外源IAA对马尾松幼苗茎干次生生长的影响

doi:10.11707/j.1001-7488.20210905

摘要/Abstract

摘要：

目的: 对2年生马尾松幼苗进行不同浓度IAA喷施处理，结合生理生化、形态解剖结构及转录组水平变化等综合分析，揭示外源IAA对马尾松苗期茎干次生生长的影响机制，为阐明马尾松苗期茎干次生生长的分子调控机制奠定基础，可以为培育速生高产的马尾松新品系提供一定的理论参考。方法: 对2年生马尾松幼苗进行不同浓度IAA（0、1、50、100 mg·L^-1）喷施处理，处理160天后进行生长指标、解剖结构、生理生化指标的测定；通过高通量转录组测序鉴定差异表达基因，对差异表达基因进行GO和KEGG功能分析。结果: IAA处理对2年生马尾松的地径、细胞生长（木质部、韧皮部厚度以及木质部细胞层数）、木材主要成分（木质素、纤维素及半纤维素含量）及内源激素含量（生长素、赤霉素及油菜素内酯）具有显著的促进作用（P＜0.05）；通过Illumina测序技术对对照组和IAA处理的6个cDNA文库进行测序，最终得到IAA处理后差异表达基因778个（包括482个上调表达基因和296个下调表达基因），GO分析表明这些差异基因主要富集于细胞成分、分子功能和生物过程中共计22个类别，KEGG分析表明它们参与了64种不同的途径，并筛选出与马尾松次生生长相关的差异表达基因（BRL1、GASA6、CAD和CESA2等）。结论: IAA处理能够改变内源激素含量，促进细胞分裂，增加木质素、纤维素和半纤维素积累，从而促进马尾松茎干的次生生长。

关键词: 马尾松, IAA, 次生生长, 转录组

Abstract:

Objective: Pinus massoniana is a unique fast-growing tree species in China and is one of the main afforestation tree species in southern China, which has high economic and ecological value. Auxin has a significant effect on the secondary growth of plants. An in-depth study on the secondary growth of the stem of P. massoniana can provide theoretical basis for breeding new varieties of P. massoniana with fast growth and high yield. In this study, two-year-old P. massoniana seedlings were sprayed with different concentrations of IAA. The effects of exogenous IAA on the secondary growth of P. massoniana seedlings were analyzed in combination with physiological, biochemical, morphological traits and anatomical structures and transcriptome changes. This study could lay a foundation for elucidating molecular regulation mechanism of stem secondary growth of P. massoniana seedlings. Method: Two-year-old P. massoniana seedlings were sprayed with different concentrations of IAA(0, 1, 50, 100 mg·L^-1). After 160 days of treatment, growth traits, anatomic structure, physiological and biochemical properties were measured. The differentially expressed genes were identified by high-throughput transcriptome sequencing, and analyzed by GO and KEGG. Result: IAA treatment significantly promoted the ground diameter, cell growth(xylem and phloem thickness and xylem cell layers), physiological components of wood(lignin, cellulose and hemicellulose), endogenous hormone contents(auxin, gibberellin and brassinolide) of two-year-old P. massoniana(P < 0.05). Six cDNA libraries of CK and IAA were sequenced by Illumina sequencing, 778 differentially expressed genes(including 482 up-regulated genes and 296 down-regulated genes) were obtained. GO analysis showed that these differential genes were mainly involved in 22 categories of cell components, molecular functions and biological processes, and KEGG analysis showed that they were involved in 64 different pathways. Differentially expressed genes related to secondary growth of P. massoniana were screened, such as BRL1, GASA6, CAD, CESA2, etc. Conclusion: IAA treatment changes the content of endogenous hormones, promotes cell division, increases the accumulation of lignin, cellulose and hemicellulose. Thus it promotes the secondary growth of P. massoniana. Our results provide a solid basis for revealing the mechanism of hormone regulation of secondary growth of P. massoniana.

Key words: Pinus massoniana, IAA, secondary growth, transcriptome

中图分类号:

周紫晶,范付华,尚先文,覃慧娟,王聪慧,丁贵杰,谭健晖. 外源IAA对马尾松幼苗茎干次生生长的影响[J]. 林业科学, 2021, 57(9): 42-51.

Zijing Zhou,Fuhua Fan,Xianwen Shang,Huijuan Qin,Conghui Wang,Guijie Ding,Jianhui Tan. Effects of Exogenous IAA on Stem Secondary Growth of Pinus massoniana Seedlings[J]. Scientia Silvae Sinicae, 2021, 57(9): 42-51.

