猕猴桃溃疡病生防菌群的构建及其生防效应

doi:10.11707/j.1001-7488.LYKX20230653

摘要/Abstract

摘要：

目的: 从猕猴桃本体分离获得生防细菌构建生防菌群，明确浙江临安猕猴桃溃疡病病原菌的类群，探究生防菌群的生防效应，为猕猴桃溃疡病的防治提供新思路。方法: 从浙江临安猕猴桃种植区分离溃疡病菌并鉴定；基于健康、发病猕猴桃枝条内生菌的宏基因组测序比较和R语言分析，以该病菌为靶标分离生防细菌，构建生防菌群；通过离体共培养和活体接种试验，验证菌群的生防效应。结果: 1）浙江临安的猕猴桃溃疡病由丁香假单胞菌猕猴桃致病变种HY-05引起。枝条内生菌的宏基因组测序结果表明，与发病的猕猴桃植株相比，健康的猕猴桃枝条内部细菌群落之间更易形成积极的互作关系。2）基于R语言分析，从猕猴桃健康植株分离获得病原菌HY-05的拮抗菌株红树林动球菌ZC-3和蒙氏肠球菌ZC-5，以及ZC-3的益生菌嗜根寡养单胞菌ZC-6，构建成生防菌群。3）离体共培养试验结果表明，各供试菌株均能抑制菌株HY-05的生长，其中以ZC-3、ZC-5和ZC-6构建的生防菌群效果最佳，抑制率达100%；植株活体试验中，添加各生防菌组合的处理均可不同程度抑制猕猴桃溃疡病的发生，其中以ZC-3、ZC-5和ZC-6构建的生防菌群处理效果最佳，防治效果达56.00%，与发病对照相比差异极显著（P<0.01）。结论: 发生自浙江临安的猕猴桃溃疡病由丁香假单胞菌猕猴桃致病变种引起，从猕猴桃植株内分离获得的生防菌株构建的生防菌群经离体和活体实验证实具有实际生防效应。

关键词: 猕猴桃溃疡病, 宏基因组测序, R语言, 生防菌, 菌群构建, 生防效应

Abstract:

Objective: In this study, biocontrol bacteria were isolated from kiwifruit and used for construction of biocontrol bacterial community. The pathogen of kiwifruit bacterial canker was identified in Lin'an, Zhejiang Province. This study aims to explore the biocontrol effect of the bacterial community on the pathogen of kiwifruit bacterial canker, so as to provide new insights for the prevention and control of kiwifruit bacterial canker. Method: The pathogenic bacteria causing canker disease of kiwifruit were isolated from kiwifruit planting areas in Lin'an, Zhejiang Province and identified. Based on the comparison and analysis of the metagenomes of endophytic bacteria in healthy and diseased kiwifruit branches using R language, antagonistic bacteria against the pathogenic bacteria were isolated, and a biocontrol bacterial community was constructed. The biocontrol effect of the bacterial community on the pathogenic bacteria was validated through in vitro co-cultivation and in vivo inoculation experiments. Result: 1) Kiwifruit bacterial canker in Lin'an, Zhejiang Province was caused by Pseudomonas syringae pv. actinidiae HY-05. The metagenomic sequencing results of endophytic bacteria in kiwifruit branches showed that positive interactions were more likely to form among the bacterial communities in healthy kiwifruit branches compared to diseased ones. 2) Based on R language analysis, antagonistic strains, Kineococcus mangrovi ZC-3 and Enterococcus mundtii ZC-5, against the pathogenic strain HY-05, as well as a probiotic strain, Stenotrophomonas rhizophila ZC-6, were isolated from healthy kiwifruit plants, and a biocontrol bacterial community was constructed. 3) In the in vitro co-cultivation experiment, all tested strains inhibited the growth of HY-05, with the biocontrol bacterial community constructed by ZC-3, ZC-5, and ZC-6 showing the best inhibitory effect, with a suppression rate of 100%. In the in vivo plant experiment, treatments with different biocontrol bacterial combinations were able to inhibit the occurrence of kiwifruit bacterial canker to varying degrees, with the biocontrol bacterial community constructed by ZC-3, ZC-5, and ZC-6 showing the best preventive effect, with a control efficiency of 56.00%, which was significantly different from the diseased control (P<0.01). Conclusion: Kiwifruit bacterial canker in Lin'an, Zhejiang Province is caused by P. syringae pv. actinidiae. The biocontrol bacterial community constructed from beneficial bacteria isolated from kiwifruit plants is proven to have practical biocontrol effects through in vitro and in vivo experiments. This study enriches the research system of biological control of bacterial canker in kiwifruit from a theoretical perspective, and the biocontrol bacterial community obtained can be used for precise prevention and control of kiwifruit bacterial canker, which is of practical significance for the development of the kiwifruit industry.

