基于深度学习的木材优选锯视觉检测算法

doi:10.11707/j.1001-7488.20201214

Abstract

Abstract:

Objective: For the purposes of playing full value of wood, increasing the timber yield and improving the automatic level of wood processing industry, a new method for automatic optimizing cross-cut saw based on deep learning algorithm was proposed in this paper. Method: Pretrained defect detection network (Net.1) and grade classification network (Net.2) were obtained based on enough samples. Images of timber were captured by the vision sensor, the defect position on image could be confirmed based on Net. 1, while the grade position could be confirmed based on Net. 2. Final physical position could be determined based on the homography relationships between image plane and physical plane. Cutting list could also be obtained. Result: The experiment in our detailed conditions showed that the time of defect detection was 123 ms (per image), while the accuracy was 95.8% (per image). The time of grade classification was 55 ms (per image), while the accuracy was 97.1% (per image). The average time of detection was 86 ms (per image), while the average accuracy was 96.5% (per image). Conclusion: Our new method presented many advantages, such as a high operation speed, a high recognition efficiency and a strong robustness. The algorithm could improve the traditional optimizing cross-cut saw with a high automation and could also meet the requirements of real-time and accurate detection in wood processing.

Key words: deep learning, optimizing cross-cut saw, wood processing, defect detection, computer vision

CLC Number:

S777

Mingwei Shao,Junyu Dong. A New Algorithm for Automatic Optimizing Cross-Cut Saw Based on Deep Learning Algorithm[J]. Scientia Silvae Sinicae, 2020, 56(12): 123-129.

Figures/Tables 10

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

Table 1

References 0

	马颂德, 张正友. 计算机视觉:计算理论与算法基础. 北京: 科学出版社, 1998.
	Ma S D , Zhang Z Y . Computer vision:computational theory and algorithm basis. Beijing: Science Press, 1998.
	Mitchell T M. 2012.机器学习.曾华军, 译.北京: 机械工业出版社.
	Mitchell T M. 2012. Machine learning. Translated by Zeng H J. Beijing: China Machine Press.[in Chinese]
	章毓晋. 图象工程:图象理解与计算机视觉. 北京: 清华大学出版社, 2000.
	Zhang Y J . Image engineering:image understanding and computer vision. Beijing: Tsinghua University Press, 2000.
	Dong C , Loy C C , He K M , et al. Image super-resolution using deep convolutional networks. IEEE Trans Pattern Anal Mach Intell, 2016, 38 (2): 295- 307. doi: 10.1109/TPAMI.2015.2439281
	Hartley R , Zisserman A . Multiple view geometry in computer vision. England: Cambridge University Press, 2003: 2- 8.
	He T , Liu Y , Xu C Y , et al. A fully convolutional neural network for wood defect location and identification. IEEE Access, 2019, doi: 10.1109/ACCESS.2019.2937461
	Huang H , Zhang H , Cheung Y . The common self-polar triangle of concentric circles and its application to camera calibration. IEEE Conference on Computer Vision and Pattern Recognition, 2015, 4065- 4072.
	Ismail H , Balachandran B . Algorithm fusion for feature extraction and map construction from SONAR data. IEEE Sensors Journal, 2015, 15 (11): 6460- 6471. doi: 10.1109/JSEN.2015.2456900
	Ji S W , Xu W , Yang M , et al. 3D convolutional neural networks for human action recognition. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2012, 35 (1): 221- 231.
	Razavian A S , Azizpour H , Carlsson S . CNN features off-the-shelf:an astounding baseline for recognition. IEEE Conference on Computer Vision and Pattern Recognition Workshops, 2014, doi: 10.1109/CVPRW.2014.131
	Ren S Q , He K M , Girshick R , et al. Faster R-CNN:towards real-time object detection with region proposal networks. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2016, 39 (6): 1137- 1149.
	Safaee-Rad R , Tchoukanov I , Smith K C , et al. Three-dimensional location estimation of circular features for machine vision. IEEE Transactions on Robotics and Automation, 1992, 624- 640.
	Shao M W , Hu M J . Parallel feature based calibration method for a trinocular vision sensor. Optics Express, 2020a, 28 (14): 20573- 20586. doi: 10.1364/OE.393012
	Shao M W , Wang P , Wang J H . Improved sensors based on scheimpflug conditions and multi-focal constraints. IEEE Acess, 2020b, doi: 10.1109/ACCESS.2020.3020731
	Shao M W . Calibration methods for a camera with a tilted lens and a three-dimensional laser scanner in the scheimpflug condition. Journal of the Optical Society of America A:Optics, Image Science and Vision, 2020, 37 (7): 1076- 1082. doi: 10.1364/JOSAA.391906
	Shiu Y, Ahmad S. 1989.3D location of circular spherical features by monocular model-based vision. Proceedings of the IEEE Conference on System, Man and Cybernetics, Cambridge, Mass, USA, 576-581.
	Steger C. 1998. Unbiased extraction of curvilinear structures from 2D and 3D image. Muenchen: PhD Dissertation of Technische Universitaet Muenchen.
	Wu W , Gao X Y , Fan J , et al. Improved mask R-CNN-based cloud masking method for remote sensing images. International Journal of Remote Sensing, 2020, 41 (23): 8908- 8931.
	Zhang Z . A flexible new technique for camera calibration. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2000, 22 (11): 1330- 1334. doi: 10.1109/34.888718
	Zheng W M . Heteroscedastic feature extraction for texture classification. IEEE Signal Processing Letters, 2009, 16 (9): 766- 769. doi: 10.1109/LSP.2009.2023939

缺陷检测Defect detection		等级分类Grade classification		平均指标Average result
单幅图像时间 Time per image/ms	正确率 Accuracy(%)	单幅图像时间 Time per image/ms	正确率 Accuracy(%)	平均时间 Average time/ms	平均正确率 Average accuracy(%)
123	95.8	55	97.1	86	96.5