图/表 10

表1

图1

图2

表2

表3

表4

图3

图4

表5

图5

参考文献 0

	陈海燕, 刘凯, 余敏, 等. 外源激素IAA和GA₃对马尾松应压木形成的影响. 北京林业大学学报, 2015, 37 (5): 134- 139.
	Chen H Y , Liu K , Yu M , et al. Effect of exogenous IAA and GA₃ on formation of compression wood of Pinus massoniana Lamb. Journal of Beijing Forestry University, 2015, 37 (5): 134- 139.
	丁贵杰, 严仁发, 齐新民. 不同种源马尾松造林效果及经济效益对比分析. 林业科学, 1994, (6): 506- 512.
	Ding G J , Yan R F , Qi X M . A comparative analysis on planting result and economic benefit of Pinus massoniana Lamb. from different provenance. Scientia Silvae Sinicae, 1994, (6): 506- 512.
	郭丽玲, 潘萍, 欧阳勋志, 等. 间伐补植对马尾松低效林生长及林分碳密度的短期影响. 西南林业大学学报: 自然科学, 2019, 39 (3): 48- 54.
	Guo L L , Pan P , Ouyang X Z , et al. Short-term effect of thinning and replanting measures on tree growth and stand carbon density of low-efficiency Pinus massoniana forest. Journal of Southwest Forestry University: Natural Science, 2019, 39 (3): 48- 54.
	吴修蓉, 周运超, 余星. 镁肥对马尾松幼苗生长与叶片元素积累的影响. 亚热带植物科学, 2019, 48 (1): 11- 16.
	Wu X R , Zhou Y C , Yu X . Effect of magnesium fertilizer on growth and element accumulation of Pinus massoniana seedlings. Subtropical Plant Science, 2019, 48 (1): 11- 16.
	张婷, 文晓鹏. 混合接种外生菌根菌对马尾松种子萌发及幼苗生长的影响. 种子, 2016, 35 (10): 1- 5. doi: 10.3969/j.issn.1000-8071.2016.10.001
	Zhang T , Wen X P . Effect of ectomycorrhizal fungi combination on seed germination and seedling growth of Masson Pine(Pinus massoniana). Seed, 2016, 35 (10): 1- 5. doi: 10.3969/j.issn.1000-8071.2016.10.001
	周乃富, 张俊佩, 刘昊, 等. 木本植物非均质化组织石蜡切片制作方法. 植物学报, 2018, 53 (5): 653- 660.
	Zhou N F , Zhang J P , Liu H , et al. New protocols for paraffin sections of heterogeneous tissues of woody plants. Chinese Bulletin of Botany, 2018, 53 (5): 653- 660.
	Bargmann B O R , Vanneste S , Krouk G , et al. A map of cell type-specific auxin responses. Molecular Systems Biology, 2013, 9, 688. doi: 10.1038/msb.2013.40
	Ben-Nissan G , Lee J , Borohov A , et al. GIP, a Petunia hybrida GA-induced cysteine-rich protein: a possible role in shoot elongation and transition to flowering. The Plant Journal, 2004, 37 (2): 229- 238. doi: 10.1046/j.1365-313X.2003.01950.x
	Bjorklund S , Antti H , Uddestrand I , et al. Cross-talk between gibberellin and auxin in development of Populus wood: gibberellin stimulates polar auxin transport and has a common transcriptome with auxin. The Plant Journal, 2007, 52 (3): 499- 511. doi: 10.1111/j.1365-313X.2007.03250.x
	Brackmann K , Qi J , Gebert M , et al. Spatial specificity of auxin responses coordinates wood formation. Nature Communications, 2018, 9, 875. doi: 10.1038/s41467-018-03256-2
	Cano-Delgado A , Yin Y , Yu C , et al. BRL1 and BRL3 are novel brassinosteroid receptors that function in vascular differentiation in Arabidopsis. Development, 2004, 131 (21): 5341- 5351. doi: 10.1242/dev.01403
	Chaiwanon J , Wang Z . Spatiotemporal brassinosteroid signaling and antagonism with auxin pattern stem cell dynamics in Arabidopsis roots. Current Biology, 2015, 25 (8): 1031- 1042. doi: 10.1016/j.cub.2015.02.046
	Chen J , Wang L , Immanen J , et al. Differential regulation of auxin and cytokinin during the secondary vascular tissue regeneration in Populus trees. New Phytologist, 2019, 224 (1): 188- 201. doi: 10.1111/nph.16019
	Fan F, Cui B, Zhang T, et al. 2014. The temporal transcriptomic response of Pinus massoniana seedlings to phosphorus deficiency. PLoS ONE, 9: e1050688.
	Glweiler L , Uan C , Ller A , et al. Regulation of polar auxin transport by AtPIN1 in Arabidopsis vascular tissues. Science, 1998, 282 (5397): 2226- 2230. doi: 10.1126/science.282.5397.2226
	Joshi C P , Bhandari S , Ranjan P , et al. Genomics of cellulose biosynthesis in poplars. New Phytology, 2004, 164, 53- 61. doi: 10.1111/j.1469-8137.2004.01155.x
	Li A , Xia T , Xu W , et al. An integrative analysis of four CESA isoforms specific for fiber cellulose production between Gossypium hirsutum and Gossypium barbadense. Planta, 2013, 237 (6): 1585- 1597. doi: 10.1007/s00425-013-1868-2
	Livak K J , Schmittgen T D . Analysis of relative gene expression data using real-time quantitative PCR and the 2^-△△CT method. Methods, 2001, 25 (4): 402- 408. doi: 10.1006/meth.2001.1262
	Ma D , Xu C , Alejos-Gonzalez F , et al. Overexpression of Artemisia annua cinnamyl alcohol dehydrogenase increases lignin and coumarin and reduces artemisinin and other sesquiterpenes. Frontiers in Plant Science, 2018, 9, 828. doi: 10.3389/fpls.2018.00828
	Maleki S S , Mohammadi K , Ji K . Characterization of cellulose synthesis in plant cells. The Scientific World Journal, 2016, 2016, 8641373.
	Maleki S S , Mohammadi K , Movahedi A , et al. Increase in cell wall thickening and biomass production by overexpression of PmCesA2 in poplar. Frontiers in Plant Science, 2020, 11, 110. doi: 10.3389/fpls.2020.00110
	Mellerowicz E J , Baucher M , Sundberg B , et al. Unravelling cell wall formation in the woody dicot stem. Plant Molecular Biology, 2001, 47 (1/2): 239- 274. doi: 10.1023/A:1010699919325
