林业科学 ›› 2021, Vol. 57 ›› Issue (11): 59-67.doi: 10.11707/j.1001-7488.20211106

•   • 上一篇    下一篇

绣球染色体制片技术优化及rDNA物理定位

郭瑞红1,邱帅2,刘光欣1,高凯2,魏建芬2,席梦利1,*

  1. 1. 南京林业大学 林木遗传与生物技术教育部重点实验室 南京 210037
    2. 杭州市园林绿化股份有限公司 杭州 310020
  • 收稿日期:2021-06-19 出版日期:2021-11-25 发布日期:2022-01-12
  • 通讯作者: 席梦利
  • 基金资助:
    国家自然科学基金项目(31670603);上海市绿化和市容管理局科研项目(G212410);上海市科学技术委员会科研项目(19DZ1203503)

Optimization of Chromosome Preparation and rDNA Physical Localization of Hydrangea macrophylla

Ruihong Guo1,Shuai Qiu2,Guangxin Liu1,Kai Gao2,Jianfen Wei2,Mengli Xi1,*

  1. 1. Key Laboratory of Forest Genetics & Biotechnology of Ministry of Education Nanjing Forestry University Nanjing 210037
    2. Hangzhou Landscaping Incorporated Hangzhou 310020
  • Received:2021-06-19 Online:2021-11-25 Published:2022-01-12
  • Contact: Mengli Xi

摘要:

目的: 建立染色体形态良好、分裂相内染色体分散且无细胞质背景的绣球根尖高质量染色体制片技术,完善中期染色体45S rDNA和5S rDNA荧光原位杂交(FISH)技术体系,为深入开展绣球属植物分子细胞遗传学研究奠定基础。方法: 以绣球‘无尽夏’当年生半木质化枝条水培长出的幼嫩根尖为材料,分别采用1 MPa一氧化二氮(N2O)、0.7 mmol·L-1环己酰胺、2 mmol·L-1 8-羟基喹啉对根尖进行不同时间预处理。预处理后的根尖分生组织在4%纤维素酶和2%果胶酶混合酶液中酶解后进行染色体制片。以45S rDNA和5S rDNA为探针,对中期染色体进行原位杂交。结果: 1)1 MPa一氧化二氮预处理的材料中,预处理0.5 h,大部分中期分裂相染色体较长,浓缩不充分;预处理1 h,染色体浓缩适当,大部分染色体的着丝粒位置可辨;预处理2 h,染色体浓缩过度,呈点状。0.7 mmol·L-1环己酰胺预处理的材料中,预处理1 h和3 h,染色体偏长,浓缩不充分;预处理5 h,染色体浓缩适当,但着丝粒位置显示不明显。2 mmol·L-1 8-羟基喹啉预处理的材料中,2、4、6 h 3个时间梯度均可得到染色体浓缩适当的材料,各处理时间之间对染色体形态的影响差异并不明显,但着丝粒位置不可辨。综合考虑后认为,绣球根尖预处理的最适条件为1 MPa一氧化二氮预处理1 h。2)3个酶解时间梯度中,酶解0.5 h的染色体制片,中期分裂相和细胞核周围存在明显的细胞质残留;酶解1 h的染色体制片,中期分裂相背景干净、染色体分散程度好;酶解2 h的染色体制片,观察到很多不完整分裂相,分裂相间无法区分,染色体容易丢失。因此,绣球根尖分生组织在4%纤维素酶和2%果胶酶混合酶液中37℃酶解1 h比较合适。3)绣球‘无尽夏’是二倍体,染色体数目为36(2n=2x=36)。45S rDNA长、短探针的FISH效果相似,均产生很强的杂交信号,位点位于1对近端着丝粒染色体的短臂末端;5S rDNA长、短探针的FISH信号均较弱,长探针的检出率高于短探针,杂交信号位于1对端着丝粒染色体的长臂末端。结论: 成功建立绣球‘无尽夏’根尖高质量中期染色体制备及rDNA物理定位技术体系,该体系可高效确定绣球属植物的染色体数目及rDNA分布,为绣球属资源鉴定、杂交育种的亲本选配提供参考,从而指导绣球属植物的杂交育种实践。

关键词: 绣球, 染色体制片, rDNA, 荧光原位杂交(FISH)

Abstract:

Objective: The purpose of this study is to develop a technique for high quality chromosome preparation of root tips, in order to improve the fluorescence in situ hybridization(FISH) system for 45S rDNA and 5S rDNA of Hydrangea macrophylla 'Endless Summer' with dispersed and good morphology chromosomes in the cell division phase, which would provide a basis for improving the molecular cytogenetic study of Hydrangea. Method: Root tips taken from semi-lignified branches of H. macrophylla 'Endless Summer' through hydroponic culture were pre-treated with 1 MPa nitrous oxide, 0.7 mmol·L-1 cycloheximide and 2 mmol·L-1 8-hydroxyquinoline respectively. Chromosome was prepared after meristem enzymolysis of the pre-treated root tips with a mixture of 4% cellulase and 2% pectinase, and the metaphase chromosome was hybridized in situ with 45S rDNA and 5S rDNA probes. Result: 1) Materials pre-treated with 1 MPa nitrous oxide for 0.5 h, their chromosomes were still insufficiently condensed and too long for analysis; those pre-treated for 1 h, the chromosomes condensation were appropriate, and the centromeres of most chromosomes could be identified; pre-treatment for 2 h, the chromosomes were over-condensed and punctate. Materials pre-treated with 0.7 mmol·L-1 cycloheximide for 1 h and 3 h, their chromosomes were insufficiently condensed; pre-treatment for 5 h, the chromosomes were properly condensed, but the centromere positions of most chromosomes were not discernible. All materials pre-treated with 2 mmol·L-1 8-hydroxyquinoline for 2 h, 4 h or 6 h, their chromosomes condensation were all appropriate, but the chromosome centromeres could not be identified. So 1 h treatment with 1 MPa nitrous oxide is the most suitable pre-treatment condition for H. macrophylla 'Endless Summer' root tips. 2) Three enzymatic treatment time gradients were used. Chromosomes digested for 0.5 h, their cytoplasm could be observed obviously around the metaphase and the nucleus; chromosomes digested for 1 h, their background were clean and the chromosomes well dispersed; when digestion time expanded to 2 h, the chromosomes were easily lost and many incomplete mitotic phases were observed. Therefore, the most suitable treatment for H. macrophylla 'Endless Summer' root tip was digested in the mixture of 4% cellulase and 2% pectinase at 37℃ for 1 h. 3) H. macrophylla 'Endless Summer' is diploid with 36 chromosomes (2n=2x=36). The FISH of 45S rDNA long and short probes showed similar effects, both produced strong hybridization signals which located at the end of the short arm of a pair of acrocentric chromosomes. Both the long and the short 5S rDNA probes only revealed weak FISH signals, but the detection rate of the long probes was higher than that of the short probes. The 5S rDNA located at the long arm ends of one pair of telocentric chromosomes. Conclusion: This study successfully established a high quality metaphase chromosome preparation and rDNA physical localization technical system for H. macrophylla. This system can efficiently analyze and determine the chromosome number and rDNA distribution in Hydrangea plants. This can be used in Hydrangea resources identification and provide a basis and guidance for Hydrangea hybrid breeding.

Key words: Hydrangea macrophylla, chromosome preparation, rDNA, fluorescence in situ hybridization(FISH)