Key words: kiwifruit bacterial canker, metagenomic sequencing, R language, biocontrol bacteria, bacterial community construction, biocontrol effect

中图分类号:

S718.43

尹志诚,顾佳颖,李南羿,张昕. 猕猴桃溃疡病生防菌群的构建及其生防效应[J]. 林业科学, 2024, 60(12): 101-110.

Zhicheng Yin,Jiaying Gu,Nanyi Li,Xin Zhang. Construction and Control Effect of Biocontrol Flora of Kiwifruit Bacterial Canker[J]. Scientia Silvae Sinicae, 2024, 60(12): 101-110.

图/表 11

表1

图1

图2

图3

图4

图5

图6

表2

图7

图8

表3

参考文献 0

	高小宁, 赵志博, 黄其玲, 等. 猕猴桃细菌性溃疡病研究进展. 果树学报, 2012, 29 (2): 262- 268.
	Gao X N, Zhao Z B, Huang Q L, et al. Advances in research on bacterial canker of kiwifruit. Journal of Fruit Science, 2012, 29 (2): 262- 268.
	胡施祺, 戴德江, 罗金燕, 等. 猕猴桃溃疡病病菌的多样性及其检测技术. 浙江农业科学, 2022, 63 (11): 2652- 2657.
	Hu S Q, Dai D J, Luo J Y, et al. Analysis of diversity and detection technology of kiwifruit bacterial canker pathogen. Journal of Zhejiang Agricultural Sciences, 2022, 63 (11): 2652- 2657.
	刘　颖. 2023. 嗜根寡养单胞菌DSF群体感应调控机制的研究. 北京: 中国科学技术大学.
	Liu Y. 2023. Regulatory mechanisms for DSF quorum sensing of Stenotrophomonas rhizophila. Beijing: University of Science and Technology of China. ［in Chinese］
	骆焱平, 王兰英. 2019. 内生菌研究方法. 北京: 化学工业出版社, 35.
	Luo Y P, Wang L Y. 2019. Research methods of endophytes. Beijing: Chemical Industry Press, 35. ［in Chinese］
	祁香宁, 程延静, 曹格妮. 我国猕猴桃产品开发和未来发展建议. 农村科学实验, 2022, (15): 3. doi: 10.3969/j.issn.2096-0743.2022.15.nckxsy202215033
	Qi X N, Cheng Y J, Cao G N. Kiwifruit product development in China and suggestions for the development in the future. Rural Scientific Experiment, 2022, (15): 3. doi: 10.3969/j.issn.2096-0743.2022.15.nckxsy202215033
	宋光桃, 付美云, 张惠颖, 等. 5种植物内生菌的分离及其拮抗月季黑斑病菌的筛选. 湖南生态科学学报, 2021, 8 (4): 59- 64. doi: 10.3969/j.issn.2095-7300.2021.04.009
	Song G T, Fu M Y, Zhang H Y, et al. Isolation of endophytes from 5 plants and screening of their antagonistic strains to Rose black spot disease. Journal of Hunan Ecological Science, 2021, 8 (4): 59- 64. doi: 10.3969/j.issn.2095-7300.2021.04.009
	盛存波, 安德荣, 鲁燕汶, 等. 生防菌株B56-3防治猕猴桃溃疡病的初步研究. 西北农业学报, 2006, (3): 75- 78. doi: 10.3969/j.issn.1004-1389.2006.03.017
	Sheng C B, An D R, Lu Y R, et al. Study on control effect of kiwifruit bacterial canker by bio-control strain B56-3. Acta Agriculturae Boreali-Occidentalis Sinica, 2006, (3): 75- 78. doi: 10.3969/j.issn.1004-1389.2006.03.017
	田雪莲, 尹显慧, 龙友华, 等. 猕猴桃溃疡病菌拮抗菌筛选、鉴定及发酵条件优化. 食品科学, 2017, 38 (16): 79- 85. doi: 10.7506/spkx1002-6630-201716012
	Tian X L, Yin X H, Long Y H, et al. Screening, identification and optimization of fermentation conditions for antagonistic actinomycetes against Pseudomonas syringae pv. actinidiae. Food Science, 2017, 38 (16): 79- 85. doi: 10.7506/spkx1002-6630-201716012
	王　丽, 周增强, 侯　珲, 等. 我国猕猴桃细菌性溃疡病研究分析及防控. 中国南方果树, 2017, 46 (2): 178- 182.
	Wang L, Zhou Z Q, Hou H, et al. Research and analysis on bacterial canker of kiwifruit in China and its prevention and control. South China Fruits, 2017, 46 (2): 178- 182.
	王朱珺, 王　尚, 刘洋荧, 等. 宏基因组技术在氮循环功能微生物分子检测研究中的应用. 生物技术通报, 2018, 34 (1): 1- 14.
	Wang Z J, Wang S, Liu Y Y, et al. The applications of metagenomics in the detection of environmental microbes involving in nitrogen cycle. Biotechnology Bulletin, 2018, 34 (1): 1- 14.
	王文正, 宋立国, 王　钱, 等. 2024. 江西九龙山铁尾矿区3种树木对土壤重金属质量分数及微生物群落组成的影响. 林业科学, 60（3）: 76-86.