	Muller C J , Valdes A E , Wang G , et al. PHABULOSA mediates an auxin signaling loop to regulate vascular patterning in Arabidopsis. Plant Physiology, 2016, 170 (2): 956- 970. doi: 10.1104/pp.15.01204
	Nairn C J , Haselkorn T . Three loblolly pine CesA genes expressed in developing xylem are orthologous to secondary cell wall CesA genes of angiosperms. The New Phytologist, 2005, 166 (3): 907- 915. doi: 10.1111/j.1469-8137.2005.01372.x
	Nemhauser J L , Mockler T C , Chory J . Interdependency of brassinosteroid and auxin signaling in Arabidopsis. PLoS Biology, 2004, 2 (9): E258. doi: 10.1371/journal.pbio.0020258
	Nieminen K M , Kauppinen L , Helariutta Y . A weed for wood? Arabidopsis as a genetic model for xylem development. Plant Physiology, 2004, 135 (2): 653- 659. doi: 10.1104/pp.104.040212
	Pan H , Zhou R , Louie G V , et al. Structural studies of cinnamoyl-CoA reductase and cinnamyl-alcohol dehydrogenase, key enzymes of monolignol biosynthesis. Plant Cell, 2014, 26 (9): 3709- 3727. doi: 10.1105/tpc.114.127399
	Pan X , Welti R , Wang X . Quantitative analysis of major plant hormones in crude plant extracts by high-performance liquid chromatography-mass spectrometry. Nature Protocols, 2010, 5 (6): 986- 992. doi: 10.1038/nprot.2010.37
	Ponniah S K , Shang Z , Akbudak M A , et al. Down-regulation of hydroxycinnamoyl CoA: shikimate hydroxycinnamoyl transferase, cinnamoyl CoA reductase, and cinnamyl alcohol dehydrogenase leads to lignin reduction in rice(Oryza sativa L. ssp. japonica cv. Nipponbare). Plant Biotechnology Reports, 2017, 11 (1): 17- 27.
	Sakamoto T , Morinaka Y , Inukai Y , et al. Auxin signal transcription factor regulates expression of the brassinosteroid receptor gene in rice. Plant Journal, 2013, 73 (4): 676- 688. doi: 10.1111/tpj.12071
	Savidge R A . Auxin and ethylene regulation of diameter growth in trees. Tree Physiology, 1988, 4 (4): 401- 414. doi: 10.1093/treephys/4.4.401
	Savidge R A . The role of plant hormones in higher plant cellular differentiation Ⅱ: Experiments with the vascular cambium, and sclereid and tracheid differentiation in the pine, Pinus contorta. The Histochemical Journal, 1983, 15 (5): 447- 466. doi: 10.1007/BF01002699
	Spicer R , Groover A . Evolution of development of vascular cambia and secondary growth. New Phytologist, 2010, 186 (3): 577- 592. doi: 10.1111/j.1469-8137.2010.03236.x
	Taylor B H , Scheuring C F . A molecular marker for lateral root initiation: the RSI-1 gene of tomato(Lycopersicon esculentum Mill) is activated in early lateral root primordia. Molecular General Genetics, 1994, 243 (2): 148- 157. doi: 10.1007/BF00280311
	Tuominen H , Puech L , Fink S , et al. A radial concentration gradient of indole-3-acetic acid is related to secondary xylem development in hybrid aspen. Plant Physiology, 1997, 115 (2): 577- 585. doi: 10.1104/pp.115.2.577
	Uggla C , Mellerowicz E J , Sundberg B . Indole-3-acetic acid controls cambial growth in Scots pine by positional signaling. Plant Physiology, 1998, 117 (1): 113- 121. doi: 10.1104/pp.117.1.113
	Yao X , Remko O . PDK1 regulates auxin transport and Arabidopsis vascular development through AGC1 kinase PAX. Nature Plants, 2020, 6, 544- 555. doi: 10.1038/s41477-020-0650-2
	Yu M , Liu K , Liu S , et al. Effect of exogenous IAA on tension wood formation by facilitating polar auxin transport and cellulose biosynthesis in hybrid poplar(Populus deltoides×Populus nigra) wood. Holzforschung, 2017, 71 (2): 179- 188. doi: 10.1515/hf-2016-0078
	Yuan H , Zhao L , Guo W , et al. Exogenous application of phytohormones promotes growth and regulates expression of wood formation-related genes in Populus simonii×P. nigra. International Journal of Molecular Sciences, 2019, 20 (3): 792. doi: 10.3390/ijms20030792
	Zhao C , Craig J C , Petzold H E , et al. The xylem and phloem transcriptomes from secondary tissues of the Arabidopsis root-hypocotyl. Plant Physiology, 2005, 138 (2): 803- 818. doi: 10.1104/pp.105.060202
	Zheng L , Gao C , Zhao C , et al. Effects of brassinosteroid associated with auxin and gibberellin on apple tree growth and gene expression patterns. Horticultural Plant Journal, 2019, 5 (3): 93- 108. doi: 10.1016/j.hpj.2019.04.006
	Zhong C , Xu H , Ye S , et al. Gibberellic acid-stimulated Arabidopsis6 serves as an integrator of gibberellin, abscisic acid, and glucose signaling during seed germination in Arabidopsis. Plant Physiology, 2015a, 169 (3): 2288- 2303.
	Zhong R , Ye Z . Secondary cell walls: biosynthesis, patterned deposition and transcriptional regulation. Plant and Cell Physiology, 2015b, 56 (2SI): 195- 214.
	Zhou A , Wang H , Walker J C , et al. BRL1, a leucine-rich repeat receptor-like protein kinase, is functionally redundant with BRI1 in regulating Arabidopsis brassinosteroid signaling. The Plant Journal, 2004, 40 (3): 399- 409. doi: 10.1111/j.1365-313X.2004.02214.x

