森林计划烧除的PM2.5排放时空过程模拟及其对空气质量的影响

doi:10.11707/j.1001-7488.20220807

Abstract

Abstract:

Objective: The forest of Pinus yunnanensis undergone prescribed burning in Yuxi City, Yunnan Province was investigated by survey of sample plots, load assessment, smoke emission calculation and the spatiotemporal diffusion process simulation, in order to understand the quantitative relationship between the simulated diffusion of PM_2.5 in downwind city and the ground measurements, and to reveal the impacts of the smoke by the prescribed burning on air quality, therefore providing a theoretical basis for appropriate prescribed burning and smoke management practice. Methods: Sample plots in size of 10 m × 10 m were set up in the forest stand of P. yunnanensis undergone prescribed burning in central Yunnan. Fuel loads were estimated by drying in the laboratory, and the PM_2.5 emission of smoke was calculated by BlueSky, the spatiotemporal pattern of diffusion was analyzed quantitatively with the aid of HYSPLIT forward trajectory model, and the reliability of the results was verified by comparing with the GF-4 satellite image, finally, the relationship between the simulated and the ground measurements of PM_2.5 in Kunming City in the downwind direction of the emission was conducted. Result: The diffusion pattern of the smoke of prescribed burning simulated by HYSPLIT is consistent with the smoke area by visual detection from GF-4 satellite imagery synchronously, the PM_2.5 emission is positively correlated with fuel load and prescribed burning area, the thicker the humus, the higher the combustible load, and the more the smoke emitted. The PM_2.5 concentration of the city located in the downwind showed a significant increase trend subsequently, and the pattern of ground measurements was consistent and positively correlated (R²=0.787 43) with the simulated values of diffusion, and the air quality was degraded from 'excellence' to 'good' or even 'slightly polluted'. Conclusion: The smoke emission of prescribed burning is correlated with the fuel load, the burning area, and the thickness of humus. The smoke generated by the prescribed burning has a significant impact on urban air quality in downwind direction of the diffusion channel with a time lag. The quantitative assessment and early warning of smoke pollution before prescribed burning can effectively alleviate the damage by the smoke of prescribed burning.

Key words: prescribed burning, PM_2.5, HYSPLIT, air quality

CLC Number:

Guojun Cao,Jiaxin Li,Fengjun Zhao,Lifu Shu,Jiangxia Ye. Simulation of the Spatiotemporal Process of PM_2.5 Emission from Prescribed Burning of Forest and Its Impacts on Air Quality[J]. Scientia Silvae Sinicae, 2022, 58(8): 63-75.