	Wang W Z, Song L G, Wang Q, et al. 2024. Effects of three kinds of trees on soil heavy metal mass fraction and microbial community composition in the iron tailing area of Jiulong, Jiangxi. Scientia Silvae Sinicae, 60(3): 76-86. ［in Chinese］
	杨若兰. 2022. 猕猴桃细菌性溃疡病生防菌筛选及其菌剂制备. 杨凌: 西北农林科技大学.
	Yang R L. 2022. Screening of biocontrol microbe and agent preparation on kiwifruit bacterial canker. Yangling: Northwest A&F University. ［in Chinese］
	杨　睿, 汪琳罗沙, 姚　迪, 等. 湘西地区猕猴桃溃疡病病原菌分离及其全基因组分析. 微生物学杂志, 2024, 44 (1): 58- 67.
	Yang R, Wang L L S, Yao D, et al. Isolation of kiwifruit canker pathogen in western Hunan and whole genome sequencing analysis of its pathogenic mechanism. Journal of Microbiology, 2024, 44 (1): 58- 67.
	燕金宜. 2013. 猕猴桃溃疡病鉴定及内生拮抗真菌的筛选. 成都: 四川农业大学.
	Yan J Y. 2013. Isolation and identification of the causal pathogens for kiwifruit bacterial canker and the antagonistic endophytic fungi from kiwifruit in Sichuan, China. Chengdu: Sichuan Agriculturak University. ［in Chinese］
	钟曼茜, 翟舒嘉, 刘　伟, 等. 我国即食猕猴桃产业发展现状、问题与对策. 中国果树, 2023, (2): 122- 127.
	Zhong M X, Zhai S J, Liu W, et al. Current situation, problems and countermeasures of the development of ready-to-eat kiwifruit industry in China. China Fruits, 2023, (2): 122- 127.
	钟铭照. 2022. 和平县猕猴桃溃疡病病原菌鉴定与防治药剂筛选. 广州: 仲恺农业工程学院.
	Zhong M Z. 2022. Pathogen identification of kiwifruit bacterial canker in Heping county and its control agents screening. Guangzhou: Zhongkai University of Agriculture and Engineering. ［in Chinese］
	张继明, 邱　琳, 李红娟. 宝鸡市猕猴桃溃疡病发生规律及防治对策. 中国农村小康科技, 2008, (9): 54- 56.
	Zhang J M, Qiu L, Li H J. The occurrence pattern of bacterial canker of kiwifruit and its control countermeasures in Baoji. Journal of Agriculture, 2008, (9): 54- 56.
	张文娟. 猕猴桃溃疡病拮抗菌株筛选及田间药效试验. 陕西农业科学, 2020, 66 (5): 36- 38，43. doi: 10.3969/j.issn.0488-5368.2020.05.009
	Zhang W J. Screening of Antagonistic Strain of Kiwifruit Bacterial Canker and Field Test of Pesticide Effectiveness. Shaanxi Journal of Agricultural Sciences, 2020, 66 (5): 36- 38，43. doi: 10.3969/j.issn.0488-5368.2020.05.009
	朱海云, 马　瑜, 柯　杨, 等. 猕猴桃细菌性溃疡病生防菌的筛选、鉴定及其防效初探. 微生物学杂志, 2016, 36 (5): 90- 96.
	Zhu H Y, Ma Y, Ke Y, et al. Screening, Identification and controlling effects of biocontrol strain against Chinese gooseberry of kiwifruit bacterial canker. Journal of Microbiology, 2016, 36 (5): 90- 96.
	朱海云, 马　瑜, 柯　杨, 等. 猕猴桃溃疡病菌拮抗菌的筛选、鉴定及其对植物病原真菌的抗性. 生物技术通报, 2021, 37 (6): 66- 72.
	Zhu H Y, Ma Y, Ke Y, et al. Screening and identification of an antagonist against the pathogen of kiwifruit canker and its antifungal activity to the phytopathogenic fungus. Biotechnology Bulletin, 2021, 37 (6): 66- 72.
	朱加虹, 刘　岩, 潘明正, 等. 浙江省猕猴桃产业高质量发展探索与思考. 农产品质量与安全, 2023, (3): 97- 100. doi: 10.3969/j.issn.1674-8255.2023.03.017
	Zhu J H, Liu Y, Pan M Z, et al. Exploration and thoughts about high quality development of kiwifruit industry in Zhejiang Province. Quality and Safety of Agro-Products, 2023, (3): 97- 100. doi: 10.3969/j.issn.1674-8255.2023.03.017
	Aysenur F, Serpil U. 2023. First isolation of a probiotic candidate Enterococcus mundtii from Herniaria glabra L. and evaluation of its wound healing activity. FEMS Microbiology letters: 370.
	Bano S, Scrimgeour F. The export growth and revealed comparative advantage of the New Zealand kiwifruit industry. International Business Research, 2012, 5 (2): 73.