基因 Gene	序列 Sequence(5′→3′)
TRINITY_DN10179_c0_g1	F: TGATGGATGGTGGTTGATAC
	R: CTGATGGGCAAACTGAGATA
TRINITY_DN8564_c0_g2	F: GCGTATTCCGCCAGAGTG
	R: TCCAGAACGAGTGCCCCT
TRINITY_DN5190_c1_g1	F: CAGGCGACTCCACCTACAACT
	R: TGCGGAACACCTAATCCAAAC
TRINITY_DN2065_c0_g1	F: GAACGCAGAGCAATGAAG
	R: AAGCCCACCACTATGACC
TRINITY_DN11133_c0_g2	F: TCACGCTTCCTTTGGCTTTT
	R: CGTACGGTCTGCACTTCATC
TRINITY_DN3030_c1_g1	F: AGAGCAGATTCCAGCAGA
	R: CGGGTTTCCAGTAGATGA
TRINITY_DN39456_c0_g1	F: TCAGCGGACCCTGTTCTA
	R: GACAAAGTTGCCGTGGAG
TRINITY_DN40433_c0_g1	F: AGGGACTGGCTCCTTGTG
	R: CTTCGGAATCGCACCTTT
TRINITY_DN99422_c0_g3	F: GAAGACTTGAAATGCCTGAC
	R: ATAGACCTTGAACGCCTC
UBC	F: GATTTATTTCATTGGCAGGC
	R: AGGATCATCAGGATTTGGGT

