
| Zhou D W ,  Fan G Z ,  Hua W , et al.  Relationship between spring rainfall in China and winter normalized difference vegetation index in the southeast of Tibetan Plateau. Chinese Journal of Atmospheric Sciences, 2009. 33 (3): 649- 656. doi: 10.3878/j.issn.1006-9895.2009.03.20 | |
| 张含玉, 方怒放, 史志华. 黄土高原植被覆盖时空变化及其对气候因子的响应. 生态学报, 2016. 36 (13): 3960- 3968. | |
| Zhang H Y , Fang N F , Shi Z H . Spatial-temporal patterns for the NDVI and its responses to climatic factors in the Loess Plateau, China. Acta Ecologica Sinica, 2016. 36 (13): 3960- 3968. | |
| Adams J B ,  Sabol D E ,  Kapos V , et al.  Classification of multispectral images based on fractions of endmembers:application to land-cover change in the Brazilian Amazon. Remote Sensing of Environment, 1995. 52 (2): 137- 154. doi: 10.1016/0034-4257(94)00098-8 | |
| Fensholt R , Proud S R . Evaluation of earth observation based global long term vegetation trends-comparing GIMMS and MODIS global NDVI time series. Remote Sensing of Environment, 2012. 119 (3): 131- 147. | |
| Gu J ,  Li X ,  Huang C , et al.  A simplified data assimilation method for reconstructing time-series MODIS NDVI data. Advances in Space Research, 2009. 44 (4): 501- 509. doi: 10.1016/j.asr.2009.05.009 | |
| Hester D B ,  Nelson S A C ,  Cakir H I , et al.  High-resolution land cover change detection based on fuzzy uncertainty analysis and change reasoning. International Journal of Remote Sensing, 2010. 31 (2): 455- 475. doi: 10.1080/01431160902893493 | |
| Jeong S J , Ho C H , Brown M E , et al. Browning in desert boundaries in Asia in recent decades. Journal of Geophysical Research Atmospheres, 2011. 116 (D2) | |
| Julien Y ,  Sobrino J A .  Global land surface phenology trends from gimms database. International Journal of Remote Sensing, 2009. 30 (13): 3495- 3513. doi: 10.1080/01431160802562255 | |
| Lambin E F ,  Strahler A H .  Indicators of land-cover change for change-vector analysis in multi-temporal space at coarse spatial scales. International Journal of Remote Sensing, 1994. 15 (10): 2099- 2119. doi: 10.1080/01431169408954230 | |
| Linderholm H W , Walther A , Chen D . Twentieth-century trends in the thermal growing season in the Greater Baltic area. Climatic Change, 2008. 87 (3/4): 405- 419. | |
| Liu Y ,  Li Y ,  Li S C , et al.  Spatial and temporal patterns of global NDVI trends:correlations with climate and human factors. Remote Sensing, 2015. 7 (10): 13233- 13250. doi: 10.3390/rs71013233 | |
| Lunetta R S ,  Knight J F ,  Ediriwickrema J .  Land-cover characterization and change detection using multi-temporal MODIS NDVI data. Remote Sensing of Environment, 2006. 105 (2): 142- 154. doi: 10.1016/j.rse.2006.06.018 | |
| Piao S L ,  Fang J ,  Ji W , et al.  Variation in a satellite-based vegetation index in relation to climate in China. Journal of Vegetation Science, 2004. 15 (2): 219- 226. doi: 10.1658/1100-9233(2004)015[0219:VIASVI]2.0.CO;2 | |
| Skakun S ,  Franch B ,  Vermote E , et al.  Early season large-area winter crop mapping using MODIS NDVI data, growing degree days information and a Gaussian mixture model. Remote Sensing of Environment, 2017. 195, 244- 258. doi: 10.1016/j.rse.2017.04.026 | |
| Stow D ,  Daeschner S ,  Hope A , et al.  Variability of the seasonally integrated normalized difference vegetation index across the north slope of Alaska in the 1990s. International Journal of Remote Sensing, 2003. 24 (5): 1111- 1117. doi: 10.1080/0143116021000020144 | |
| Zhao M ,  Running S W .  Drought-induced reduction in global terrestrial net primary production from 2000 through 2009. Science, 2010. 329 (5994): 940. doi: 10.1126/science.1192666 |