Figures/Tables 11

Table 1

Table 2

Table 3

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

References 0

	曹莹莹. 北京市PM_2.5酸性组分的时空分布与沉降特征研究. 北京: 北京林业大学, 2016.
	Cao Y Y . The spatial-temporal distribution and deposition characteristic of PM_2.5 acidic components in Beijing. Beijing: Beijing Forestry University, 2016.
	陈剑, 杨文忠, 张珊珊, 等. 基于林分关键指标的云南省云南松地理分布格局. 西部林业科学, 2021, 50 (1): 19- 26. doi: 10.16473/j.cnki.xblykx1972.2021.01.003
	Chen J , Yang W Z , Zhang S S , et al. Geographical distribution patterns of Pinus yunnanensis in Yunnan Province based on critical indicators of the forest stand. Journal of West China Forestry Science, 2021, 50 (1): 19- 26. doi: 10.16473/j.cnki.xblykx1972.2021.01.003
	崔芬萍. 南京地区大气气溶胶光学特性的观测研究. 南京: 南京信息工程大学, 2017.
	Cui F P . Observational study on optical properties of in Nanjing. Nanjing: Nanjing University of Information Science & Technology, 2017.
	胡婧, 郭新彪. 生物质燃料燃烧所致的室内空气污染及其健康影响研究进展. 环境与健康杂志, 2007, (10): 827- 829. doi: 10.3969/j.issn.1001-5914.2007.10.036
	Hu Q , Guo X B . Research progress in indoor air pollution and health effects caused by combustion of biomass fuels. Journal of Environment and Health, 2007, (10): 827- 829. doi: 10.3969/j.issn.1001-5914.2007.10.036
	胡宗华. 云南省森林资源调查报告. 昆明: 云南科技出版社, 2017.
	Hu Z H . Forest resources survey report of Yunnan Province. Kunming: Yunnan Science and Technology Press, 2017.
	柯华兵, 龚山陵, 何建军, 等. 露天生物质燃烧对地面PM_2.5浓度的影响评估. 应用气象学报, 2020, 31 (1): 105- 116.
	Ke H B , Gong S L , He J J , et al. Impact assessment of biomass combustion in open air on surface PM_2.5concentration. Journal of Applied meteorological Science, 2020, 31 (1): 105- 116.
	李艳, 王元, 储惠芸, 等. 中国陆域近地层风能资源的气候变异和下垫面人为改变的影响. 科学通报, 2008, (21): 2646- 2653. doi: 10.3321/j.issn:0023-074X.2008.21.017
	Li Y , Wang Y , Chu H Y , et al. Climate variability and the impact of anthropogenic changes in the underlying surface of terrestrial wind energy resources in China. Chinese Science Bulletin, 2008, (21): 2646- 2653. doi: 10.3321/j.issn:0023-074X.2008.21.017
	刘灏, 王颖, 王思潼, 等. 基于HYSPLIT4模式的天水市颗粒物输送路径的研究. 中国环境科学, 2021, 41 (8): 3529- 3538. doi: 10.3969/j.issn.1000-6923.2021.08.007
	Liu H , Wang Y , Wang S T , et al. Study on the transport path of particles in Tianshui City based on HYSPLIT4 model. China Environmental Sciences, 2021, 41 (8): 3529- 3538. doi: 10.3969/j.issn.1000-6923.2021.08.007
	马志贵, 鄢武先, 杨道贵. 云南松计划烧除林地危险可燃物累积量动态及计划烧除周期探讨. 四川林业科技, 1998, (1): 3- 5. doi: 10.16779/j.cnki.1003-5508.1998.01.004
	Ma Z G , Yan W X , Yang D G . Study on the dynamics of accumulation of dangerous combustibles and planned burning cycle in prescribed burning forest of Pinus yunnanensis. Journal of Sichuan Forestry Science and Technology, 1998, (1): 3- 5. doi: 10.16779/j.cnki.1003-5508.1998.01.004
	覃先林, 刘树超, 李晓彤, 等. 高分四号卫星在我国森林草原火情监测中的应用. 卫星应用, 2018, (12): 34- 37. doi: 10.3969/j.issn.1674-9030.2018.12.009
	Qin X L , Liu S C , Li X T , et al. Application of GF-4 satellite in forest and grassland fire monitoring in China. Satellite Application, 2018, (12): 34- 37. doi: 10.3969/j.issn.1674-9030.2018.12.009
	王兰新, 赵建伟, 郭贤明. 我国计划烧除研究综述. 林业调查规划, 2015, 40 (6): 17- 21. doi: 10.3969/j.issn.1671-3168.2015.06.004
	Wang L X , Zhao J W , Guo X M . Research review on planned burning in China. Forest Inventory and Planning, 2015, 40 (6): 17- 21. doi: 10.3969/j.issn.1671-3168.2015.06.004
	王秋华, 单保君, 龚家平, 等. 滇中地区云南松纯林计划烧除研究. 江西农业大学学报, 2018, 40 (2): 235- 240. doi: 10.13836/j.jjau.2018031
	Wang Q H , Shan B J , Gong J P , et al. A study on prescribed burning of pure forest of Pinus yunnanensis franch in central Yunnan Province. Acat Agriculturae Universitatis Jiangxiensis, 2018, 40 (2): 235- 240. doi: 10.13836/j.jjau.2018031
	闫想想, 王秋华, 龙腾腾, 等. 美国大自然保护中心的计划烧除情况分析. 森林防火, 2020, (2): 46- 50. doi: 10.3969/j.issn.1002-2511.2020.02.011
	Yan X X , Wang Q H , Long T T , et al. Study on the status of planned burning accomplished by the American Nature Conservation Center. Forest Fire Prevention, 2020, (2): 46- 50. doi: 10.3969/j.issn.1002-2511.2020.02.011
	张钰伊, 吴非, 储文超. 利用Hysplit模式探究长江角洲冬春季霾的来源及其成因. 普洱学院学报, 2016, 32 (3): 4- 8. doi: 10.3969/j.issn.1008-8059.2016.03.003
	Zhang Y Y , Wu F , Chu W C . Using Hysplit model to explore the source and cause of winter and spring haze in the Yangtze River delta. Journal of Puer University, 2016, 32 (3): 4- 8. doi: 10.3969/j.issn.1008-8059.2016.03.003
	Abatzoglou J T , Williams A P , Barbero R . Global emergence of anthropogenic climate change in fire weather indices. Geophysical Research Letters, 2019, 46 (1): 326- 336.
	Draxler R R , Stein A F , Rolph G D , et al. NOAA's HYSPLIT atmospheric transport and dispersion modeling system. Bulletin of the American Meteorological Society, 2015, 96 (12): 2059- 2077. doi: 10.1175/BAMS-D-14-00110.1
	Draxler R R , Hess G D . An overview of the HYSPLIT_4 modeling system of trajectories, dispersion, and deposition. Australian Meteorological Magazine, 1998, 47 (4): 295- 308.
	Forkel M , Andela N , Harrison S P , et al. Emergent relationships with respect to burned area in global satellite observations and fire-enabled vegetation models. Biogeoences Discussions, 2019, 16 (1): 1- 31.
	Goodrick , S L , Achtemeier G L , Larkin N K , et al. Modelling smoke transport from wildland fires: a review. International Journal of Wildland Fire, 2013, 22 (1): 83- 94. doi: 10.1071/WF11116
	Hu Yongtao , Odman M T , Chang M E , et al. Simulation of air quality impacts from prescribed fires on an urban area. Environmental Science & Technology, 2008, 42 (10): 3676- 3682.
	Iraji F , Memarian M H , Joghatae M T , et al. Determining the source of dust storms with use of coupling WRF and HYSPLIT models: a case study of Yazd Proince in central desert of Iran. Dynamics of Atmospheres and Oceans, 2020, 93 (14): 101197.
	Larkin S , Raffuse S M , Strand T , et al. Developing an improved wildland fire emissions inventory. American Geophysical Union Fall meeting, 2010, P13- 17.
	Liu Y , Goodrick S , Achtemeier G , et al. Smoke incursions into urban areas: simulation of a Georgia prescribed burn. International Journal of Wildland Fire, 2009, 18 (3): 336- 348. doi: 10.1071/WF08082
	Ma Y F , Wang M B , Wang S , et al. Air pollutant emission characteristics and HYSPLIT model analysis during heating period in Shenyang, China. Environmental Monitoring and Assessment, 2020, 193 (1): 9- 9.
	McLauchlan K K , Higuera P E , Miesel J R , et al. Fire as a fundamental ecological process: research advances and frontiers. Journ of Ecology, 2020, 108 (5): 2047- 2069. doi: 10.1111/1365-2745.13403
	Mcvicar T R , Niel T G V , Roderick M L , et al. Observational evidence from two mountainous regions that near-surface wind speeds are declining more rapidly at higher elevations than lower elevations: 1960-2006. Geophysical Research Letters, 2010, 37, 06402.
	Moroz B E , Beck H L , Bouville , et al. Predictions of dispersion and deposition of fallout from nuclear testing using the NOAA-HYSPLIT meteorological model. Health Physics, 2010, 99 (2): 252- 269. doi: 10.1097/HP.0b013e3181b43697
	Pouliot G , Gilliam R , Eder B , et al. Evaluating the Wildfire emission estimates in an air quality simulation of the 2016 Southeastern United States wildfires. International Emissions Inventory Conference, 2017,
	Stambaugh M C , Smith K T , Dey D C . Fire scar growth and closure rates in white oak (Quercus alba) and the implications for prescribed burning. Forest Ecology and Management, 2017, 391, 396- 403. doi: 10.1016/j.foreco.2017.02.005
	Stevens-Rumann C S , Morgan P . Tree regeneration following wildfires in the western US: a review. Fire Ecology, 2019, 15 (1): 1- 17. doi: 10.1186/s42408-018-0007-7
	Vinogradova A A , Vasileva A V , Ivanova Y A . Air pollution by black carbon in the region of Wrangel Island: comparison of Eurasian and American sources and their contributions. Atmospheric and Oceanic Optics, 2021, 34 (2): 97- 103. doi: 10.1134/S1024856021020111
	Wu J , Zha J L , Zhao D M , et al. Changes in terrestrial near-surface wind speed and their possible causes: an overview. Climate Dynamics, 2018, 51 (5/6): 2039- 2078.
	Ye J X , Wu M S , Deng Z J , et al. Modeling the spatial patterns of human wildfire ignition in Yunnan Province, China. Applied Geography, 2017, 89, 150- 162. doi: 10.1016/j.apgeog.2017.09.012
	Zhao F J , Liu Y , Goodrick S , et al. The contribution of duff consumption to fire emissions and air pollution of the rough ridge fire. International Journal of Wildland Fire, 2020, 28 (13): 993- 1004.

