聚合物型土壤固结剂对土壤的固结性能及其在苗木移栽上的应用

doi:10.11707/j.1001-7488.20220116

Abstract

Abstract:

Objective: In this paper, we investigated the soil consolidation performance and anti-vibration of polymer soil consolidation agent, and explored the application technology of polymer soil consolidation agent in seedling transplanting, by which this study aimed to form a new technology of seedling transplanting to gradually expand the application of polymer to the ecological environment engineering of afforestation and greening. Method: In this paper, konjac glucomannan (KGM) and chitosan (CA) were used as the main raw materials and polyvinyl alcohol (PVA) was used as assistant to prepare environmental-friendly soil consolidation agent through polymer blending technology. The characteristic soil in North China—cinnamon soil was taken as the research object, the soil was prepared into soil column samples by moulds, and the prepared binary blend KGM/CA soil consolidation agent was evenly spread on the soil column, and after drying, a hard film formed on the surface of the soil column. In order to test whether the compression resistance and the anti-vibration performance of consolidated soil columns can meet the requirements of seedling transplantation in the actual transportation process, two different test methods were used to simulate the transportation anti-vibration of consolidated soil column. Finally, the seedlings of mulberry, Sabina chinensis and Euonymus japonicus were as transplanting objects to explore the application of blending soil consolidation agent in seedling transplanting. Result: The results showed that when the concentration of acetic acid solution was 20%, the pH of the glue was 4.5, the blending temperature was 40 ℃ and the content of KGM, CA and PVA were 4.5%, 4.5% and 6.0% in the prepared of KGM/CA/PVA ternary blend adhesive, the formulation of consolidating agent had the best consolidation effect on soil column and the consolidated soil column had the best anti-vibration performance in transportation. Conclusion: By testing the anti-vibration of consolidated soil columns with two different test methods, it has been found that the prepared KGM/CA and KGM/CA/PVA blend soil consolidation agent meet the requirements of consolidated soil balls. Through the preliminary application of the blend soil consolidation agent in the transplanting process of mulberry seedlings, Sabina chinensis seedlings and Euonymus japonicus seedlings, it is found that the blend soil consolidation agent has good consolidation effect on loam and sandy soil. In addition, the application of this kind of consolidation agent not only makes the transplanting process of seedlings faster, and ensures the survival rate of transplanted seedlings, but also has no adverse effect on the growth of seedlings.

Key words: polymer soil consolidation agent, seedling transportation, anti-vibration performance, consolidated soil ball, consolidation strength

CLC Number:

S688

Shaoli Wang,Xuping Yang,Chaoxing Luo,Zhengqi Xiong,Shaobo Wang,Shengju Song,Lili Liu,Shaofeng Li. Effects of Polymer Soil Consolidation Agent on Soil Consolidation Performance and Its Application in Seedling Transplantation[J]. Scientia Silvae Sinicae, 2022, 58(1): 151-161.

