与林内小气候舒适度相关的城市森林冠层结构指数选择

doi:10.11707/j.1001-7488.20200204

摘要/Abstract

摘要：

目的: 选择与林内小气候舒适度相关的城市森林冠层结构指数，为进一步优化城市森林结构、改善城市森林热环境提供参考。方法: 以与城市森林降温效应相关度较高的一维度冠层结构指标（包括叶面积指数、平均叶倾角、冠层厚度、枝下高、冠高比和冠层通透度）为基础，从林内外空气流动和能量交换的角度，构建多维度城市森林冠层结构指数，通过相关分析筛选对小气候舒适度解释度较高的城市森林冠层结构指数。结果: 一维度冠层结构指标与林内舒适度（S）、舒适度相对变化（S_d）呈弱度相关关系，对S的解释力为0~30.5%，对S_d的解释力为0~53.5%；多维度冠层结构指数对S和S_d的解释程度明显提升，对S的解释力为0~37.5%，对S_d的解释力为30.9%~55.1%；热垂直扩散结构指数和热水平扩散结构指数的协同作用对S的解释程度相对较高（43.5%）；垂直冠层指数和树冠垂直均匀指数的协同作用对S_d的解释程度最高（63.9%）。结论: 城市森林舒适度和舒适度相对变化受多个冠层结构指标和指数共同影响，所构建的多维度冠层结构指数（包括热垂直扩散结构指数、热水平扩散结构指数、综合热扩散结构指数、垂直冠层指数、树冠均匀指数、树冠垂直均匀指数和冠层综合指数）与林内小气候舒适度及其相对变化相关性较高。

关键词: 城市森林, 降温效应, 舒适度, 冠层结构, 叶面积指数

Abstract:

Objective: In order tooptimizethe structure of the urban forestsand to improve thermal environment, canopy structure indices related to comfort of microclimate were constructed and screened. Method: One dimension canopy structure indicators(including leaf area index, mean tilt angle of leat, canopy thickness, under branch height, ratio of canopy thickness to tree height, and the permeability of the canopy), highly correlatedwith urban forest cooling effect, were selected to construct multidimensional canopy structure indices on the basis of both air flow and energy exchange in and out of the forests. Furthermore, correlation analysis was used to select canopy structure indices with high explanation to the microclimate comfort in the forests. Result: The one dimension canopy structure indicators were weakly correlated with the comfort degree in the forest (S) and the relative variationin comfort (S_d), whose explanatory power to S was between 0 and 30.5%and the explanatory power to S_d was between 0 and 53.5%; The multidimensional canopy structure indices significantly improved the interpretation to S and S_d, which were 0 to 37.5%and 30.9% to 55.1% respectively; The synergistic effect on S of the structure index for vertical heat diffuse and the structure index for horizonta heat diffuse was 43.5% relatively large. The synergistic effect on S_d of the vertical canopy index and the canopy vertical evenness index was 63.9%, the highest, among others. Conclusion: The comfort and the relative variationin comfortin urban forests are influenced by several structureindicators and indices jointly. The multidimensional canopy structure indices (including structure index for vertica heat diffuse, structure index for horizontal heat diffuse, comprehensive structure index for heat diffuse, vertical canopy index, canopy uniformity index, canopy vertical evenness index and comprehensive canopy index), constructed in this paper are highly correlated with comfort degree and its relative variation, providing a reference for the optimization of urban forest structure.

Key words: urban forest, cooling effect, degree of comfort, canopy structure, leaf area index

中图分类号:

S718.51

刘海轩,吴鞠,许丽娟,徐程扬. 与林内小气候舒适度相关的城市森林冠层结构指数选择[J]. 林业科学, 2020, 56(2): 32-39.

Haixuan Liu,Ju Wu,Lijuan Xu,Chengyang Xu. Selection of Canopy Structure Index of Urban Forest Associated with Comfort Degree of Microclimate Within the Forest[J]. Scientia Silvae Sinicae, 2020, 56(2): 32-39.

