框锯减振机构平衡的研究

林业科学 ›› 1995, Vol. 31 ›› Issue (5): 443-452.

框锯减振机构平衡的研究

欧阳富,姜贵君,李成元

吉林林学院, 吉林 132011

收稿日期:1994-06-23 出版日期:1995-09-25 发布日期:1995-09-25

A STUDY ON A NEW METHOD OF BALANCING GANG SAW WITH SHOCK ATTENUATION DEVICE

Fu Ouyang,Guijun Jiang,Chengyuan Li

Jilin Forestry College Jilin 132011

Received:1994-06-23 Online:1995-09-25 Published:1995-09-25

摘要/Abstract

摘要：

用变角速度减振机构平衡框锯往复惯性力研究表明, 此方法可以有效地平衡往复惯性力的99%, 使框锯的最大往复惯性力降低268倍; 比飞轮平衡块法降低惯性力小90倍。为框锯消除有害的冲击振动提供了理论依据。

关键词: 框锯, 惯性力, 变角速度, 等值原则, 等差原则, 惯性力因子

Abstract:

This paper puts forward a new mothod of balancing the big reciprocating inertia force of gang saw with the altering angular velocity of the shock attenuation device. The study and calculation indicate: the method can balance the reciprecating force by 99%; decrease the maximum reciprocating inertia force by 268 times and by 90 times over the present balancing method with counterbalance. Thus, the gang saw can elimlnate the vibration caused by impact, increase its tangential velocity and productivity of labor and the stability of the frame, This method provides the eneoretical base for ideal balanced gang saw.

Key words: Gang saw, Balancing axle, Inertia force, Altering angular velocity, Eccentric counterbalance, Equidifferent and equivalent principle

欧阳富,姜贵君,李成元. 框锯减振机构平衡的研究[J]. 林业科学, 1995, 31(5): 443-452.

Fu Ouyang,Guijun Jiang,Chengyuan Li. A STUDY ON A NEW METHOD OF BALANCING GANG SAW WITH SHOCK ATTENUATION DEVICE[J]. Scientia Silvae Sinicae, 1995, 31(5): 443-452.

图/表 7

图1

图2

图3

图4

图5

图6

图7

1	B.Φ。谢加里著, 沈阳机电学院内燃机教研室译。内燃机动力计算。机械工业出版社, 1982: 31, 110-114
2	翁家昌等编。拖拉机构造原理与计算。中国工业出版社, 1964: 90-100
3	李新民, 何德芳。 MJ425框锯不平衡程度的计算. 木工机床, 1991, (4): 1- 6
4	A。 И.高尔钦, В. Ⅱ。杰米道夫著.朱仙鼎等译。汽车拖拉机发动机计算。机械工业出版社, 1985: 144-146, 166-167
5	天津大学等主编。机械原理(下册)。人民教育出版社, 1979: 246-247
6	王永常等。油锯减振机构新设计。1986, (1): 11-13
7	傅有保, 叶倩如编著。木工机械理论与设计计算。中国林业出版社, 1992: 270-271