Figures/Tables 11

Fig.1

Table 1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Table 2

Fig.7

Fig.8

Fig.9

References 0

	封晴霞, 赵雄伟, 陈志周, 等. 壳聚糖及其应用研究进展. 食品工业科技, 2018, 39 (21): 333- 336, 341.
	Feng Q X , Zhao X W , Chen Z Z , et al. Research progress of chitosan and its application. Science and Technology of Food Industry, 2018, 39 (21): 333- 336, 341.
	顾蓉, 郭康权, 漆楚生, 等. 魔芋粉-壳聚糖-聚乙烯醇共混胶黏剂的性能及其胶合机理. 农业工程学报, 2010, 26 (5): 373- 378.
	Gu R , Guo K Q , Qi C S , et al. Properties and bonding mechanism of konjac flour-chitosan-polyvinyl alcohol blending adhesive. Transactions of the Chinese Society of Agricultural Engineering, 2010, 26 (5): 373- 378.
	顾蓉, 穆宝宁, 郭康权. 魔芋粉-壳聚糖-聚乙烯醇共混胶黏剂的结构表征. 农业工程学报, 2013, 29 (7): 277- 283.
	Gu R , Mu B N , Guo K Q . Structural characterization of konjak flour-chitosan-polyvinyl alcohol blending adhesive. Transactions of the Chinese Society of Agricultural Engineering, 2013, 29 (7): 277- 283.
	顾蓉, 穆宝宁, 郭康权. 魔芋粉-壳聚糖-聚乙烯醇共混胶黏剂的流变模型. 农业工程学报, 2014, 30 (1): 278- 284. doi: 10.3969/j.issn.1002-6819.2014.01.035
	Gu R , Mu B N , Guo K Q . Rheological model of konjak powder-chitosan-polyvinyl alcohol blending adhesive. Transactions of the Chinese Society of Agricultural Engineering, 2014, 30 (1): 278- 284. doi: 10.3969/j.issn.1002-6819.2014.01.035
	李琴, 孙可伟, 徐彬, 等. 土壤固化剂固化机理研究进展及应用. 材料导报A: 综述篇, 2011, 25 (5): 64- 67, 53.
	Li Q , Sun K W , Xu B , et al. Progress and application on curing mechanism of soil stabilize. Material Report A: Review, 2011, 25 (5): 64- 67, 53.
	刘澜, 郑怀礼, 吴幼权. 壳聚糖的改性及应用研究. 水处理技术, 2009, 35 (11): 48- 51, 56.
	Liu L , Zheng H L , Wu Y Q . Modification and application of chitosan. Technology of water treatment, 2009, 35 (11): 48- 51, 56.
	米吉福, 汪浩, 刘晶冰, 等. 土壤固化剂的研究及应用进展. 材料导报, 2017, 31 (29): 388- 391, 401.
	Mi J F , Wang H , Liu J B , et al. Research and application progress of soil stabilizer. Materials Review, 2017, 31 (29): 388- 391, 401.
	彭军仓, 段小娥, 郭文娟, 等. 河滩地圃地管理技术措施. 西北园艺(综合), 2020, 6, 19- 20.
	Peng J C , Duan X E , Guo W J , et al. Technical measures for beach and nursery land management. Northwest Horticulture (Comprehensive), 2020, 6, 19- 20.
	王碧, 岳兴建, 覃松, 等. 葡甘聚糖-壳聚糖复合膜的制备及细胞相容性评价. 华东理工大学学报, 2006, 32 (10): 1206- 1211. doi: 10.3969/j.issn.1006-3080.2006.10.014
	Wang B , Yue X J , Qin S , et al. Preparation and cytocompatibility evaluation of glucomannan chitosan composite membrane. Journal of East China University of Science and Technology, 2006, 32 (10): 1206- 1211. doi: 10.3969/j.issn.1006-3080.2006.10.014
	王丽霞, 姚闽娜, 王芹, 等. 魔芋葡甘聚糖结构的研究进展. 食品与机械, 2011, 27 (3): 143- 146. doi: 10.3969/j.issn.1003-5788.2011.03.044
	Wang L X , Yao M N , Wang Q , et al. Review of structure of konjac glucomannan. Food and Machinery, 2011, 27 (3): 143- 146. doi: 10.3969/j.issn.1003-5788.2011.03.044
	王少丽, 王然, 孙丽芳, 等. 2019. 一种可降解型土壤固结剂及其制备方法以及植物苗的移植方法. 中国专利, CN108774530A, 2018-11-09.
	Wang S L, Wang R, Sun L F, et al. 2019. A degradable soil consolidation agent and its preparation method and transplantation method of plant seedlings, Chinese patent, CN 108774530 A, 2018-11-09. [in Chinese]
	王英, 郭康权, 李家宁, 等. 魔芋葡苷聚糖/壳聚糖共混胶黏剂应用于胶合板的研究. 木材工业, 2009, 23 (2): 13- 15. doi: 10.3969/j.issn.1001-8654.2009.02.005
	Wang Y , Guo K Q , Li J N , et al. Konjac glucomannan/chitosan based adhesive for plywood production. China Wood Industry, 2009, 23 (2): 13- 15. doi: 10.3969/j.issn.1001-8654.2009.02.005
	武战翠. 2012. 聚乙烯醇基生物可降解复合材料的制备及性能研究. 兰州: 西北师范大学.
	Wu Z C. 2012. Preparation and properties of biodegradable polyvinyl alcohol composites. Lanzhou: Northwest Normal University. [in Chinese]
	夏朝红, 戴奇, 房韦, 等. 几种多糖的红外光谱研究. 武汉理工大学学报, 2007, 29 (1): 45- 47.
	Xia C H , Dai Q , Fang W , et al. Study on infrared spectra of several polysaccharides. Journal of Wuhan university of technology, 2007, 29 (1): 45- 47.
	赵国骏, 姜涌明, 孙龙生, 等. 不同来源壳聚糖的基本特性及红外光谱研究. 功能高分子学报, 1998, 11 (3): 403- 406.
	Zhao G J , Jiang Y M , Sun L S , et al. Study on basic properties and infrared spectra of chitosan from different sources. Journal of functional polymers, 1998, 11 (3): 403- 406.
	张雪梅, 张玲, 高飞虎, 等. 魔芋葡甘露聚糖的结构及改性研究进展. 南方农业, 2014, 8 (16): 41- 42, 53.
	Zhang X M , Zhang L , Gao F H , et al. Study progress in structure and modification of Konjac glucomannan. South China Agriculture, 2014, 8 (16): 41- 42, 53.
	周海龙, 申向东. 土壤固化剂的应用研究现状与展望. 材料导报A: 综述篇, 2014, 28 (5): 134- 138.
	Zhou H L , Shen X D . Application research situation and prospect of soil stabilizer. Material Report A: Review, 2014, 28 (5): 134- 138.
	周鹏, 谢明勇, 傅博强. 多糖的结构研究. 南昌大学学报(理科版), 2001, 25 (2): 197- 204. doi: 10.3969/j.issn.1006-0464.2001.02.023
	Zhou P , Xie M Y , Fu B Q . Research on the structure of polysaccharide. Journal of Nanchang university (Natural Science), 2001, 25 (2): 197- 204. doi: 10.3969/j.issn.1006-0464.2001.02.023
	邹超, 赵小燕, 刘孝国. 2014. 一种苗木移植土球凝固剂. 中国专利: CN 103540323 A, 2014-01-29.
	Zou C, Zhao X Y, Liu X G. 2014. A kind of soil ball coagulant for seedling transplantation. China Patent: CN 103540323 A, 2014-01-29. [in Chinese]
	Arnold M A . Challenges and benefits of transplanting large trees: an introduction to the workshop. Hort technology, 2005, 15 (1): 115- 117.
	Cuisinier O , Le Borgne T , Deneele D , et al. Quantification of the effects of nitrates, phosphates and chlorides on soil stabilization with lime and cement. Engineering Geology, 2011, 117 (3/4): 229- 235.
	Katsuraya K , Okuyama K , Hatanaka K , et al. Constitution of konjac glucomanan: chemical analysis and CNMR spectroscopy. Carbohydrate Polymers, 2003, 53, 183- 188. doi: 10.1016/S0144-8617(03)00039-0
	Katz L , Rauch A , Liljestrand H , et al. Mechanisms of soil stabilization with liquid ionic stabilizer. Transportation Research Record, 2001, 1757 (1): 50- 57. doi: 10.3141/1757-06
	Lin D F , Luo H L , Hsiao D H , et al. Enhancing soft subgrade soil with a sewage sludge ash/cement mixture and nano-silicon dioxide. Environmental Earth Sciences, 2016, 75 (7): 1- 11.
	Liu J , Shi B , Jiang H , et al. Research on the stabilization treatment of clay slope topsoil by organic polymer soil stabilizer. Engineering Geology, 2011, 117 (1/2): 114- 120.
	Nishinari K . Konjac glucomannan. Developments in Food Science, 2000, 41 (25): 309- 330.
	Sun Y . Big tree transplanting techniques in urban road renovation: a case study of big tree transplanting in urban road renovation of jinchang city, gansu province. Journal of Landscape Research, 2015, 7 (1): 1- 2.
	Svetlana P K , Li K . Investigation of chitosan phenolics systems as wood adhesives. Journal of Biotechnology, 2003, 102 (2): 199- 207. doi: 10.1016/S0168-1656(03)00026-9
	Tao J Q , Lin W Y , Luo X H , et al. Compressive strength analysis of ionic soil stabilizer improving soil. Key Engineering Materials, 2015, 667, 341- 346. doi: 10.4028/www.scientific.net/KEM.667.341
	Wang S , Wei D , Yang X , et al. Study on the effects of polymer-type soil consolidation agent for seedling transplantation. Scientific Reports, 2021, 11, 5575. doi: 10.1038/s41598-021-83594-2
	Wang Y J , Lin W Y , Huang Y S , et al. Analysis of durability performance of ionic soil stabilizer improving soil. Key Engineering Materials, 2015, 667, 335- 340. doi: 10.4028/www.scientific.net/KEM.667.335
	Zhao Z , Hamdan N , Shen L , et al. Biomimetic hydrogel composites for soil stabilization and contaminant mitigation. Environmental Science & Technology, 2016, 50 (22): 12401- 12410.
	Zhu Z D , Liu S Y . Utilization of a new soil stabilizer for silt subgrade. Engineering Geology, 2008, 97 (3/4): 192- 198.