图/表 7

表1

表2

表3

表4

图1

图2

图3

参考文献 0

	高美蓉, 贾宝全, 王成, 等. 厦门本岛城市森林树冠覆盖与热岛效应关系. 林业科学, 2014. 50 (3): 63- 68.
	Gao M R , Jia B Q , Wang C , et al. Relationship between urban forest canopy cover and heat island effect in Xiamen Island. Scientia Silvae Sinicae, 2014. 50 (3): 63- 68.
	黄良美, 黄玉源, 黎桦, 等. 南宁市植物群落结构特征与局地小气候效应关系分析. 广西植物, 2008. 28 (2): 211- 217. doi: 10.3969/j.issn.1000-3142.2008.02.014
	Huang L M , Huang Y Y , Li H , et al. Analysis on the relation between the structural characteristics of plant communities and the microclimate effects in Nanning City, China. Guihaia, 2008. 28 (2): 211- 217. doi: 10.3969/j.issn.1000-3142.2008.02.014
	贾宝全, 马明娟. 辽宁抚顺近10年来市域热场与植被变化分析. 遥感技术与应用, 2012. 27 (2): 256- 264.
	Jia B Q , Ma M J . The variation analysis of surface heat status and vegetation index of Fushun city in recent 10 years. Remote Sensing Technology and Application, 2012. 27 (2): 256- 364.
	贾宝全, 仇宽彪. 北京市平原百万亩大造林工程降温效应及其价值的遥感分析. 生态学报, 2016. 37 (3): 726- 735.
	Jia B Q , Qiu K B . The cooling effect of plain afforestation in the Beijing Project and its remote sensing-based valuation. Acta Ecologica Sinica, 2016. 37 (3): 726- 735.
	康满春. 2016.北方典型杨树人工林能量分配与碳水通量模拟.北京:北京林业大学博士学位论文, 50-54.
	Kang M C. 2016.Energy partitioning and modelling of carbon and water fluxes of a polar plantation ecosystem in northern China.Beijing: PhD thesis of Beijing Forestry University: 50-54.[in Chinese]
	蔺银顶, 韩学武, 武小刚, 等. 城市绿地空间结构对绿地生态场的影响. 生态学报, 2006. 26 (10): 3340- 3346.
	Lin Y D , Han X W , Wu X G , et al. Ecological field characteristic of green land based on urban green space structure. Acta Ecologica Sinica, 2006. 26 (10): 3340- 3346.
	刘海轩, 金桂香, 吴鞠, 等. 林分规模与结构对北京城市森林夏季温湿效应的影响. 北京林业大学学报, 2015. 37 (10): 31- 40.
	Liu H X , Jin G X , Wu J , et al. Effects of scale and structure of urban forest in lowering air temperature and increasing humidity in Beijing. Journal of Beijing Forestry University, 2015. 37 (10): 31- 40.
	潘建彬, 李树华. 北京城市公园绿地热舒适度空间格局特征研究. 中国园林, 2015. 31 (10): 91- 95. doi: 10.3969/j.issn.1000-6664.2015.10.018
	Pan J B , Li S H . Study on spatial pattern of the function of thermal comfort improvement on Beijing city parks. Chinese Landscape Architecture, 2015. 31 (10): 91- 95. doi: 10.3969/j.issn.1000-6664.2015.10.018
	彭保发, 石忆邵, 王贺封, 等. 城市热岛效应的影响机理及其作用规律:以上海市为例. 地理学报, 2013. 68 (11): 1461- 1471. doi: 10.11821/dlxb201311002
	Peng B F , Shi Y S , Wang H F , et al. The impacting mechanism and laws of function of urban heat islands effect:a case study of Shanghai. Acta Geographica Sinaca, 2013. 68 (11): 1461- 1471. doi: 10.11821/dlxb201311002
	齐石茗月. 2016.绿地对建筑外热环境特征及人体舒适度的影响.北京:北京林业大学硕士学位论文, 25-48.
	Qi S M Y. 2016. The influence of green space to external of buildings' thermal environmental characteristics and human comfort. Beijing: MS thesis of Beijing Forestry University, 25-48.[in Chinese]
	王昭燕. 2008.长江滩地抑螺防病林生态系统能量平衡与水汽通量研究.北京:中国林业科学研究院博士学位论文, 35-38.
	Wang Z Y. 2008. Energy balance and water vapor flux of snail control and schistosomiasis prevention forests ecosystem in Yangtze Rive Beach Land. Beijing: PhD thesis of Chinese Academy of Forestry, 35-38.[in Chinese]
	辛渝, 于晓晶, 陈洪武. 两种背景场改进方案对新疆"狭管"风区风场预报性能评估. 中国沙漠, 2015. 35 (4): 994- 1005.
	Xin Y , Yu X J , Chen H W . Verification of wind forecasts at funneling wind area in Xinjiang by two background field improving schemes. Journal of Desert Research, 2015. 35 (4): 994- 1005.
	杨德江, 荆平. 小区规划方案的大气流场模拟及环境影响分析. 环境科学与技术, 2008. 31 (9): 147- 150. doi: 10.3969/j.issn.1003-6504.2008.09.039
	Yang D J , Jing P . Analysis of air flow-field simulation and environmental impact for community planning scenario. Environmental Science & Technology, 2008. 31 (9): 147- 150. doi: 10.3969/j.issn.1003-6504.2008.09.039