	Camargos L P F, Demetra S, Ferreira F S D, et al. An integrative view of the phyllosphere mycobiome of native rubber trees in the Brazilian Amazon. Journal of Fungi, 2022, 8 (4): 373.
	Chand K K, Poonam S, Sharon N, et al. Dual microbial inoculation, a game changer? – Bacterial biostimulants with multifunctional growth promoting traits to mitigate salinity stress in spring mungbean. Frontiers in Microbiology, 2021, 11, 600576.
	Cheng D D, Tian Z S, Feng L, et al. Diversity analysis of the rhizospheric and endophytic bacterial communities of Senecio vulgaris L. (Asteraceae) in an invasive range. PeerJ, 2019, 6, e6162.
	Egamberdieva D, Eshboev F, Shukurov O, et al. Bacterial bioprotectants: biocontrol traits and induced resistance to phytopathogens. Microbiology Research, 2023, 14 (2): 689- 703.
	Kannika D, Supattra M, Ratchanee M, et al. Kineococcus mangrovi sp. nov., isolated from mangrove sediment. International Journal of Systematic and Evolutionary Microbiology, 2016, 66 (3): 1230- 1235.
	Lu Q, Liu Y Y, Yan F H, et al. First report of Pectobacterium carotovorum subsp. actinidiae causing summer canker on kiwifruit in Zhejiang province of China. Plant Disease, 2020, 104 (2): 561.
	Mcatee P A, Lara B, Ben C, et al. Re-programming of Pseudomonas syringae pv. actinidiae gene expression during early stages of infection of kiwifruit. BMC genomics, 2018, 19 (1): 822.
	Mintoo N M, Mishra S, Dantu K P. Isolation and characterization of endophytic bacteria from Piper longum. Proceedings of the National Academy of Sciences, India Section B: Biological Sciences, 2019, 89 (4): 1447- 1454.
	Reyes-Perez J J, Hernandez-Montiel L G, Vero S, et al. Postharvest biocontrol of Colletotrichum gloeosporioides on mango using the marine bacterium Stenotrophomonas rhizophila and its possible mechanisms of action. Journal of Food Science and Technology, 2019, 56 (11): 4992- 4999.
	Shahzad M, Yongmei L, Pengbo H, et al. Defeating huanglongbing pathogen candidatus Liberibacter asiaticus with indigenous citrus endophyte Bacillus subtilis L1-21. Frontiers in Plant Science, 2021, 12, 789065.
	Shao X L, Wu Q H, Li L, et al. Adapting the inoculation methods of kiwifruit canker disease to identify efficient biocontrol bacteria from branch microbiome. Molecular Plant Pathology, 2023, 25 (1): e13399.
	Tomas R, Bernardo M, J. J R, et al. Debaryomyces hansenii, Stenotrophomonas rhizophila, and ulvan as biocontrol agents of fruit rot disease in muskmelon (Cucumis melo L. ). Plants, 2022, 11 (2): 184- 184.
	Wang N N, Han N, Tian R Z, et al. Role of the type VI secretion system in the pathogenicity of Pseudomonas syringae pv. actinidiae, the causative agent of kiwifruit bacterial canker. Frontiers in Microbiology, 2021, 12, 627785. doi: 10.3389/fmicb.2021.627785
	Wicaksono W A, Jones E E, Casonato S, et al. Biological control of Pseudomonas syringae pv. actinidiae(Psa), the causal agent of bacterial canker of kiwifruit, using endophytic bacteria recovered from a medicinal plant. Biological Control, 2018, 116, 103- 112. doi: 10.1016/j.biocontrol.2017.03.003
	Yan H, Yein J T, Huiyu X, et al. 2023. A metagenomic survey of wood decay fungi in the urban trees of singapore. Journal of Fungi (Basel, Switzerland), 9(4): 460.
	Zhang Z K, Zhang W X, Wang X F, et al. Isolation and identification of antagonistic bacteria of Angelica root rot and their mechanism as biological control. Biological Control, 2023, 177, 150120.