样品编号 Sample No.	处理样品所用固结胶液主剂的制备条件 Preparation conditions of the main agent of consolidation glue used for sample treatment	样品初始质量 Initial mass of sample/g
样品Sample 1	对照，未用胶液固结 Control, unused glue consolidation	166
样品Sample 2	30 ℃；KGM, CA, PVA (4.5%, 4.5%, 3%)；pH 4.5	162
样品Sample 3	50 ℃；KGM, CA, PVA(4.5%, 4.5%, 3%)；pH 4.5	154
样品Sample 4	60 ℃；KGM, CA, PVA(4.5%, 4.5%, 3%)；pH 4.5	156
样品Sample 5	85 ℃；KGM, CA, PVA(4.5%, 4.5%, 3%)；pH 4.5	162
样品Sample 6	40 ℃；KGM, CA, PVA(4.5%, 4.5%, 6%)；pH 4.5	170

样品编号 Sample No.	试验1土柱质量的减少量 Experiment 1 reduction of soil column mass/g	占比 Proportion (%)	试验5土柱质量的减少量 Experiment 5 Reduction of soil column mass/g	占比 Proportion (%)	试验6土柱质量的减少量 Experiment 6 Reduction of soil column mass/g	占比 Proportion(%)
样品Sample 1	0	0	16	9.6	26	17.3
样品Sample 2	0	0	6	3.7	8	5.1
样品Sample 3	0	0	7	4.5	17	11.6
样品Sample 4	1	0.6	11	7.1	9	6.3
样品Sample 5	0	0	10	6.2	13	8.6
样品Sample 6	1	0.6	3	1.8	5	3.0