	姚玉龙, 刘普幸, 陈丽丽. 基于遥感影像的合肥市热岛效应时空变化特征及成因. 生态学杂志, 2013. 32 (12): 3351- 3359.
	Yao Y L , Liu P X , Chen L L . Spatial-temporal variation characteristics and causes of urban heat islands in Hefei City, Anhui Province of China based on remote sensing. Chinese Journal of Ecology, 2013. 32 (12): 3351- 3359.
	应天玉, 李明泽, 范文义, 等. 基于GIS技术的城市森林与热岛效应的分析. 东北林业大学学报, 2010. 38 (8): 63- 67+101. doi: 10.3969/j.issn.1000-5382.2010.08.020
	Ying T Y , Li M Z , Fan W Y , et al. Analysis of urban forests and heat island effect based on GIS. Journal of Northeast Forestry University, 2010. 38 (8): 63- 67+101. doi: 10.3969/j.issn.1000-5382.2010.08.020
	苑征. 2011.北京部分绿地群落温湿度状况及对人体舒适度影响.北京:北京林业大学硕士学位论文, 70-78.
	Yuan Z. 2011. The research on the temperature and humidity condition and the comfort index in the plant communities of Beijing. Beijing: MS thesis of Beijing Forestry University, 70-78.[in Chinese]
	张雪松, 刘雅各, 胡正华, 等. 生态模型在农田蒸散及土壤水分模拟中的适用性评价. 生态学杂志, 2017. 36 (1): 267- 276.
	Zhang X S , Liu Y G , Hu Z H , et al. Evaluating the applicability of ecological model for simulating evapotranspiration and soil water content in winter wheat farmland. Chinese Journal of Ecology, 2017. 36 (1): 267- 276.
	赵慧颖, 田宝星, 宫丽娟, 等. 近308年来大兴安岭北部森林植被气候生产潜力及其对气候变化的响应. 生态学报, 2017. 37 (6): 1900- 1911.
	Zhao H Y , Tian B X , Gong L J , et al. Climate-induced potential productivity of forest vegetation during the past 308 years in northern Da Hinggan Mountain region, China. Acta Ecologica Sinica, 2017. 37 (6): 1911- 1911.
	Connors J P , Galletti C S , Chow W T L . Landscape configuration and urban heat island effects:assessing the relationship between landscape characteristics and land surface temperature in Phoenix, Arizona. Landscape Ecology, 2013. 28 (2): 271- 283. doi: 10.1007/s10980-012-9833-1
	Estoque R C , Murayama Y , Myint S W . Effects of landscape composition and pattern on land surface temperature:an urban heat island study in the megacities of Southeast Asia. Science of the Total Environment, 2017. 577 (1): 349- 359.
	Gkatsoploulos P . A methodology for calculating cooling from vegetation evapotranspiration for use in urban space microclimate simutations. Procedia Environmental Sciences, 2017. 38 (3): 477- 484.
	Klemma W , Heusinkveld B G , Lenzholzer S , et al. Street greenery and its physical and psychological impact on thermal comfort. Landscape and Urban Planning, 2015. 138 (6): 87- 98.
	Lin Y H , Tsai K T . Screening of tree species for improving outdoor human thermal comfort in a Taiwanese City. Sustainability, 2017. 9 (1): 340.
	Qin Z , Li Z D , Cheng F Y , et al. Influence of canopy structural characteristics on cooling and humidifying effects of Populus tomentosa community on calm sunny summer days. Landscape and Urban Planning, 2014. 127 (7): 75- 82.
	Rahman M A , Armson D , Ennos A R . A comparison of the growth and cooling effectiveness of five commonly planted urban tree species. Urban Ecosyst, 2015. 18 (2): 371- 389. doi: 10.1007/s11252-014-0407-7
	Taleghani M , Sailor D J , Tenpierik M , et al. Thermal assessment of heat mitigation strategies:the case of Portland State University, Oregon, USA. Building and Environment, 2014. 73 (3): 138- 150.
	Wang Y , Berardic U , Akbari H . Comparing the effects of urban heat island mitigation strategies for Toronto, Canada. Energy and Buildings, 2016. 114 (2): 2- 19.
	Wu Z , Chen L . Optimizing the spatial arrangement of trees in residential neighborhoods for better cooling effects:integrating modeling with in-situ measurements. Landscape and Urban Planning, 2017. 167 (11): 463- 472.