级别 Degree	代表值 Representative value	分级标准 Classified standard
Ⅰ	0	接种部位未出现病斑或伤口完全愈合 No lesions appear at the vaccination site or the wound is completely healed
Ⅱ	1	接种部位出现较浅褐色病斑，病斑面积<0.1 cm² Light brown lesions appear at the inoculation site, lesion area<0.1 cm²
Ⅲ	2	接种部位出现褐色病斑， 0.1 cm²≤ 病斑面积<0.2 cm² Brown lesions appear at the inoculation site, 0.1 cm²≤lesion area<0.2 cm²
Ⅳ	3	接种部位出现深褐色病斑， 0.2 cm²≤ 病斑面积<0.3 cm² Dark brown lesions appear at the inoculation site, 0.2 cm²≤lesion area<0.3 cm²
Ⅴ	4	接种部位出现锈红色病斑，病部凹陷， 0.3 cm²≤病斑面积 Rust-red lesions appear at the inoculation site, lesion area is sunken, 0.3 cm²≤lesion area

菌株编号 Strain code	菌落形态 Colony morphology	革兰氏染色反应 Gram stain reaction	氧化酶反应 Oxidase reaction	过氧化氢酶反应 Catalase reaction
ZC-3	菌落扁平，边缘不规则，中间白，外圈呈半透明雪花状，透明圈大，菌落整体呈淡粉色。 Colonies flattened, irregular edge, white in the middle, translucent snowflake-like outer ring, large transparent circle, overall pale pink color of the colony.	+	?	+
ZC-5	菌落扁平，边缘规则，圆形，中间白色，边缘呈半透明状。 Colonies flattened, with regular, rounded edges, white in the center, with translucent edges.	+	?	?
ZC-6	菌落凸起，边缘规则，圆形，质地黏稠，中间黄色，边缘呈乳黄色半透明状，透明圈较大。 Colonies are convex, with regular, rounded edges, thick texture, yellow in the middle, milky yellow translucent edges, and large transparent circles.	?	?	+

处理方法 Treatment	病情指数 Disease index (%)	防治效果 Prevention and control effect (%)	显著水平 Significance level
仅接种病原菌 Only pathogenic bacteria	78.13	—	A
接种病原菌与菌株ZC-5 Inoculation pathogen and strain ZC-5	62.50	20.01	A
接种病原菌与生防菌群 Inoculation pathogenic bacteria and biocontrol flora	34.38	56.00	B