可燃物类型 Fuel types	可燃物大小 Fuel size
1 h	直径 < 0.64cm的小枝、树叶以及枯死的杂草Branchlets < 0.64 cm in diameter, leaves，and dead weeds
10 h	直径0.64~2.54cm小枝Branchlets 0.64-2.54cm in diameter
100 h	直径在2.54~7.62cm的枯枝Twigs 2.54-7.62cm in diameter
＞100 h	直径＞7.62cm的枯枝Twigs＞7.62cm in diameter

项目Item	样点1 Plot 1	样点2 Plot 2	样点3 Plot 3	均值 Mean value	平均值占比 Average percentage
1 h	4.43	6.53	3.84	4.93	10%
10 h	2.09	6.2	1.58	3.29	6.6%
100 h	0.01	0.11	0.001	0.04	忽略不计Ignore
＞100 h	0.002	0.002	0.002	0.002	忽略不计Ignore
腐殖质Duff	56.89	45.06	22.52	41.49	83.4%
总载量Total load	63.422	57.902	27.943	49.756
腐殖质载量占比 Proportion of duff load	89.7%	77.82%	80.59%	82.7%

计划烧除时间 Prescribed burning time	计划烧除地点 Prescribed burning location	计划烧除面积 Prescribed burning area/hm²	PM_2.5排放量 PM_2.5 emissions/t
02-11	新平县Xinping County	12 108	78 080.42
	新平县Xinping County	1 188	7 663.27
02-12	峨山县Eshan County	8 637	55 222.77
	新平县Xinping County	6 592	42 510.27
02-13	峨山县Eshan County	10 608	67 824.85
	新平县Xinping County	410	2 643.99
02-14	峨山县Eshan County	1 971	12 602.08