胸径范围 Range of DBH/cm	样地数量 Number of sample plots	平均树高 Mean tree height/m	平均冠层厚度 Mean canopy thickness/m	平均冠幅 Mean crown width/m	LAI
≤16.00	166	9.25±0.24	6.25±0.19	4.20±0.08	2.15±0.07
16.01~18.00	227	10.95±0.18	7.51±0.14	4.29±0.07	1.95±0.07
18.01~20.00	496	11.63±0.06	6.38±0.09	5.45±0.02	2.42±0.05
20.01~22.00	129	10.98±0.12	8.47±0.12	5.70±0.06	2.81±0.10
22.01~24.00	147	10.56±0.20	7.99±0.17	6.42±0.06	2.15±0.08
24.01~26.00	129	12.25±0.24	9.25±0.21	6.92±0.07	1.89±0.07
＞26.00	150	13.39±0.24	10.09±0.20	7.73±0.12	1.85±0.07

舒适度指标 Comfort index	一维度树冠结构指标 One dimension indicators of canopy structure	样地数量 Number of sample plots	Pearson相关性 Pearson correlation		线性回归 Linear regression
舒适度指标 Comfort index	一维度树冠结构指标 One dimension indicators of canopy structure	样地数量 Number of sample plots	相关系数 Correlation coefficient	P	斜率 Slope	截距 Intercept	R²
S	lg(LAI)	101	-0.309	0.002	-0.013	0.412	0.095
	lg(MTA)	101	0.455	＜0.001	0.042	1.174	0.207
	lg(CTH)	101	0.457	＜0.001	0.001	0.825	0.205
	lg(UBH)	101	0.552	＜0.001	0.013	0.364	0.305
	lg(RCT)	101	0.263	0.011	0.004	-0.203	0.067
	lg(PC)	101	0.066	0.226	—	—	—
S_d	lg(LAI)	82	-0.362	0.001	-0.189	0.319	0.172
	lg(MTA)	82	-0.008	0.871	—	—	—
	lg(CTH)	82	0.058	0.227	—	—	—
	lg(UBH)	82	0.082	0.085	—	—	—
	lg(RCT)	82	0.458	＜0.001	0.086	-0.14	0.21
	lg(PC)	82	0.732	＜0.001	1.181	1.201	0.535

舒适度指标 Comfort index	多维度树冠结构指数 Multidimensional indices of canopy structure	样地数量 Number of sample plots	Pearson相关性 Pearson correlation		线性回归 Linear regression
舒适度指标 Comfort index	多维度树冠结构指数 Multidimensional indices of canopy structure	样地数量 Number of sample plots	相关系数 Correlation coefficient	P	斜率 Slope	截距 Intercept	R²
S	lg(SIV)	101	0.421	＜0.001	0.04	0.027	0.177
	lg(SIH)	101	0.612	＜0.001	0.015	0.542	0.375
	lg(SIL)	101	-0.016	0.694	—	—	—
	lg(CSI)	101	0.48	＜0.001	0.05	0.604	0.231
S_d	lg(VCI)	82	0.556	＜0.001	0.356	-0.016	0.309
	lg(CU)	82	0.72	＜0.001	1.465	0.979	0.519
	lg(CVE)	82	0.756	＜0.001	1.257	1.43	0.572
	lg(CC)	82	0.743	＜0.001	1.587	1.246	0.551