IAA	木质素含量 Lignin content/(mg·g^-1)	纤维素含量 Cellulose content/(mg·g^-1)	半纤维素含量 Hemicellulose content/(mg·g^-1)
CK	89.95±0.98 a	199.30±35.81 a	160.51±1.01 a
1 mg·L^-1	116.33±0.07 b	292.35±18.03 b	207.13±15.40 b
50 mg·L^-1	122.43±3.92 b	287.18±16.06 b	202.68±5.75 b
100 mg·L^-1	124.94±7.08 b	285.85±12.47 b	187.36±3.05 ab

	内源激素Endogenous hormone/(ng·g^-1)	CK	IAA处理 IAA treatment
生长素类 Auxins	吲哚-3-乙酸Indole-3-acetic acid(IAA)	58.67±1.95	113.67±4.91^**
	氧化吲哚乙酸Oxidized indoleacetic acid(OxIAA)	0.00	114.00±4.73^**
	吲哚-3-甲醛Indole-3-carboxaldehyde(ICAld)	4.48±0.04	133.00±3.51^**
	吲哚-3-乙酸甲酯Indole-3-methyl acetate(MEIAA)	3.85±0.10	7.18±0.28^**
	吲哚乙酸-亮氨酸Indoleacetic acid-leucine(IAA-Leu)	1.06±0.08^**	0.56±0.03
	吲哚乙酸-天冬氨酸Indoleacetic acid-aspartic acid(IAA-Asp)	1.89±0.13^**	1.27±0.06
	色胺Tryptamine(TRA)	0.16±0.01	0.14±0.00
	色氨酸Tryptophan(TRP)	2 156.67±53.64^*	1 903.33±43.33
	3-吲哚丙酸3-Indolepropionic acid(IPA)	42.63±0.92	44.30±2.86
赤霉素类 Gibberellins	赤霉素1 Gibberellin1(GA1)	17.67±0.69	24.60±2.46
赤霉素类 Gibberellins	赤霉素15 Gibberellin15(GA15)	0.27±0.05	0.27±0.03
油菜素内酯类 Brassinolides	油菜素内酯Brassinolide(BR)	0.05±0.00	0.09±0.00^**
	油菜素甾酮Castasterone(CS)	19.89±1.18	27.03±0.99^**
	28-高油菜素甾酮28-homocastasterone(28-homoCS)	1.25±0.07	1.58±0.03^**
	香蒲甾醇Typhasterol(TY)	36.38±0.31	35.42±0.32
	6-脱氧油菜素甾酮6-deoxocastasterone(6-deoxoCS)	0.02±0.00	0.03±0.00

样本 Sample	原始读数 Raw reads	清洁读数(清洁读数/原始读数) Clean reads(clean reads/raw reads)	错误率 Error rate(%)	Q20(%)	Q30(%)	GC含量 GC content(%)
CK1	79 111 552	78 288 654(98.96%)	0.024 4	98.31	94.73	44.47
CK2	73 641 850	72 846 758(98.92%)	0.024 3	98.33	94.83	44.96
CK3	86 263 202	85 424 670(99.03%)	0.024 4	98.28	94.66	44.65
IAA1	87 975 948	87 084 030(98.99%)	0.024 2	98.36	94.87	44.83
IAA2	93 638 284	92 535 608(98.82%)	0.024 6	98.24	94.55	45.16
IAA3	77 429 912	76 588 978(98.91%)	0.024 7	98.17	94.39	44.87

基因号 Gene ID	注释 Description	差异倍数 Log₂FC	表达量Expression quantity
基因号 Gene ID	注释 Description	差异倍数 Log₂FC	CK	IAA
激素Hormone
TRINITY_DN6209_c0_g1	油菜素内酯受体激酶Brassinosteroid LRR receptor kinase(BRL1)	1.92	9.15	30.11
TRINITY_DN105600_c0_g2	赤霉素响应蛋白Gibberellin-regulated protein(GASA6)	1.70	2.09	6.35
木质素Lignin
TRINITY_DN40433_c0_g1	肉桂醇脱氢酶Cinnamyl alcohol dehydrogenases(CAD)	7.48	0	1.06
纤维素Cellulose
TRINITY_DN2065_c0_g1	纤维素合酶Cellulose synthase(CESA2)	1.13	23.30	45.01
